42
IBM System x3800 Type 8865: User's Guide
Memory card
retention levers
3. Remove the memory card.
a. Open the memory card retention levers on the top of the memory card.
b. While holding the retention levers open, lift the memory card out of the
server.
4. Place a memory card on a flat, static-protected surface with the DIMM
connectors facing up.
Attention: To avoid breaking the DIMM retaining clips or damaging the
DIMM connectors, open and close the clips gently.
5. Open the retaining clip on each end of the DIMM connector and remove the
DIMM or DIMMs to be replaced.
6. Touch the static-protective package that contains the DIMM to any unpainted
metal surface on the outside of the server; then, remove the DIMM from the
package.
7. Turn the DIMM so that the DIMM keys align correctly with the slot.
