13
Remove the four screws that secure the hard drive to
the hard drive bracket.
Screw
Screw
14
Remove the bracket from the old drive.
15
Insert the new drive into the bracket, label side up, so
the screw holes line up.
16
Replace the four screws that secure the bracket to the
drive.
17
Slide the new hard drive into your convertible
notebook, then replace the screw that secures the hard
drive to your convertible notebook.
18
Replace the hard drive bay cover, then tighten the cover
screws.
19
Insert the main and optional multibay batteries, then
turn your convertible notebook over.
20
Connect to the optional port replicator.
-OR-
Connect the power adapter, modem cable, and network
cable.
21
Turn on your convertible notebook, open the DVD drive,
insert the Windows DVD, close the DVD drive, then
restart your convertible notebook.
22
When the prompt "Press any key to boot from CD
or DVD" appears, press any key on your keyboard and
follow the on-screen instructions. As part of the process
you may be prompted to insert your Drivers and
Applications Recovery disc.
23
Reconnect all peripheral devices and replace any
PC cards.
Screw
Screw
