Maytag MFI2266AEU Parts List page 16

For Models: MFI2266AEW11, MFI2266AEB11, MFI2266AEQ11, MFI2266AES11, MFI2266AEU11
Illus. Part
No. No. DESCRIPTION
1 67006433 Screw
2 W10156818 Blade, Fan
3 12591404 Basepan
4 67006425 Screw
5 67004954 Screw (3)
6 67006737 Screw, Clip
7 W10119239 Harness, Evap
Heater
8 67004713 Pan, Drain
9 61004743 Grommet (3)
10 W10166768 Heater, Defrost
11 2264017 Capacitor
12 W10128791 Start Device
13 61003210 Seal, Condenser
Shroud
14 67006387 Thermostat,
Defrost
15 67005680 Grommet (2)
16 12820504 Pad, Acoustic
17 2255199 Strap, Bale
18 W10135027 Condenser
19 67005149 Roller (2)
20 67001080 Tray, Drip
UNIT PARTS
(White) (Black)
Illus. Part
No. No.
21 67006434 Axle (2)
22 W10166256 Evaporator
23
W10162951 Right Side
W10162962 Left Side
24 67004432 Motor, Fan
25 10428101 Clip, Heater
26 13060202 Harness, Unit
27 W10143759 Drier
28 W10134623 Compressor
29 W10183709 Tube, Discharge
30 67006573 Screw
31 12575309 Shroud
32 67004953 Bracket, Fan Motor
33 67006432 Screw (3)
34 10547003 Clip, Drier
35 W10169124 Grommet (4)
36 10623002 Clip, Evaporator
37 W10117502 Grommet, Cond. (4)
(Bisque) (Stainless)
Illus.
DESCRIPTION No.
Dam
and Optional Parts Not Included
with Power Cord
(Includes Items
11, 12, 17, 27,
& 35)
16
(Ultra Silver)
Part
No. DESCRIPTION
Following Parts Not Illustrated
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.0 Ozs.
(R−134A)
W10239572
