Grass Trimmer
Operator's Manual
MODEL
Read rules for safe operation and instructions carefully. ECHO provides an Operator's
Manual and a Safety Manual. Both must be read and understood for proper and safe
operation.
X7702273900
GT-2000EZR
Serial Number 03001001 - 03999999
WARNING
DANGER
X770000370
01/02
Advertisement
Table of Contents
Related Manuals for Echo GT-2000EZR
Summary of Contents for Echo GT-2000EZR
- Page 1 Grass Trimmer Operator's Manual MODEL Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X7702273900 GT-2000EZR Serial Number 03001001 - 03999999...
- Page 3 Manual, write to ECHO, INCORPORATED, 400 Oakwood Road, Lake Zurich, IL 60047. •Keep shield and other components in place and in good condition. Do not use attachments or other parts not approved by ECHO. GT style (non-blade capable) units must not be converted to blade use except Maxi-Cuts or similar ECHO approved attachments.
-
Page 4: International Symbols
PERSONAL CONDITION AND SAFETY EQUIPMENT Trimmer/Brush Cutter users risk injury to themselves and others if the trimmer/brush cutter is used improperly and or safety precautions are not followed. Proper clothing and safety gear must be worn when operating a trimmer. -
Page 5: Extended Operation/Extreme Conditions
Use only ECHO approved attachments. Serious injury may result from the use of a non approved attachment combi- nation. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual. -
Page 6: Safe Operation
The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions, shield installation and positioning of the front handle are necessary. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. - Page 7 _____ 1 - Plastic Bag (Co-Pack) _____ - Operator's Manual _____ - Safety Manual _____ - Shield Assembly _____ 1 - Nylon Trimmer Head _____ - 12, 8 in. x .080 Pre-cut Nylon Line _____ - Hardware Bag _____ - 1, Locking Tool...
- Page 8 CUT-OFF KNIFE - Trims line to the correct length (5"). If trimmer is operated without a cut-off knife the line will become too long - more than (5") - the operating speed will slow, the engine overheat and performance will suffer.
-
Page 9: Specifications
PECIFICATIONS RASS RIMMER PERATOR ANUAL l f f ) l i . t i . l f i r t " 4... -
Page 10: Plastic Shield
Remember to remove the locking tool. NYLON LINE REPLACEMENT Tools Required: None Parts Required: Two (2) ECHO 0.080 (2 mm) Nylon Trimmer Line 203 mm (8 in.) long Shut engine off. Lay unit on the ground with head assembly up. -
Page 11: Pre-Operation
Emission Defect Warranty Explanation.) IMPORTANT Echo Premium 2-Stroke Oil may be mixed at 50:1 ratio for applica- tion in all Echo engines sold in the past regardless of ratio speci- fied in those manuals. Mixing Instructions 1. Fill an approved fuel container with half of the required amount of gasoline. - Page 12 IMPORTANT Spilled fuel is a leading cause of hydrocarbon emissions. Some states may require the use of automatic fuel shut-off containers to reduce fuel spillage. Contact your ECHO dealer for ordering information. After refueling • Wipe any spilled fuel from the unit.
-
Page 13: Grass Trimmer
WARNING Never attempt to disassemble this recoil starter otherwise serious personal injury may result. See your Echo Dealer if the starter handle will not operate using light pulling force. NOTE Energy is stored in the starter spring each time the handle/rope is pulled. -
Page 14: Starting Warm Engine
WARNING The cutting attachment should not rotate at idle. If attachment rotates, readjust carburetor according to "Carburetor Adjustment" instructions in this manual or see your ECHO Dealer, otherwise serious personal injury may result. Stop Switch Move stop switch button (A) away from the STOP position. -
Page 15: Stopping Engine
ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed see your Echo dealer for repairs. -
Page 16: Maintenance Intervals
MAINTENANCE INTERVALS t l i n i l l f f ) s l s t l l l i ® l a i . y l . s t l l i... -
Page 17: Air Filter
AIR FILTER Level 1. Tools required: Cleaning brush, 25 or 50 mm (1 or 2 in.) medium bristle paint brush. Parts required: 90008 REPOWER 1. Close choke (Cold Start Position). This prevents dirt from entering the carburetor throat when the air filter is removed. Brush accumulated dirt from the air cleaner area. -
Page 18: Spark Plug
SPARK PLUG Level 2. Tools Required: Spark Plug socket wrench and screw driver, Feeler gauge. Preferably a wire gauge. Parts Required: 90064 REPOWER Remove spark plug and check for fouling, worn and rounded center electrode. Clean the plug or replace with a new one. DO NOT sand blast to clean. -
Page 19: Exhaust System
Remove the four screws that retain the cover. Two at the top of the Recoil Starter, two on either side of the front. Lift the cover from the engine and lay to the front of the trimmer. NOTE The throttle linkage remains assembled to the cover and the spark plug lead and grommet remain installed. -
Page 20: Carburetor Adjustment
Accelerate to full throttle to check for smooth transition from idle to full throttle. If engine stops or stalls after full warm up return the unit to your authorized ECHO dealer for repair. Check HI speed RPM at W.O.T. (Wide Open Throttle). HI speed RPM should be set to specifications found on page 9 "Specifica-... - Page 21 LUBRICATION Level 1. Tools Required: 8mm Open End Wrench, Screwdriver, Clean Rag. Parts Required: ECHO LUBE 8 oz. (P/N 91014) or ® Lithium Base Grease. Remove plastic shield. Loosen bearing housing locating screw (A), at the top of the housing, loosen mounting screw (B) and remove gear case from drive housing.
-
Page 22: Troubleshooting
ROUBLESHOOTING i l y s t r t ' n e r i t l i f t l i f y l r i l o Fuel vapors are extremely flammable and may cause fire and/or explosion. Never test for ignition spark near an open spark plug opening, otherwise serious personal injury may result. - Page 23 TORAGE Long Term Storage (over 30 days) During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious property damage or personal injury may result.
-
Page 24: Echo Consumer Product Support
• Sending a check or money order for $2.00 per Parts Catalog or $1.50 per Operator's Manual made payable to ECHO, INCORPORATED. State on a sheet of paper the model number and serial number of the ECHO unit you have, part number of the manual (if known), your name and address and mail to address below. -
Page 25: Plastic Shield
IMPORTANT Remember to remove the locking tool. SUP22203524 SUPPLEMENT TO OPERATOR'S MANUAL PART NUMBER X7702273900 (X770000370) FOR MODEL: GT-2000EZR S/N 03001001 & UP Please use this Operator Manual Supplement when assembling and maintaining your GT-2000EZR. ____ - Safety Manual ____... - Page 26 Disengage the heat deflector tabs (G) under the muffler from the slots in the engine/muffler cover. SUP22203562 SUPPLEMENT TO OPERATOR'S MANUAL FOR MODELS: GT-201EZR S/N 02001001- 02999999 PART NUMBER X7702274001 (X770000381) FOR MODELS: GT-2000EZR S/N 03001001- 03999999 PART NUMBER X7702273900 (X770000370) 99922203562 04/02...
- Page 27 Lift the cover from the engine and lay to the front of the trimmer. NOTE The throttle linkage remains assembled to the cover. 10. Reinstall spark plug to prevent dirt and debris from entering engine. 11. Use a brush to remove dirt from the cylinder fins.
