Dual XDVD700 Installation & Owner's Manual

Dvd multimedia receiver with 7” touch screen display
Hide thumbs
Table of Contents

Advertisement

Quick Links

XDVD700
INSTALLATION/OWNER'S MANUAL
DVD Multimedia Receiver with 7" Touch Screen Display
TOUCH
Safety Notes:
The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature to
prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the parking
brake is engaged. It is illegal in most states for the driver to view video while the vehicle is in motion.

Advertisement

Table of Contents

Troubleshooting

loading

Related Manuals for Dual XDVD700

Summary of Contents for Dual XDVD700

  • Page 1 XDVD700 INSTALLATION/OWNER’S MANUAL DVD Multimedia Receiver with 7” Touch Screen Display TOUCH Safety Notes: The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the parking...
  • Page 2 Copyright Notes This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.

  • Page 3: Table Of Contents

    Some DVD discs can be played only in certain playback modes according to the intentions of the software. As the XDVD700 plays discs according to their intentions, some functions may not work as intended. Please be sure to read the instructions provided with each disc. This player has been designed to play back DVD software that has been encoded for specific region areas.
  • Page 4 XDVD700 PREPARATION Upon installation of this Monitor/DVD player (“unit”) into a vehicle, the driver of the vehicle must not operate this unit by watching videos or playing video games while driving. Failure to follow this instruction could lead to driver distraction which could result in serious injury or death to the vehicle’s occupants or persons outside the vehicle and/or...

  • Page 5: Safety Information/Precautions

    Please read all instructions carefully before attempting to install or operate. Due to its technical nature, it is highly recommended that your DUAL XDVD700 is installed by a professional installer or an authorized dealer. This product is only for use in vehicles with 1VDC negative ground only.
  • Page 6 XDVD700 INSTALLATION Preparation Please read entire manual before installation. Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
  • Page 7 In-dash DVD video functions will only operate when vehicle is in Park and the parking brake is engaged. It is illegal in most states for the driver to view video while the vehicle is in motion. Altering or defeating this safety feature is a violation of law and is prohibited. XDVD700 INSTALLATION...
  • Page 8 XDVD700 INSTALLATION Wiring Diagram - Optional A/V Connections...
  • Page 9 Remove the battery holder Remove the battery from the battery holder Install the new battery Make sure to keep the (+) side up Insert the battery holder XDVD700 OPERATION IR Remote Preparation Notes: • Remove the battery if the remote will not be used for a month or longer •...

  • Page 10: Control Locations - Monitor Closed

    XDVD700 OPERATION Control Locations - Monitor Closed Band Auto Store/Preset Scan Secondary LCD Display Open/Close Monitor Eject Rotary Encoder/Enter Mode Monitor Notes: • This model incorporates a motorized moving monitor. Before final installation, make sure the monitor will not obstruct the dash, shifter or any other controls.
  • Page 11 MUTE POWER ON/OFF VOLUME XDVD700 Control Functions - Monitor Closed Press BAND to increment from FM1, FM, FM3, AM ] FM1. The FM band indicator is shown as "1", "" or "3" and is located on the far left side of the secondary LCD.

  • Page 12: Control Locations - Monitor Open

    XDVD700 OPERATION Control Locations - Monitor Open Disc-in indicator - Red = Disc inserted, White = No disc. ANGLE  - Press to decrease the monitor view angle. ANGLE  - Press to increase the monitor view angle. INFO - Press to display DVD INFO. Press and hold to access the Picture Menu and adjust the CONTRAST and BRIGHTNESS.
  • Page 13 RESET button for 3 seconds, located on the front bottom-right corner of the unit. After a system reset, the unit restores some of the factory default settings. Note: Use the tip of a pen to access the button. XDVD700 OPERATION System Reset...

  • Page 14: Control Locations - Remote

    XDVD700 OPERATION Control Locations - Remote Mode Mute Open/Close Power Key #1 Key # Key #3 Volume Up Key #4 Key #5 Key #6 Volume Down Key #7 Key #8 Key #9 * The remote control uses one 3 volt Lithium CR05 battery. For best performance, replace only with CR05 or equivalent.
  • Page 15 Fast Forward Zoom Audio Angle Sub-Title XDVD700 Control Functions - Remote Press once to incrementally select desired source. Press once to MUTE audio, press again to return audio. Press once to open monitor, press again to close the monitor. Press once to turn the unit on, press again to turn unit off.

  • Page 16: General Operation

    XDVD700 OPERATION General Operation Power On/Off Monitor Open/Close Monitor Angle Position Press POWER momentarily to turn the unit on, the unit will beep. Press and hold POWER for more than  seconds to turn the unit off. Note: EJECT will still function even if POWER is off.
  • Page 17 (from front panel) Audio Adjustment (from Remote) XDVD700 Press MODE to select between TUNER, DVD and AUX IN inputs. Modes of operation are indicated in the OSD (On Screen Display) and secondary LCD. With the monitor open, press the top left corner of the screen to display the OSD menu.
  • Page 18 XDVD700 OPERATION General Operation INFO/PIC BRIGHTNESS/CONTRAST BAND AS/PS (Auto Store /Preset Scan) DISP EJECT RIGHT ROTARY MODE TRACK/SEEK UP TRACK/SEEK DOWN STOP PLAY/PAUSE FAST FORWARD/TUNE UP FAST REVERSE/TUNE DOWN SECONDARY LCD Press INFO button for 1 second to display DVD disc information.
  • Page 19 The rotary encoder can also control touch screen functions from the main menu. • • • XDVD700 Press the ENTER button on the right ROTARY knob. Press the MENU button on the remote control. Touch the upper left corner of the touch screen.

  • Page 20: General Setup Menu

    XDVD700 OPERATION General Setup Menu General Setup Menu Settings Default Radio Video Out Disable TFT Auto Open Clock Mode 1Hr Clock Anti-Theft Code 0000 Anti-Theft Load Factory • Upon entering Setup Menu, the General tab is the default display. •...
  • Page 21 XDVD700 OPERATION General Setup Menu Select Radio Region From the General Setup Menu, press Radio. Touch the setting for your region. Video Out From the General Setup Menu, press Video Out. Touch the desired setting (Disable or Enable). TFT Auto Open From the General Setup Menu, press TFT Auto Open.
  • Page 22 XDVD700 OPERATION General Setup Menu Clock Mode Clock Adjust Anti-theft Code From the General Setup Menu, press Clock Mode. Touch the desired setting to choose a 1-hour or 4-hour clock display. From the General Setup Menu, press the current time on the Clock line, and a keypad will appear.
  • Page 23 OK. Load Factory From the General Setup Menu, press Load Factory. Press YES to factory parameters to their original settlings, The unit will prompt for confirmation before reloading the factory settings. XDVD700 XDVD700 OPERATION OPERATION General Setup Menu...

  • Page 24: Screen Setup Menu

    XDVD700 OPERATION Screen Setup Menu Screen Setup Menu Settings Default Screen Tilt Screen Saver TS Calibrate Version Screen Tilt • Press the Screen tab to access Screen Setup Menu. • Select desired parameter to change. • Page will return back to previous screen after 10 seconds of inactivity or by pressing the BACK button.
  • Page 25 XDVD700 OPERATION Screen Setup Menu From the Screen Setup Menu, press Screen Saver. Touch On to activate the Screen Saver screen saver or Off to deactivate it. From the Screen Setup Menu, press TS Calibrate. Touch Yes to enter Touch Touch Screen Calibrate Screen Calibration Mode.

  • Page 26: Language Setup

    XDVD700 OPERATION Language Setup Menu Language Setup Menu Settings Default Subtitle English, French, Spanish, Auto, Off Select desired disc subtitle language Audio English DVD menu English Disc Subtitle • Press the Language tab to access Language Setup Menu. • Select desired parameter to change.
  • Page 27 XDVD700 OPERATION Language Setup Menu From the Language Setup Menu, press Audio. Select the desired disc audio Audio Language language. From the Language Setup Menu, press DVD menu. Select the desired disc DVD Menu menu language.

  • Page 28: Video Setup Menu

    XDVD700 OPERATION Video Setup Menu Video Setup Manu TV Shape View Mode • Press the Video tab to access Video Setup Menu. • Select desired parameter to change. • Page will return back to previous screen after 10 seconds of inactivity or by pressing the BACK button.

  • Page 29: Rating Setup

    The default rating password is 9991. From the Rating Setup Menu, press Rating to select the desired rating level. The Set Rating Level unlock icon must appear beside "----" to adjust the rating level. XDVD700 OPERATION Rating Setup Menu...
  • Page 30 XDVD700 OPERATION AM/FM Tuner Operation - OSD Overview Tuner Mode From the main menu, touch TUNER icon on the screen to select AM/FM Tuner mode. Current Source Indicator Displays source currently playing. Tune Frequency - Down Touching this icon will tune the radio to a lower frequency by one frequency step.
  • Page 31 Indicates current volume level, controlled by rotary encoder. Band Indicator Shows which band the radio is tuned to, FM-1, FM-, FM-3, or AM. Seek Next Station - Down Touching this icon will tune to the next strong station at a lower frequency. XDVD700 XDVD700 OPERATION OPERATION...

  • Page 32: Am/Fm Tuner Operation

    XDVD700 OPERATION AM/FM Tuner Operation AM/FM Tuner Mode Band Manual Tuning Seek Tuning Preset Scan Scan Tuning Local Tuning From the main menu, touch TUNER icon to select AM/FM Tuner mode. From the remote control or the front panel: Press MODE until TUNER is displayed on the screen.
  • Page 33 Touch and hold the AS icon to automatically program the 1 strongest Auto Store Presets stations available into the presets in the current band. Press the AS/PS button for more than  seconds. XDVD700 AM/FM Tuner Operation to scroll through the presets. When the correct preset is OPERATION...
  • Page 34 XDVD700 OPERATION Upon installation of this Monitor/DVD player (“unit”) into a vehicle, the driver of the vehicle must not operate this unit by watching videos or playing video games while driving. Failure to follow this instruction could lead to driver distraction which could result in serious injury or death to the vehicle’s occupants or persons outside the vehicle and/or...
  • Page 35 DVD and AUX IN audio can be heard while the vehicle is in motion without engaging the parking brake. Follow these two initialization procedures carefully to allow video playback on XDVD700 front panel TFT: There are two situations that start the PARKING BRAKE sequence. First situation is while driving:...

  • Page 36: Dvd Operation

    Some DVD discs can be played only in certain playback modes according to the intentions of the software. As the XDVD700 plays discs according to their intentions, some functions may not work as intended. Please be sure to read the instructions provided with each disc. This player has been designed to play back DVD software that has been encoded for specific region areas.
  • Page 37 XDVD700 OPERATION DVD Operation - Inserting a Disc DVD Loading Slot Eject button Insert CD/DVD with label facing upwards With the label facing up, insert a standard size disc into the slot. The disc will Inserting a disc automatically begin playback. Other sub-menus may have to be pressed to access the DVD movie/music content.
  • Page 38 XDVD700 OPERATION DVD Operation - Touch Screen Controls Hidden Touch Screen Areas A - Displays MAIN menu B - Displays DVD disc information C - Selects PREVIOUS chapter D - Selects NEXT chapter E - Displays the full DVD transport controls...
  • Page 39 Stop Fast Reverse Fast Forward Repeat A-B Repeat Audio Mode XDVD700 Jumps to the DVD Title menu. Activates sub-titles and cycles between multiple sub-title languages. Touch the icon to temporarily stop or resume playback. Touch the icon to stop the chapter where it is.
  • Page 40 Notes: Some DVD discs can be played only in certain playback modes according to the intentions of the software. As the XDVD700 plays discs according to their intentions, some functions may not work as intended. Please be sure to read the instructions provided with each disc.
  • Page 41 ROOT button will return to the bonus menu instead of the main menu.) Pressing ROOT again will usually return to the current chapter. XDVD700 to fast forward or to fast reverse. B icon once to select a start point. Touch it a second time to...
  • Page 42 XDVD700 OPERATION CD Operation - OSD Overview CD Mode From the main menu, touch DVD icon on the screen to select CD mode. Current Source Indicator Displays source currently playing. Fast Reverse Touch the icon to fast reverse at x speed.
  • Page 43 This function is available in track view only. Refer to page 44. Stop Touch the icon to stop the song where it is. Volume Indicator Indicates current volume level, controlled by rotary encoder. Track Select - Down Touching this icon will select the previous track. XDVD700 OPERATION to select it.

  • Page 44: Cd Operation

    XDVD700 OPERATION CD Operation Playing CD-DA discs Selecting by Keypad Selecting by Direct Track Access Previous/Next Page After inserting a CD disc, files will play in numerical order. Touch to display keypad. Enter desired track number and press OK. Touch desired track for DIRECT TRACK access.
  • Page 45 Press to fast forward. Press to fast reverse. XDVD700 OPERATION once to return to the beginning of the current track. Press a to scroll through the tracks. When the correct track is icon to display a numeric keyboard. Enter desired track number...
  • Page 46 XDVD700 OPERATION CD Operation Shuffle Mode Repeat Mode Scan Mode Play/Pause Stop Touch the Shuffle button to shuffle all of the tracks on the CD. The Shuffle button will be illuminated while Shuffle Mode is active. When the button is illuminated, touching it a second time will disable Shuffle Mode.
  • Page 47 Touching this icon will select the next song. Song Number Indicator Displays current song number and total number of songs in the current folder. XDVD700 icon to fast reverse at x speed. icon to temporarily stop or resume playback. icon to fast forward at x speed.
  • Page 48 XDVD700 OPERATION MP3/WMA Operation - OSD Overview Clock Indicates current time. Elapsed Time Indicator Shows how much time has elapsed in the current song. Current Filename Indicates filename of current song. Display Press to select between standard display and filename view.

  • Page 49: Mp3/Wma Operation

    OK to select it. From the remote control: Use the numeric keypad to enter the desired song number. XDVD700 MP3/WMA Operation once to return to the beginning of the current song. Press a to scroll through the songs. When the correct song is highlighted icon to display a numeric keyboard.
  • Page 50 XDVD700 OPERATION MP3/WMA Operation Song Control Shuffle Mode Repeat Mode Scan Mode Play/Pause Stop You can use the Fast Forward or Fast Reverse on-screen buttons to speed up the playback of a song. Each subsequent press of the button will change the speed from normal to x to 4x to 8x to 16x and back to 1x.

  • Page 51: Media Compatibility Information

    Media Compatibility Playback Order Compatible Recording Formats XDVD700 The following types of discs/files are compatible: • CD-ROM (ISO), CD-R, CD-RW, DVD+R/RW, DVD-R/RW • CD-DA, DVD Video • MP3 data • WMA data The following types of discs/files are not compatible: •...
  • Page 52 XDVD700 OPERATION Media Compatibility Additional MP3/WMA Information Sampling Frequency Rates Transfer Bit rates Recommended Settings An internal buffer provides ESP (Electronic Skip Protection) to virtually eliminate skipping. When playing a disc recorded with regular audio files (CD-DA or .WAV) and MP3/WMA files, the unit will play the MP3/WMA files only.

  • Page 53: Warranty

    This warranty gives you specific legal rights. You may also have other rights which vary from state to state. Dual Electronics Corp. warrants this product to the original purchaser to be free from defects in material and workmanship for a period of one year from the date of the original purchase.

  • Page 54: Troubleshooting

    XDVD700 OPERATION Troubleshooting Problem Unit will not turn on Yellow wire not connected or incorrect voltage (no power) Red wire not connected or incorrect voltage Black wire not connected Fuse blown Unit has power Speaker wires not connected (but no sound)

  • Page 55: Specifications

    CEA-006 Power Standard Specifications (reference: 14.4VDC +/- 0.V, 0Hz~0kHz) Power Output: 17 Watts RMS x 4 channels at 4 ohms and < 1% THD+N Signal to Noise Ratio: 80dBA (reference: 1 watt into 4 ohms) XDVD700 OPERATION Specifications 10Hz-20kHz >60dB 8.5dBf...
  • Page 56 Dual Electronics Corp. Toll Free: 1-866-38-5476 www.dualav.com ©007 Dual Electronics Corp. All rights reserved. NSA0707-V1.1 Printed in China...
