Table 5-4
Class: HP_CoolingRedundancySet
Property name
Description
ElementName
InstanceID
MaxNumberSupported
MinNumberNeeded
TypeOfSet
LoadBalanceAlgorithm
RedundancyStatus

5.3.4HP_MemberOfCoolingRedundancy

HP_MemberOfCoolingRedundancy is used to represent an association between HP_Fan and
HP_CoolingRedundancySet. The Windows implementation class is
HP_WinMemberOfCoolingRedundancy.
Table 5-5
Class: HP_MemberOfCoolingRedundancy
Property name
Collection
Member
Property implementation
Cooling Redundancy Set n is collection of fault tolerant
fans that provide redundant cooling, where n
represents the number of the redundancy set instance.
Cooling Redundancy Set n, where n represents the
number of the redundancy set instance.
CIM_SystemSpecificCollection
HPQ:HP_WinCoolingRedundancySet:x, where x is a
unique identifier for this cooling redundancy instance
(for example, 1,2,...).
CIM_RedundancySet
Represents the maximum number of fans supported for
this redundancy set
Not supported.
2 (N+1)
0 (Unknown)
•
0 (Unknown)—if the redundancy status is
unknown
•
2 (Fully Redundant)—if the all fans in the set are
operating properly and enough to achieve
redundancy
•
3 (Degraded Redundancy)—if there are at least
enough fans for the redundancy set to provide
cooling, but fans have failed
•
4 (Redundancy Lost)—if there are not enough fans
required to achieve redundancy, but enough for
the redundancy set to provide cooling
•
5 (Overall Failure)—if there are not enough fans
operating properly for the redundancy set to
provide cooling.
Property implementation
References HP_CoolingRedundancySet
References HP_Fan
System fan 67
