MINOURA RS-1600 Instruction Manual

Repair stand

Advertisement

Quick Links

Made in Japan
For More Information /
If you have any questions or need help, you should contact the dealer where you purchased
or the Minoura distributor in your country first. Only when you cannot get enough service,
you can contact us. The distributor info is found on our web site.
もし何かわからないことがあった場合は, まずお買い求めになったショップにお問い合わせください。
もしそこで十分な情報やサービスを受けられない場合に限り,下記までお問い合わせください。
Contact /
お問い合わせ先
MINOURA Japan Headquarters
(for ALL customers)
1197-1 Godo, Anpachi, Gifu 503-2305 Japan
Phone: +81-584-27-3131 / Fax: +81-584-27-7505
Mail: minoura@minoura.jp
Web: www.minoura.jp
株式会社 箕浦
〒 503-2305 岐阜県安八郡神戸町神戸 1197-1
Phone (0584) 27-3131 / Fax (0584) 27-7505
infodesk@minoura.jp / www.minoura.jp
Repair Stand RS-1600 instructions manual /
サポートが必要なときは
MINOURA North America
1996 East Ave, Hayward, CA 94541
Phone: 1-510-538-8599 / Fax: 1-510-538-5899
Mail: support@minourausa.com
株式会社 深谷産業
〒 460-0015 名古屋市中区大井町 1-38
Phone (052) 321-6571 / Fax (052) 332-3166
www.fukaya-sangyo.co.jp
Important Notes
!
注意していただきたいこと
• For normal 2-wheel bicycle only.
通常の2輪自転車専用です。
• Read this instructions manual
carefully before use, and keep handy
at all times.
使用前にこの説明書をしっかりと読み,
常に手元に保管し参照してください。
• Maintain the balance by rotating the
bike position.
自転車の向きを変える際は,バランスに注意
して行なってください。
• For light maintenance only. Do not
apply too much force.
軽いメンテナンス用のスタンドです。あまり
力を入れた作業には向きません。
• No disassembling and modification
by yourself are allowed.
弊社の許可を受けない分解や改造は行なわな
いでください。
• Minoura offers 5-year limited warranty
for the original user who purchased
through authorized Minoura dealer in
brand-new condition only.
弊社では,正規販売店で新品状態で購入いた
だいた最初のユーザに限り,5年間の品質保
証を行なっています(消耗品を除く) 。
(for U.S. residents only)
取扱説明書
