HP 8 Internal Port SAS Controller and HP
Multi-Port Internal SAS Controller Support
Guide
HP-UX 1 1i v2, 1 1i v3
HP Part Number: 5900-01 12
Published: September 2009
Edition: 6

Advertisement

Table of Contents
loading

Summary of Contents for HP AH226A - Smart Array E500/256MB Controller RAID

  • Page 1 HP 8 Internal Port SAS Controller and HP Multi-Port Internal SAS Controller Support Guide HP-UX 1 1i v2, 1 1i v3 HP Part Number: 5900-01 12 Published: September 2009 Edition: 6...
  • Page 2 © Copyright 2009 Hewlett-Packard Development Company L.P. Legal Notices The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
  • Page 3: Table Of Contents

    Table of Contents Preface: About This Document ..................7 Intended Audience..........................7 New and Changed Documentation in This Edition................7 Publishing History..........................7 What’s in This Document........................7 Related Documents..........................8 HP Encourages Your Comments......................8 1 Controller Overview.......................9 Serial-Attached SCSI (SAS) Technology Description................9 Controller Description..........................9 Connectors and Indicators.......................11 2 Replacing a Controller....................13 Replacement Overview.........................13 Preparing the Server..........................13...
  • Page 4 Resetting the Error Counts......................31 Exiting drvcfg..........................31 Example: Adding, Viewing, and Deleting An Integrated Mirror Volume Using drvcfg.....32 Determining the Driver ID and Ctrl ID...................32 Adding An Integrated Mirror Volume....................33 Viewing the Properties of an Array....................37 Deleting an Integrated Mirror Volume....................38 The cfggen Utility..........................41 Starting cfggen..........................41 Using cfggen............................41...
  • Page 5 4 Configuring and Troubleshooting the Controller Online.........51 Introduction............................51 Troubleshooting sasd..........................51 The ioscan Utility..........................51 Displaying Interface and Disk Information................52 The sasmgr Utility...........................52 The sasmgr Command Set........................54 Using sasmgr: Common Command Examples..................57 Displaying General Statistics and Information................57 Displaying Information About Error Conditions................59 Deleting the Spare Disk........................64 Updating SAS Controller Firmware Online..................64 Performing Other Common Operations..................65...
  • Page 7: Preface: About This Document

    Preface: About This Document This document describes how to install, configure, and troubleshoot HP internal Serial-Attached SCSI (SAS) controllers on HP-UX 11i v2 and 11i v3 platforms. The latest version of this document is available online at: http://docs.hp.com/en/netcom.html Intended Audience This document is for system and network administrators responsible for installing, configuring, and managing fault tolerant data storage.
  • Page 8: Related Documents

    Chapter 4 “Configuring and Troubleshooting the Controller Online” provides information on configuring and troubleshooting the HP internal SAS controllers online using the ioscan and sasmgr commands. Appendix A “Electrostatic Discharge” provides information about preventing damage due to electrostatic discharge. Appendix B “Specifications” Related Documents For more information about HP internal SAS controllers, see: http://docs.hp.com/en/netcom.html...
  • Page 9: Controller Overview

    1 Controller Overview This chapter provides an overview of the SAS controller and its technology. This chapter includes the following topics: “Serial-Attached SCSI (SAS) Technology Description” (page 9) “Controller Description” (page 9) Serial-Attached SCSI (SAS) Technology Description Serial-attached SCSI (SAS) is a method for connecting computer peripheral devices that employs a serial (one bit at a time) means of digital data transfer over thin cables.
  • Page 10 Figure 1-1 HP 8 Internal Port PCI-X SAS Controller Controller Overview...
  • Page 11: Connectors And Indicators

    Connectors and Indicators Figure 1-2 illustrates the connectors and indicator LEDs on the HP 8 Internal Port PCI-X SAS Controller. Table 1-1 describes each component. Figure 1-2 Connectors and Indicators Table 1-1 Component Descriptions Number Description Heartbeat LED (green/amber). Flashing green indicates normal operation. Amber indicates that the card’s firmware has detected a fault.
  • Page 13: Replacing A Controller

    2 Replacing a Controller This chapter provides information on replacing an HP 8 Internal Port PCI-X SAS Controller. This chapter includes the following topics: “Replacement Overview” (page 13) “Preparing the Server” (page 13) “Replacing the Controller” (page 13) “Completing the Controller Replacement” (page 14) NOTE: The HP 8 Internal Port PCI-X SAS Controller is a factory-integrated core I/O card.
  • Page 14: Completing The Controller Replacement

    Label the connectors to the internal drive bays. The connector closest to the mounting bracket is Port 1, and the connector closest to the interior of the server is Port 2. Disconnect the cables from the PCI-X card. Depending on the server model, remove the retaining screw or open the expansion slot latch that secures the PCI-X card.
  • Page 15: Configuring The Controller Offline

    3 Configuring the Controller Offline The following information provides steps needed to configure the SAS controller during installation. This chapter includes the following topics: “Integrated RAID” (page 15) “The drvcfg Utility” (page 16) “Example: Adding, Viewing, and Deleting An Integrated Mirror Volume Using drvcfg” (page 32) “The cfggen Utility”...
  • Page 16: The Drvcfg Utility

    The drvcfg Utility This section describes in detail all of the available commands and options in the drvcfg utility. For step-by-step examples of common configuration procedures using drvcfg, see: • “Determining the Driver ID and Ctrl ID” (page 32). • “Adding An Integrated Mirror Volume”...
  • Page 17: Adapter Properties Screen

    The Adapter List screen displays a scrolling list of up to 256 SAS controllers in the system, and provides information about each of them. Use the arrow keys to select a SAS controller, and then press Enter to view and modify the selected SAS controller's properties.
  • Page 18 The information fields on the Adapter Properties screen are as follows: Adapter Indicates the specific SAS Host Bus Adapter type. PCI Address Displays the PCI address assigned by the system BIOS to the adapter. • Bus value range 0x00 - 0xFF, 0 - 255 decimal •...
  • Page 19: Raid Properties Screens

    Enabled BIOS & OS The SAS controller is controlled by both the BIOS and OS driver Enabled BIOS Only The SAS controller is controlled only by the BIOS. This setting may not be supported by all OS drivers. For example, it is not possible to disable an adapter in a Windows driver.
  • Page 20: Select New Array Type Screen

    Select New Array Type Screen Use the Select New Array Type screen to view an existing array, or create an Integrated Mirror array of two disks with an optional hot spare. See “Viewing the Properties of an Array” (page 37), “Adding An Integrated Mirror Volume”...
  • Page 21: View A New Array Screen

    Initializing Disk is initializing. CfgOffln Disk is offline at host's request. User Fail Disk is marked failed at host's request. Offline Disk is offline for some other reason. Inactive Disk has been set inactive. Not Syncd Data on disk is not synchronized with the rest of the array.
  • Page 22 Displays the bay in which devices are located. Device Identifier Displays the device identifier. RAID Disk Specifies the devices (disks) that make up an IM array. If RAID Disk is “Yes,” the device is part of an IM array; if “No,” the device is not part of an IM array.
  • Page 23: Manage A New Array Screen

    Wrg Intfc Device interface (SAS) differs from existing IM disks Pred Fail Indicates whether device SMART is predicting device failure (Yes, No). Size(MB) Indicates the size of the device in megabytes (1 megabyte = 1024 x 1024 bytes = 1,048,576 bytes). If the device is part of a two-disk array, this field will reflect the size of the array, not the size of the individual disk.
  • Page 24: Sas Topology Screen

    SAS Topology Screen SAS Topology is accessed by pressing Enter on SAS Topology from the adapter Properties screen. This screen presents a view of the adapter's SAS hierarchy, and provides other user functionality. The following objects along with their significant properties are shown: •...
  • Page 25: Device Properties Screen

    The following screen is accessed from SAS Topology: • Pressing D from an expanded enclosure accesses the Device Properties screen for the specific device, and turns on the locate LED. The following actions are performed from SAS Topology: • The SAS Topology is expanded for display by select an expander/enclosure and pressing Enter.
  • Page 26: Formatting

    Percent Complete Graphical status bar display that indicates the current relative percentage complete of the operation. Formatting On the Device Format screen, if enabled, a low-level formatting on a disk drive is allowed. Low-level formatting will completely and irreversibly erase all data on the drive. Press F to begin the format CAUTION: Once format has begun it cannot be stopped or cancelled...
  • Page 27: Advanced Device Properties Screen

    SCSI Plug and Play Mapping Automatically determines the most efficient and compatible settings. This is the default setting. Alternate CHS Mapping Uses an alternate and potentially less-efficient mapping system that might be required if a device is moved between adapters from different vendors.
  • Page 28 Native Command Queuing for SATA devices: Enabled or Disabled. • Disabled: Default setting. • Enabled: Not supported at the time of publication. IO Timeout for Block Devices Specifies the time out value for I/Os to the following devices with non-removable media: •...
  • Page 29: Spinup Properties Screen

    To toggle between LUN 0 and All, press + or -. LUN 0 scans only LUN 0. All scans all LUNs. LUNs to Scan for Sequential Devices Controls LUN scans for “SCSI Device Type 01h - Sequential Access” devices. LUNs to Scan for Other Devices Controls LUN scans for devices other than the following: •...
  • Page 30 Discovery Status A 32 bit hexadecimal that indicates the discovery status for the PHY or expander. Possible values: • Discovery completed successfully - 0x00000000 • Loop Detected - 0x00000001 • Unaddressable device exists- 0x00000002 • Multiple Ports - 0x00000004 • Expander Error - 0x00000008 •...
  • Page 31: Resetting The Error Counts

    To return to the Advanced Adapter Properties screen, press Esc. To display the next PHY, press N. To display the previous PHY, press P. Resetting the Error Counts To reset the link error counts for this PHY or all PHYs, highlight the Reset Link Error Counts field and press Enter.
  • Page 32: Example: Adding, Viewing, And Deleting An Integrated Mirror Volume Using Drvcfg

    Example: Adding, Viewing, and Deleting An Integrated Mirror Volume Using drvcfg This section provides step-by-step procedures for creating, viewing the properties of, and deleting an Integrated Mirror volume using the drvcfg utility. For a detailed discussion of all of the available drvcfg options, see “The drvcfg Utility”...
  • Page 33: Adding An Integrated Mirror Volume

    Find the SAS Host Bus Adapter’s Driver ID in the list, and make a note of the corresponding Ctrl ID. In this example, the SAS Host Bus Adapter is Drv[2C], and the Ctrl ID is 2F. Adding An Integrated Mirror Volume To add an Integrated Mirror volume, follow these steps: Start drvcfg, using the Driver ID and Ctrl ID of the SAS Host Bus Adapter (See “Determining...
  • Page 34 Select RAID Properties and press Enter. The Select New Array Type screen appears: Select Create IM Volume and press Enter. The Create New Array screen appears: Configuring the Controller Offline...
  • Page 35 Assign a disk to be the Primary disk in the array. Move the cursor to the RAID Disk column, and then to the row for the disk that will be the Primary; then press Enter. In this example, the disk in Slot Num (or port) 2 has been assigned to be the Primary: Repeat the process from the previous step to assign another disk as the Secondary;...
  • Page 36 Press D to overwrite (erase) all of the data on the disks and create a new, empty logical volume with RAID 1 mirroring. WARNING! Option M, “Keep existing data and migrate to an IM array,” is not supported. This function has been disabled in later versions of drvcfg. WARNING! If you overwrite the disks with option D and create a new array, all of the data on the disks will be permanently lost.
  • Page 37: Viewing The Properties Of An Array

    Viewing the Properties of an Array To view the properties of an existing array volume, follow these steps: Start drvcfg, using the Driver ID and Ctrl ID of the SAS Host Bus Adapter (See “Determining the Driver ID and Ctrl ID” (page 32)).
  • Page 38: Deleting An Integrated Mirror Volume

    Select View Existing Array and press Enter. The View Array screen displays, showing the total array capacity, and the assignments and status of all disks that are in arrays. In this example, one Integrated Mirror array has been defined: To change array settings, choose Manage Array and press Enter. To exit drvcfg without making any changes, press Esc.
  • Page 39 Start drvcfg, using the Driver ID and Ctrl ID of the SAS Host Bus Adapter (See “Determining the Driver ID and Ctrl ID” (page 32)). In this example, the Driver ID is 2C, and the Ctrl ID is 2F: Shell>drvcfg -s 2C 2F The Adapter List screen appears: Select the SAS Host Bus Adapter (SAS1068) and press Enter.
  • Page 40 Select View Existing Array and press Enter. The View Array screen displays, showing the total array capacity, and the assignments and status of all disks that are in arrays. In this example, one Integrated Mirror array has been defined: Select Manage Array and press Enter. The Manage Array screen appears: Configuring the Controller Offline...
  • Page 41: The Cfggen Utility

    Select Delete Array and press Enter. An additional confirmation appears. WARNING! If you delete an array, all data on the array is lost. The cfggen Utility The cfggen utility is a command line utility that runs in the Linux, EFI, and Windows Pre-Installation (WinPE) environments.
  • Page 42: Rules For Creating Im Volumes And Hot Spare Disks

    • Text surrounded by [ ] may be replaced by an optional parameter. • Parameters surrounded by {} must be entered one or more times, as appropriate for the executed command. • Do not enter the command line definition characters (<>, [ ], and {}) on the command line. Syntax: cfggen <controller #>...
  • Page 43: Using The Auto Command

    Using the AUTO Command The AUTO command automatically creates an IM volume on the SAS controllers. The volume will be created with the maximum number of disks available for use in the specified volume type. The main difference from the CREATE command is that with AUTO command user does not specify SCSI ID values for disks to use in the volume.
  • Page 44: Parameters

    Parameters <controller #> A SAS controller number between 0 and 255. [noprompt] Eliminates warnings and prompts. Operation After entering the DELETE command you will be prompted to be sure if you want to proceed with the command. Answer “yes” if you want to proceed. DISPLAY This DISPLAY command displays information about controller configurations: controller type, firmware version, BIOS version, volume information, and physical drive information.
  • Page 45 Enclosure # Slot # Target ID State : Ready (RDY) Size (in MB)/(in sectors) : 70007/143374738 Manufacturer : HP Model Number : DG072A8B54 Firmware Revision : HPD6 Serial No : 3LB02CXH00008523E83Z Drive Type : SAS Target on ID #5 Device is a Hard disk Enclosure # Slot # Target ID...
  • Page 46: Logical Drive Status Values

    Start TargetID Start Bus Logical drive status values: Okay (OKY) Volume is Active and drives are functioning properly and user data is protected if the current RAID level provides data protection. Degraded (DGD) Volume is Active and the user's data is not fully protected due to a configuration change or drive failure;...
  • Page 47: Status

    This command will not complete and return to a shell prompt until the format operation is complete. Depending on the capacity and model of disk drive, this can take a considerable amount of time. STATUS The STATUS command displays the status of any volume synchronization operation that is currently in progress on the controller.
  • Page 48: Disableir

    Faulty controller or peripheral hardware (such as cables, disk drives, etc.) will not cause this utility to hang. It will exit with the appropriate return value. If an operation fails, clear the fault condition by whatever means necessary and retry the operation. DISABLEIR The DISABLEIR command turns off IR functionality on a SAS controller, by setting the MPI_IOUNITPAGE1_DISABLE_IR bit in the IO Unit 1 MPT Configuration Page.
  • Page 49 The sasflash.efi utility and firmware images are included on the IPF Offline Diagnostics and Utilities CD, version 0803 and later. To update the adapter firmware offline, follow the procedures provided with the sasflash utility. CAUTION: If you have updated the adapter firmware using sasflash, booting a disk with an older version of SerialSCSI-00 (including Ignite-UX) might download an older version of the firmware and EFI driver to all HBAs controlled by SerialSCSI-00 in the system.
  • Page 51: Configuring And Troubleshooting The Controller Online

    4 Configuring and Troubleshooting the Controller Online This chapter describes the online configuration, troubleshooting, and maintenance tools for HP internal SAS controllers. This chapter includes the following topics: “Introduction” (page 51) “Troubleshooting sasd” (page 51) “The sasmgr Command Set” (page 54) “Using sasmgr: Common Command Examples”...
  • Page 52: Displaying Interface And Disk Information

    /usr/sbin/ioscan [-F] -m dsf [devfile] /usr/sbin/ioscan -m hwpath [-F] [-H hw_path] /usr/sbin/ioscan -s /usr/sbin/ioscan -r -H hw_path /usr/sbin/ioscan -B /usr/sbin/ioscan -U /usr/sbin/ioscan -a [-F] For a complete explanation of ioscan command line options and parameters for the version of HP-UX that you are using, see the ioscan(1M) manpage. Displaying Interface and Disk Information The following example will display information about interface cards which use the sasd driver: # ioscan -fnkd sasd...
  • Page 53 sasmgr [-h] clear_stat -D device_file sasmgr [-h] clear_stat -D device_file -q all sasmgr [-h] clear_stat -D device_file -q phy={all | phy_id} sasmgr [-h] clear_stat -D device_file -q phy_in_port={all | phy_id} sasmgr [-h] clear_stat -D device_file -q target={all | sasaddr} sasmgr [-h][-f] delete -D device_file -q raid -q raid_vol={rvol_id | all} sasmgr [-h][-f] delete -D device_file -q raid -q spare sasmgr [-h][-f] disable -D device_file...
  • Page 54: The Sasmgr Command Set

    sasmgr [-h] set_attr -D device_file -q lun=lun_dsf -q locate_led={on | off} sasmgr [-h][-f] set_attr -D device_file -q raid -q raid_vol=rvol_id -q state=vol_state sasmgr [-h][-f] set_attr -D device_file -q raid -q raid_vol=rvol_id -q rebuild_rate=rebuild_rate A -N option has been added to the sasmgr utility for HP-UX 11i v3. For example: sasmgr -N get_info -D /dev/sasd0 -q raid When this option is specified for some commands, it enables you to specify the persistent device file as input to a qualifier.
  • Page 55 The following qualifier must be specified with the bdr command: • lun - Resets the specified target device. This is a destructive operation. If the -f option is not specified with this command, sasmgr displays a warning message before continuing. Otherwise, it suppresses the warning message and executes the command.
  • Page 56 NOTE: To update SAS controller firmware online, you must be running version 11.31.0909 or higher of the sasd driver. Online SAS controller firmware updates are not supported on systems running HP-UX 11i v2. If you do not specify the -f option with this command, sasmgr displays a warning message before continuing.
  • Page 57: Using Sasmgr: Common Command Examples

    This command is typically intended for replacing a bad drive. This operation must not be used while there are outstanding I/O requests to the lun_dsf or to any LUNs under the new_hw_path. If the -f option is not specified, sasmgr displays a warning message before proceeding.
  • Page 58 PHY Health : UP Port SAS Address : 0x500605b00016f700 Attached SAS Address : 0x500000e0126926d2 Current Link Rate : 3 Gbps Max Link Rate : 3 Gbps Info for PHY ID PHY Health : UP Port SAS Address : 0x500605b00016f701 Attached SAS Address : 0x500000e012691cb2 Current Link Rate : 3 Gbps...
  • Page 59: Displaying Information About Error Conditions

    /dev/rdsk/c1t4d0 0x500000e01122d7d2 34732 /dev/rdsk/c1t7d0 0x500000e01263fcc2 34732 ---------- LOGICAL DRIVE 4 ---------- Raid Level : RAID 1 Volume sas address : 0x611d224fa01c82 Device Special File : /dev/rdsk/c1t10d0 Raid State : OPTIMAL Raid Status Flag : ENABLED Raid Size : 34000 Rebuild Rate : 20.00 % Rebuild Progress : 100.00 %...
  • Page 60 Time at which HBA went to online state : Mon Dec 11 19:57:29 No. of times HBA went offline Time at which HBA went to offline state : N/A No. of times HBA went to transient state Time at which HBA went to transient state : Mon Dec 11 19:57:08 No.
  • Page 61 No. of IO data length mismatch TM Statistics NOTE: TM stats are derived from target stats. NOTE: Clearing target stats affects TM stats. No. of TMs posted to HAL No. of TMs aborted on ccb_send_list No. of TMs timed-out on iotm_res_wait_q No.
  • Page 62 HAL resource allocation retry count Flash f/w update count No resource to ACK count No resource to process Device event count No resource to process PHY event count Reply frame bounds error count Reply frame offset error count Stale tag count Context Reply for non-IO count Tag bounds check fail count Heart Beat bad reply status count...
  • Page 63 No. of times PHY went Down Time PHY went Down : N/A Seconds since PHY statistics was last cleared : 1165910402 Statistics for PHY ID No. of times PHY came UP Time PHY came UP : Wed Dec 31 19:00:00 No.
  • Page 64: Deleting The Spare Disk

    No. of Loss Dword Syncs No. of PHY Reset Problems encountered Statistics for PHY ID No. of Invalid Dwords No. of Running Parity Errors No. of Loss Dword Syncs No. of PHY Reset Problems encountered Statistics for PHY ID No. of Invalid Dwords No.
  • Page 65: Performing Other Common Operations

    NOTE: To update SAS controller firmware online, you must be running version 11.31.0909 or higher of the sasd driver. Online SAS controller firmware updates are not supported on systems running HP-UX 11i v2. For example, to update the firmware of the controller with the device file /dev/sasd0 online with the firmware file sas1068_b0fw.fw: sasmgr download -D /dev/sasd0 -q downloadfile=sas1068_b0fw.fw -q hba NOTE:...
  • Page 66 io_redirect_dsf(1M) manpage. To view the manpage, enter this command: man 1m io_redirect_dsf WARNING! If you shut down a server to replace a failed disk offline, the DSF of the failed disk will not be visible in ioscan when the server restarts. The DSF is required by the replace_tgt command to rebuild the array with the new disk.
  • Page 67: Recommendations

    Reassign the original device file to the new I/O path using sasmgr with the replace_tgt qualifier: # sasmgr replace_tgt -D /dev/sasd0 -q old_tgt=/dev/dsk/c3t2d0 -q new_tgt_hwpath=0/4/1/0.0.0.1.0 WARNING: This is a DESTRUCTIVE operation. This might result in failure of current I/O requests. Do you want to continue ?(y/n) [n]...y LUN has been replaced with new Target.
  • Page 68: Update To The Latest Drivers And Firmware

    After the disk is replaced, use sasmgr(1M) to configure the new disk as spare: sasmgr add -D /dev/sasdX -q raid -q spare -q enc_bay=<enc>:<bay> (where X is the instance of the SAS controller and <enc>:<bay> is the location of the disk to be configured as spare).
  • Page 69: A Electrostatic Discharge

    A Electrostatic Discharge This appendix discusses ways to prevent damage to your system due to Electrostatic Discharge (ESD). This appendix addresses the following topics: “Handling Parts” (page 69) “Grounding” (page 69) Handling Parts To prevent damage to your system, you must take precautions when setting up the system or handling parts.
  • Page 71: B Specifications

    B Specifications HP 8 Internal Port SAS Controller Specifications Table B-1 HP 8 Internal Port PCI-X SAS Controller Physical Specifications Dimensions (excluding bracket) 16.8 x 6.4 x 1.6 cm (6.6 x 2.5 x 0.6 in ) Data Transfer Method 64-bit wide, PCI-X 133 MHz (1 GB/s maximum bandwidth) PCI Bus Speed PCI-X-133 and 3.3 volt PCI compatibility only PCI Compatibility...
