Maytag MFI2266AEU Parts List page 4

REFRIGERATOR LINER PARTS
For Models: MFI2266AEW11, MFI2266AEB11, MFI2266AEQ11, MFI2266AES11, MFI2266AEU11
(White) (Black) (Bisque)
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 67006328 Module, Light
3 67006326 Foil, Light
4 67006327 Cover, Light
5 67006316 Grille, Air
6 12466103 Switch, Light (2)
7 67006318 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light
10 Y12570701 Socket, Light
11 67006330 Cover, Water Tank
(Upper)
12 67006331 Lid, Water Filter
13 67006329 Cover, Water Tank
(Lower)
14 UKF8001AXX Filter, Water
15 67006325 Bracket, Filter
Base
16 12002355 Thermistor
17 67006324 Bracket, Water
Tank & Valve
18 12956202 Water Tank &
Head Assembly
19 12664501 Plug, Bypass
20 67006322 Valve, Water Inlet
21 W10165861 Cover, Ice Box
Harness
22 M0238642 Screw
23 67006319 Cover, Chiller
Vent
24 W10165864 Waterline, Cabinet
(W/Nut)
25 W10118193 Enclosure, Water
Valve Connector
26 W10118194 Lid, Enclosure
4
(Stainless) (Ultra Silver)
W10239572
