INSTRUCTION MANUAL
AUTO CHARGE
4000
AUTOMATIC BATTERY CHARGER
MODEL #091-89-12
NOTE : This charger is designed for vehicles with
dual batteries and negative ground.
INPUT :120 volt, 50/60 Hz, 8 amps
3 YEAR WARRANTY
KUSSMAUL ELECTRONICS CO., INC
170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796
TEL: in NY 631-567-0314
OUTPUT: 40 AMPERES
TOLL FREE: 800-346-0857
file: 091-89-12.p65
Rev.A
10-27-2004
.
FAX: 631-567-5826
