Illus.
Part
No.
No.
DESCRIPTION
1 W10153099 Cover, Access
2
9763501BL Support, Front
& Rear
3
Brace, Drawer
4453720 Right
4453721 Left
4
9761796 Enclosure,
Warming Drawer
5
Side, Base
9759953 Right
9759954 Left
W10269051
DRAWER PARTS
For Models: KGSS907SBL02, KGSS907SWH02, KGSS907SSS02
(Black)
Illus.
Part
No.
No.
6 W10058460 Foot
7
9758676 Support, Element
8
3196037 Foot Assembly
9
4449809 Screw
10 W10164163 Drawer
11
W10155633 Right
W10155632 Left
12 W10164169 Panel, Drawer
(White)
(Stainless)
Illus.
DESCRIPTION
No.
13
14
Slide, Drawer
15
16
17 W10207401 Element, Warming
7
Part
No.
DESCRIPTION
Front, Drawer
W10203760 Black
W10203762 White
W10203763 Stainless
Handle, Drawer
W10292375 Black
W10292379 White
W10292374 Stainless
3196537 Screw
8274149 Thermistor
