28 C
HAPTER
Clearing and
Applying System
Configuration
Settings
Downloaded from www.Manualslib.com
3: C B
ONFIGURING THE RIDGE
Table 8 Connection Status Page (continued)
Current Channel
Security
Rx Data Rate (Mbps) The most recent data reception
Tx Data Rate (Mbps) The most recent data transmission
Link Quality
Received Signal
Strength
Activity (Packets Rx)
Activity (Packets Tx)
IP Address
The pages in the Configuration Management System have two buttons:
Clear and Apply.
Clear returns the settings to the values they were when you last
■
clicked Apply.
Apply stores the settings permanently in the nonvolatile flash memory.
■
After you click Apply, the new settings take effect and you can see the
changes on the System Summary page.
CAUTION: Your changes are lost if you forget to
moving to a new configuration page.
manuals search engine
The channel over which the Bridge
is communicating with clients.
The type of security for which the
Bridge is configured.
rate.
rate.
The normalized transmitted data
rate (that is, the current data rate
over the maximum data rate).
Note: Link Quality is shown in
Infrastructure mode only.
The strength of the radio signal
that the Bridge detects.
Note: Received Signal Strength is
shown in Infrastructure mode only.
The number of packets the Bridge
has received.
The number of packets the Bridge
has transmitted.
The IP address of the Bridge.
Varies
Open System
(no security)
N/A
N/A
N/A
N/A
N/A
N/A
Varies
click Apply before
