- Page 1 PR400 ™ Commercial Series Two-Way Radio User Guide Manuel de l'utilisateur de la radio bidirectionnelle...
-
Page 2: Computer Software Copyrights
Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent... -
Page 3: Table Of Contents
Wall Charger......16 CONTENTS Desktop Chargers..... 16 Rapid Charger . - Page 4 Repeater or Talkaround Mode ...31 Scan....... 39 Revert Memory Channel (1 &...
- Page 5 Tone Preferences ....51 Tones On/Off......53 Keypad On/Off Tones .
- Page 6 Notes: English...
-
Page 7: Safety
RF Exposure booklet enclosed with your radio (Motorola Publication part number 68P81095C98) to ensure compliance with RF energy exposure limits. For a list of Motorola-approved antennas, batteries, and other accessories, visit the following web site which lists approved accessories: http://www.motorola.com/cgiss/ index.shtml. - Page 8 Notes: English...
-
Page 9: Introduction
any one radio and minimizes channel/ INTRODUCTION talkgroup congestion. Some of the benefits of trunked two-way radio ® Your PR400™ radio can operate on both LTR systems are: trunked and conventional radio systems. This • No channel/talkgroup monitoring required prior radio combines the very latest in two-way to transmission technology while delivering outstanding... -
Page 10: Pr400 Radio Features
radio sends a “channel/talkgroup request” to • Transmit Time-Out Timer • Monitor and Sticky Permanent Monitor the home repeater. The system then sends • System Scan with 2 Priority Levels and Revert back a “channel/talkgroup grant” to the user’s Scan radio. - Page 11 • DTMF Signaling - DTMF PTT ID - DTMF Encode Selective Call - DTMF Call Alert Encode Encode English...
- Page 12 Notes: English...
-
Page 13: Radio Overview
RADIO OVERVIEW Antenna On/Off/Volume Belt Knob Clip Channel Selector Push-to-Talk Knob (PTT) Button LED Indicator Microphone/ Side Button 1 Speaker (programmable) Display Front Button P2 (programmable) Menu Scroll Side Button 2 Buttons (programmable) Front Button P1 (programmable) Accessory Connector with a Dust Cover DTMF Keypad English... -
Page 14: Accessory Information
ACCESSORY INFORMATION Remove the Battery Attach the Battery Locked Unlocked Battery Latch Turn off the radio if it is turned on (see page 27). Slide the battery latch into the unlock position. Align the battery to the battery rails on the Disengage by pushing downward and holding back of the radio (approximately 1/2 in. -
Page 15: Attach The Antenna
Attach the Antenna Remove the Antenna Turn the antenna clockwise to attach it. Turn the antenna counter-clockwise to remove English... -
Page 16: Attach The Belt Clip
Attach the Belt Clip Remove the Belt Clip Belt Clip Tab Align the grooves of the belt clip with those of Use a key to press the belt clip tab away from the battery. the battery to unlock the belt clip. Press the belt clip downward until you hear a Slide the belt clip upward to remove it. -
Page 17: Battery Information
Always charge a new battery 14 to 16 battery was designed specifically to be used hours before initial use, regardless of the with a Motorola charger. Charging in non- status indicated by the charger. Motorola equipment may lead to battery... -
Page 18: Wall Charger
WALL CHARGER Unplug the charger from the electrical outlet and radio after 10 hours. Note: Do not use the wall charger if using lithium- ion (Li-Ion) or nickel-metal hydride (NiMH) Note: After the initial charge of 14 to 16 batteries. The wall charger is for a nickel- hours, do not charge the battery more cadmium (NiCd) battery only. -
Page 19: Slow Charger
The battery is battery for 14 to 16 hours prior to initial use fully charged after 11 hours. for best performance. A list of Motorola authorized batteries and battery chargers appears on page 66. The listed chargers will charge only Motorola English... -
Page 20: Battery Charge Status
BATTERY CHARGE STATUS LED INDICATOR Indicates power-up, transmit, receive, scan You can check battery charge status if your monitor status, channel/talkgroup busy, Call dealer has preprogrammed one of the Alert™ receive/transmit, Selective Call receive/ programmable buttons. Hold down the transmit, and battery status. preprogrammed Battery Indicator button. -
Page 21: Display
DISPLAY Symbol Indication PERS4 Indicates scan has stopped on an active Priority 1 •Priority 1 Scan channel/talkgroup. • flashing) The top display row displays menu and radio status information: Indicates scan has stopped on an active Priority 2 Symbol Indication Priority 2 Scan channel/talkgroup. -
Page 22: Dtmf Keypad
DTMF KEYPAD Entering Characters Using the DTMF Keypad Number of Times Button is Pressed Button The keypad is used for: • Dialing a phone number. • Entering information when programming phone lists. • Accessing a repeater. • Each key can generate several different characters. -
Page 23: Indicator Tones
INDICATOR TONES Positive Negative Programmable High pitched tone Low pitched tone Indicator Tone Indicator Tone Buttons Scan Start Stop Self Test Pass Tone Power Level High Squelch Tight Normal Self Test Fail Tone Repeater/ Does not use Uses repeater Talkaround repeater Enabled Disabled... -
Page 24: Programmable Buttons
PROGRAMMABLE BUTTONS In the “Button” column, have your dealer record the name of the programmable button Your radio has four programmable buttons. next to the feature that has been programmed Your dealer can program these buttons as to it. shortcuts to various radio features. The dealer can use the abbreviations (S1, S2, Check with your dealer for a complete list of P1, or P2) shown in the radio illustration on... - Page 25 Programmable Features Feature Indicator Short Press Long Press Hold Down Page Button Battery — — Checks the Indicator battery charge status. Menu Mode — button enters Menu Mode and — selects menu options. Once in Menu Mode, button is automatically †...
- Page 26 Programmable Features (Continued) Feature Indicator Short Press Long Press Hold Down Page Button Store Memory — Stores current — Channel (1&2) channel/talkgroup to the home channel/talkgroup. — Home Revert If a Revert Memory Channel is an LTR — AutoKey (1&2) talkgroup, the radio keys-up and trans- mits an MDC PTT ID.
- Page 27 Programmable Features (Continued) Feature Indicator Short Press Long Press Hold Down Page Button † Phone Directly access phone mode. — 45,46 † Speed Dial Quickly access speed dial phone list. — † Escalert — Toggle escalert on and off. — Squelch —...
-
Page 28: Menu Buttons
MENU BUTTONS to scroll through the sub-menu options. Select the option with a short press of Menu Button button. If preprogrammed by your dealer, the two front Exit the Menu buttons ( ) can be used, in conjunction with other programmable features, While in Menu Mode, the button is to access and select menu options (... -
Page 29: Getting Started
ADJUST THE VOLUME GETTING STARTED Turn the On/Off/Volume Control knob TURN THE RADIO ON OR OFF clockwise to increase the volume, or counterclockwise to decrease the volume. –or– Note: Your dealer can preprogram one of the programmable buttons to Volume Set. button Hold down the Volume Set (see... -
Page 30: Select An Ltr Channel/Talkgroup
SELECT AN LTR CHANNEL/ SELECT A CONVENTIONAL RADIO TALKGROUP CHANNEL Your PR400 display radio can be programmed Your radio offers 64 conventional channels. with up to 10 LTR sites and a maximum of 100 To select a channel, turn the Channel talkgroups, in total, across one or more sites Selector knob clockwise or counterclockwise (up to a total of 10 sites). -
Page 31: Monitor
Permanent Monitor Listen for voice activity. • The LED indicator flashes red while your A long press of the preprogrammed Monitor radio is receiving. button places the radio in Permanent Monitor mode. To respond, hold the radio vertically 1 to 2 •... -
Page 32: Transmit An Ltr Call
TRANSMIT AN LTR CALL TRANSMIT A CONVENTIONAL CALL Turn the Channel Selector knob to select the appropriate LTR channel/talkgroup. Turn your radio on. –or– to select the appropriate LTR Use the Channel Selector knob to select the channel/talkgroup. desired channel. Note: Monitor for traffic before transmitting to Hold the microphone in a vertical position at a... -
Page 33: Call Light (Trunked Operation Only)
CALL LIGHT To Select either Repeater Mode or Talkaround Mode (TRUNKED OPERATION ONLY) Press the preprogrammed Repeater/ The Call Light indicator informs you that you Talkaround button (see page 23) to toggle have received a call from a specified LTR ®... -
Page 34: Revert Memory Channel (1 & 2)
REVERT MEMORY CHANNEL (1 & 2) HOME REVERT AUTOKEY (1 & 2) The Revert Memory Channel feature allows If a Revert Memory Channel is an LTR you to instantly access up to two of your talkgroup, the Home Revert AutoKey feature favorite channels/talkgroups at the touch of a automatically keys-up and transmits an MDC button. -
Page 35: Enable/Disable Headset Sidetone
You can select channels/talkgroups to enable Turn the radio on. During transmit, you will or disable VOX as preprogrammed by your hear your voice through the headset while dealer/programmer. you speak. Select a channel/talkgroup that has been To disable the headset sidetone, turn off your preprogrammed by your dealer to enable radio and turn the radio on again. -
Page 36: Keypad Lock/Unlock
KEYPAD LOCK/UNLOCK to scroll through the standard TPL frequencies or DPL codes. To lock or unlock the keypad, long press the preprogrammed Keypad Lock/Unlock button - or - (see page 24). Enter a non-standard or standard 4-digit TPL frequency or the 3-digit octal (numbers 0-7 Note: The L symbol appears on the display when only) code for DPL via the DTMF microphone... -
Page 37: Radio Calls
• The LED indicator flashes yellow, if programmed RADIO CALLS by your dealer/programmer. SELECTIVE RADIO INHIBIT • You hear two high-pitched tones. Your radio is equipped with a security feature 1 To acknowledge the call, press and release the that can temporarily render the unit inoperative PTT button. -
Page 38: Receive A Call Alert™ Page (Conventional Operation Only)
RECEIVE A CALL ALERT™ PAGE F to enter menu mode (CONVENTIONAL OPERATION ONLY) RAD CALL until When you receive a Call Alert page: RAD CALL to select • The display shows F and the preprogrammed name or ID of the calling radio. SEL CALL until •... -
Page 39: Repeater Access
REPEATER ACCESS to enter menu mode Use this feature to send DTMF tones to a RAD CALL repeater. until Press and hold the PTT button and enter your RAD CALL to select access code using the DTMF keypad. CALL ALT until Press and release the required DTMF buttons. - Page 40 Notes: English...
-
Page 41: Scan
TALKBACK SCAN The Talkback feature allows you to respond to Your radio is equipped with the Scan feature, a transmission while scanning. If transmission which allows you to monitor multiple channels/ is detected on a channel/talkgroup while talkgroups for voice activity. The radio will stop scanning, the radio will stop on that channel/ on a channel/talkgroup when it detects activity talkgroup for a default period of time after... -
Page 42: Stop System Scan
Note: Your dealer/programmer can preprogram SYS SCAN to select your radio when exiting System Scan to automatically revert to the last scan channel/ The display shows the current scan status. talkgroup that had activity on it or to automatically revert to the channel/talkgroup SCAN ON until where scan was initiated. -
Page 43: Delete A Nuisance Channel/Talkgroup
DELETE A NUISANCE CHANNEL/ Restore Channels/Talkgroups to the Scan List TALKGROUP Note: Your dealer/programmer must preprogram a Power off the radio. Once the radio is powered button to access this feature (see page 24). on again, the deleted nuisance channels/ talkgroups are restored to the scan list. -
Page 44: Edit A Scan List
EDIT A SCAN LIST channel/talkgroup Note: One Scan list per available. Your radio can support up to 16 Scan lists. Each Scan list can contain up to 16 channels/ to select SCAN LST talkgroups. The same channel/talkgroup can be included in several Scan lists, and the same until ADD ITEM Scan list can be assigned to several channels/... -
Page 45: Prioritize A Channel Or Talkgroup In A Scan List
ADD ITEM Priority Scanning Sequence to return to Channel/ DELETE – or – Talkgroup until you exit menu mode. None specified Ch1 Ch2 Ch3 Ch4 …Ch1 PRIORITIZE A CHANNEL OR Channel/ Ch2 Ch1 Ch2 Ch3 Talkgroup 2 TALKGROUP IN A SCAN LIST Ch2 Ch4 Ch2 …Ch1 (Priority 1) You may want to check the activity on one or... - Page 46 Set Priority Channels/Talkgroups until you see the channel/talk- Note: You cannot assign the same priority to two group you want to prioritize. different channels/talkgroups. SELECTED – or – until to enter menu mode. to select the current channel/talkgroup the PROG LST until radio is on.
-
Page 47: Phone
access code is sent automatically when you PHONE exit phone mode. Your radio allows you to place and receive Manual - Enter your access/deaccess code telephone calls through a repeater (depending using the DTMF keypad. on phone line availability). You can edit the RECEIVE A PHONE CALL D phone list through your radio’s menu (see page 48). -
Page 48: Disconnect A Phone Call
MAKE A PHONE CALL D Press and hold the PTT button to talk. Hold the radio in a vertical position with the Note: Only the first 8 digits of the phone number will microphone 1 to 2 inches (2.5 to 5 cm) away be displayed on your radio's display. - Page 49 XXXXXXXX When your party answers, press and hold the select a number from PTT button to talk. Hold the radio in a vertical the phone list. position with the microphone 1 to 2 inches (2.5 to 5 cm) away from your mouth. Release –...
-
Page 50: Edit The Phone List
EDIT THE PHONE LIST Use the DTMF keypad to enter the name (see Entering Characters Using the DTMF Keypad Your radio contains a Phone list that holds up on page 20.) to 25 phone numbers. You can edit the Phone list in three ways through your radio’s menu: to store the name, •... -
Page 51: Delete An Entry
Delete an Entry Edit an Entry to enter menu mode. to enter menu mode. PROG LST PROG LST until until PROG LST to select PROG LST to select PHN LST until PHN LST until PHN LST to select PHN LST to select DELETE until... -
Page 52: Edit Access/Deaccess Codes
PHN LST to confirm your selection. until PHN LST 12 Use the DTMF keypad to edit the entry (see to select Entering Characters Using the DTMF Keypad EDT CODE on page 20.) until – or – EDT CODE to select until you see the location where you want to store the phone number. -
Page 53: Tone Preferences
TONE PREFERENCES You can use the radio’s menu to access user- adjustable settings to customize the tones on your radio. to enter menu mode. TONES until TONES to select until you see the feature you want to change (see the table on page 52). to select the feature. - Page 54 Tone Settings Feature What it Does Settings TONE Turns all alert tones on or off. KPD TONE Turns the keypad tones on or off. TONE TAG STANDARD Assigns a specific tone when receiving a specific type of ALERT 1 – 6 radio call.
-
Page 55: Tones On/Off
TONES ON/OFF KEYPAD ON/OFF TONES You can program your radio to enable or You can program your radio to enable or disable all keypad tones. disable all alert tones. Note: Tones for the programmable buttons to enter Menu mode. and Side Buttons 1 and 2 can not be disabled. -
Page 56: Call Tone Tagging (Conventional Operation Only)
CALL TONE TAGGING TONE TAG to return to (CONVENTIONAL OPERATION ONLY) until you exit the menu mode. You can program your radio to sound a particular alert tone when receiving Selective ESCALERT Call or Call Alert (call tone tagging). (CONVENTIONALOPERATION ONLY) Note: Seven alert tones are available to select from You can program your radio to increase the... -
Page 57: User Settings
USER SETTINGS You can use the radio’s menu to access user- adjustable settings to customize some of your radio features. to enter menu mode. UTILITY until UTILITY to select until you see the feature you want to change (see table on page 56). to select the feature. - Page 58 Utilities Features Feature What it Does Settings SQUELCH TIGHT Changes the squelch of the radio to tight or normal. NORMAL PWR LVL HIGHz Changes the power level of the radio to high or low. OPT BRD Enables or disables an option board. LIGHT Enables or disables the radio’s keypad and display backlight.
-
Page 59: Set Squelch Level
SET SQUELCH LEVEL SET POWER LEVEL B Use this feature to filter out (unwanted) calls Each channel/talkgroup in your radio has a and/or background noise. However, tightening predefined transmit power level that can be squelch could cause calls from remote changed. -
Page 60: Option Board On/Off
HIGH until until – or – until – or – until to select the current setting. to select the current setting. OPTION BOARD ON/OFF SET THE LIGHTS Use this feature to enable or disable an option Use this feature to enable or disable the radio’s board. -
Page 61: Display The Software Version
DISPLAY THE SOFTWARE VERSION Use this feature to view the current software version of your radio. to enter menu mode. until UTILITY to select UTILITY SOFTWARE until to view the software version. until you exit menu mode. English... - Page 62 Notes: English...
-
Page 63: Warranty
One (1) Year connection with the Product, or for operation of the Product with any ancillary equipment, and all MOTOROLA, at its option, will at no charge either such equipment is expressly excluded from this repair the Product (with new or reconditioned warranty. - Page 64 LIMITATION OR EXCLUSIONS MAY NOT Product. Repair, replacement or refund of the APPLY. purchase price, at MOTOROLA’s option, is the exclusive remedy. THIS WARRANTY IS GIVEN This warranty gives specific legal rights, and there IN LIEU OF ALL OTHER EXPRESS may be other rights which may vary from state to WARRANTIES.
- Page 65 VI. PATENT AND SOFTWARE PROVISIONS: Product of non-MOTOROLA supplied equipment) which adversely affect performance MOTOROLA will defend, at its own expense, any of the Product or interfere with MOTOROLA's suit brought against the end user purchaser to the normal warranty inspection and testing of the extent that it is based on a claim that the Product Product to verify any warranty claim.
- Page 66 B)that MOTOROLA will have sole control of the Laws in the United States and other countries defense of such suit and all negotiations for its preserve for MOTOROLA certain exclusive rights settlement or compromise; and for copyrighted MOTOROLA software such as the...
-
Page 67: Accessories
CARRY ACCESSORIES ACCESSORIES RLN5496 Leather DTMF Case with 2-1/2 inch Motorola offers a number of accessories to Swivel (for Full-Display models) enhance the productivity of your two-way RLN5497 Leather DTMF Case with 3 inch radio. Many of the available accessories are Swivel (for Full-Display models) listed below. -
Page 68: Chargers
RLN4815 Universal Radio Pak HMN9013 Lightweight Headset w/o In-line PTT RLN4570 Break-A-Way Chest Pack RMN4016 Lightweight Headset with In-line PTT 1505596Z02 Replacement Strap for HLN6602 RLN5238 Lightweight Headset with In-line PTT, Universal Chest Pack NFL Style 4280384F89 Belt Lengthener for RLN4815 HMN9021 Medium Weight Over the Head Dual Universal Radio Pak... -
Page 69: Surveillance Accessories
REX4648 Replacement Foam Ear Pad and RLN5317 2-Wire Comfort Earpiece w/Mic & Windscreen Kit for use with headsets PTT for use with HMN9754 & HMN9013 & RMN4016 NTN8371 (Beige) 7580376E34 Replacement Ear Seals for use with RLN5318 2-Wire Comfort Earpiece w/Mic & headsets HMN9021 &... -
Page 70: Ear Microphone Systems
REMOTE SPEAKER MICROPHONES 5080371E73 Replacement Ear Tip for use with low noise kit NTN8371 (Beige) 5080371E75 Replacement Ear Tip for use with low HMN9030 Remote Speaker Microphone noise kit NTN8371 (Black) HKN9094 Replacement Cord for HMN9030 7580372E11 Replacement Ear Cushion for use with earpiece BDN6720 MISCELLANEOUS EAR MICROPHONE SYSTEMS... - Page 71 Turn the Radio On or Off 1. Rotate the On/Off/Volume knob clockwise. You will hear the self-test pass tone and see the display icons light momentarily and LED indicator flash green. ™ PR400 Quick Reference Card 2. Rotate the On/Off/Volume knob counterclockwise until you hear a click and both the display and the LED indicators turn off.
- Page 72 Restore Channels/Talkgroups to the Scan List Audio Indicators for Programmable Buttons Power off the radio then turn it on. – OR – Press the preprogrammed Scan button Positive Negative to stop the scan. The deleted nuisance channels/talkgroups are restored to the Programmable Buttons Indicator Tone Indicator Tone...
-
Page 73: Menu Navigation Chart
Menu Navigation Chart (Refer to Menu Navigation guidelines— lower, left-hand corner of this page) Rptr/ System Edit PL/ Program Phone Tones Utility Radio Call Scan DPL Codes Talkarnd Lists (p. 45) (p. 51) (p. 55) (p. 35) (p. 39) (p. 34) (p. - Page 76 © Motorola, Inc. 2005. All rights reserved. Printed in U.S.A. MOTOROLA et le logotype au M stylisé sont enregistrés auprès du Bureau des marques et brevets des États-Unis. Tous les autres noms de produits et de services sont la propriété de leurs titulaires respectifs.
