KitchenAid KGSS907SBL - 30" Slide-In Gas Range Parts List page 6

DOOR PARTS
For Models: KGSS907SBL02, KGSS907SWH02, KGSS907SSS02
(Black)
Illus. Part
No. No.
1 9759413 Panel, Door
2 9757706 Glass, Inner
3 4451722 Insulation, Door
4 4457132 Retainer, Glass
5
9760579 Right
9760580 Left
6 9759225 Glass, Inner
7 4457114 Shield, Heat
8 9759229 Bracket, Glass
9 4457104 Shield, Heat Top
10 9759225 Glass, Inner Door
11 9759230 Bracket, Central
12
W10246114 Right
W10246113 Left
13 8522415 Seal, Window
14
W10131888 Black
W10131889 White
15
W10292381 Black
W10292382 White
W10292380 Stainless
16 3196184 Screw
17 4448520 Bumper, Door
18
W10243392 Black
W10243393 White
W10243391 Stainless
(White) (Stainless)
DESCRIPTION
Hinge, Oven Door
Bottom
Side
Bracket, Handle
Assembly, Door
Kit
Handle, Door
Badge
6 W10269051
