Manual Del Usuario
Network your
computers and
share your ADSL
Internet access
User Manual
User Manual
ADSL Modem
with High-Speed Mode
Wireless G Router
Designed to Meet ADSL2+ Specification
EN
Manuals and/or Software are
available in your local language:
FR
Les manuels et/ou le logiciel sont
disponibles en français :
DE
Benutzerhandbuch und/oder
Software gibt es in Ihrer Sprache:
NL
Voor Nederlandstalige handleidingen
en/of software kunt u terecht op:
ES
Los manuales y/o el software están
disponibles en la lengua local:
IT
I manuali e/o il software nella
propria lingua si trovano su:
www.belkin.co.uk/support
802.11g
F5D7633uk4
Mbps
2.4GHz • Wireless
Advertisement
Table of Contents
Related Manuals for Belkin F5D7633uk4
Summary of Contents for Belkin F5D7633uk4
-
Page 1: Internet Access
Voor Nederlandstalige handleidingen en/of software kunt u terecht op: Los manuales y/o el software están disponibles en la lengua local: I manuali e/o il software nella propria lingua si trovano su: www.belkin.co.uk/support User Manual User Manual F5D7633uk4 Mbps 802.11g 2.4GHz • Wireless... -
Page 2: Table Of Contents
Benefits of a Home Network ......3 Advantages of a Belkin Wireless Network ....3 2 Make Sure You Have the Following . -
Page 3: Introduction
Introduction Thank you for purchasing the Belkin ADSL Modem with High-Speed Mode Wireless G Router (the Router). In minutes you will be able to share your Internet connection and network your computers with your new Router. The following is a list of features that make your Router an ideal solution for your home or small office network. - Page 4 Introduction Introduction 125 High-Speed Mode High-Speed Mode (HSM)*, a 54g™ performance enhancement, provides the fastest wireless connectivity for 802.11g-capable networks in real-world environments. It is designed for home networks that require additional bandwidth for applications such as sharing digital pictures. 125HSM makes 802.11g WLANs more efficient without impacting the performance of neighboring networks, and it is compatible at high speeds with leading brands.
-
Page 5: Benefits Of A Home Network
– set up and access printers, computers, and other networking devices from anywhere in your home Easy Expansion – the wide range of Belkin networking products let you expand your network to include devices such as printers and gaming consoles No cabling required –... -
Page 6: Make Sure You Have The Following
Make Sure You Have the Following Package Contents • ADSL Modem with High-Speed Mode Wireless G Router • RJ11 Telephone Cord - Gray • RJ45 Ethernet Networking Cable - Yellow • ADSL Microfilter* • Power Adapter • User Manual CD *ADSL microfilter varies by country. -
Page 7: Knowing Your Router
Knowing your Router The Router is designed to be placed on a desktop. All of the cables exit from the rear of the Router for better organization and utility. The LED indicators are easily visible on the front of the Router to provide you with information about network activity and status. - Page 8 Knowing your Router WLAN Status LED The WLAN Status LED is solid GREEN when you enable the wireless LAN function. It flashes when the Router is transmitting or receiving data wirelessly. WLAN is off Green WLAN is up and connected Green - blinking When transmitted or receiving data ADSL LED...
- Page 9 Knowing your Router Back Panel DSL Line This port is for connection to your ADSL line. Connect your ADSL line to this port. Ethernet Ports The Ethernet ports are RJ45, 10/100 auto-negotiation. The ports are labeled 1 through 4. These ports correspond to the numbered LEDs on the front of the Router.
-
Page 10: Connecting Your Router
Connecting your Router Positioning your Router Your wireless connection will be stronger the closer your computer is to your Router. Typical indoor operating range for your wireless devices is between 100 and 200 feet. In the same way, your wireless connection and performance will degrade somewhat as the distance between your Router connected devices increases. -
Page 11: Connecting Your Computers
Connecting your Router Connecting your Computers Power off your computers and networking equipment. Connect your computer to one of the YELLOW RJ45 ports on the rear of the Router labeled “connections to your computers” by using an Ethernet networking cable (one Ethernet network cable is supplied). -
Page 12: Connecting Your Adsl Line
Connecting your Router Connecting your ADSL Line Connection for the Router to the ADSL line varies by country and region. Typically it involves a microfilter or a microfilter with built-in splitter to allow simultaneous use of ADSL service and telephone service on the same telephone line. - Page 13 Connecting your Router Note: One RJ11 telephone cord is supplied. When inserting an RJ11 plug, be sure the tab on the plug clicks into position to ensure that it is properly seated. If you have a dedicated ADSL service telephone line with an RJ11 wall jack, simply connect a telephone cord from the wall jack to gray RJ11 port labeled “DSL line”...
-
Page 14: Powering Up Your Router
Connecting your Router Powering Up your Router Connect the supplied power adapter to the Router power-input plug labeled “Power”. Note: For safety and performance reasons, only use the supplied power adapter to prevent damage to the Router. After connecting the power adapter and the power source is turned on, the Router’s power icon on the front panel should be on. -
Page 15: Setting Up Your Computers
Setting Up your Computers In order for your computer to properly communicate with your Router, you will need to change your computer’s “TCP/IP Ethernet” settings to “Obtain an IP address automatically/Using DHCP”. This is normally the default setting in most home computers. You can set up the computer that is connected to the ADSL modem FIRST using these steps. - Page 16 Setting Up your Computers Manually Configuring Network Adapters in Windows 98SE or Me Right-click on “My Network Neighborhood” and select “Properties” from the drop-down menu. Select “TCP/IP -> settings” for your installed network adapter. You will see the following window. If “Specify an IP address”...
- Page 17 Setting Up your Computers Set up the computer that is connected to the cable or DSL modem by FIRST using these steps. You can also use these steps to add computers to your Router after the Router has been set up to connect to the Internet.
- Page 18 Setting Up your Computers If not already set, at “Configure:”, choose “Using DHCP Server”. This will tell the computer to obtain an IP address from the Router. Close the window. If you made any changes, the following window will appear. Click “Save”. Restart the computer.
- Page 19 Setting Up your Computers Manually Configuring Network Adapters in Mac OS X Click on the “System Preferences” icon. Select “Network” (1) from the “System Preferences” menu. Select “Built-in Ethernet” (2) next to “Show” in the Network menu.
- Page 20 Setting Up your Computers Select the “TCP/IP” tab (3). Next to “Configure” (4), you should see “Manually” or “Using DHCP”. If you do not, check the PPPoE tab (5) to make sure that “Connect using PPPoE” is NOT selected. If it is, you will need to configure your Router for a PPPoE connection type using your user name and password.
-
Page 21: Recommended Web Browser Settings
Setting Up your Computers Recommended Web Browser Settings In most cases, you will not need to make any changes to your web browser’s settings. If you are having trouble accessing the Internet or the advanced web-based user interface, then change your browser’s settings to the recommended settings in this section. - Page 22 Setting Up your Computers Make sure there are no check marks next to any of the displayed options: “Automatically detect settings”, “Use automatic configuration script”, and “Use a proxy server”. Click “OK”. Then click “OK” again in the “Internet Options” page. Netscape Navigator 4.0 or Higher Start Netscape.
-
Page 23: Configuring Your Router With The Setup Wizard
Configuring your Router with the Setup Wizard Running the Setup Wizard You can access the web-based management user interface of the Router using the Internet browser on a computer connected to the Router. Type “192.168.2.1” (do not type in anything else such as “http://”... - Page 24 Configuring your Router with the Setup Wizard A Status page will follow showing detail status of your Router. Next, click on the “Setup Wizard” button for express configuration (recommended). Click on the “Setup Wizard” button to start the Router’s Setup Wizard.
- Page 25 Configuring your Router with the Setup Wizard Now enter the required values provided by your ISP. For the “PPPoE” or “PPPoA” page you will see the following screen. Enter the required values provided by your ISP and click “Next”. Note: For more detailed instruction on other connection types, please refer to the “Manually Configuring your Router”...
-
Page 26: Connecting To The Wireless Lan
Congratulations! You have finished installing your new Belkin Router. To test your Internet connection, open your browser and visit any website, such as www.belkin.com. For advanced features and more detailed installation and security setup information, see the following section, “Manually Configuring... -
Page 27: Manually Configuring Your Router
Manually Configuring your Router Understanding the Web-Based User Interface The home page shows you a quick view of the Router’s status and settings. All advanced setup pages can be reached from this page. (10) Quick-Navigation Links You can go directly to any of the Router’s UI pages by clicking directly on these links. - Page 28 Manually Configuring your Router Manually Configuring your Router Configuring Your Router with the Setup Wizard take you to a separate login page where you will need to enter a password. When you are logged into the Router, you can make changes to the settings.
-
Page 29: Changing Lan Settings
Manually Configuring your Router Changing LAN Settings All settings for the internal LAN setup of the Router can be viewed and changed here. Clicking on the header of the LAN tab will take you to the LAN tab’s header page. A quick description of the functions can be found here. - Page 30 10.x.x.x (where x is anything between 0 and 255) Subnet Mask There is no need to change the subnet mask. This is a unique, advanced feature of your Belkin Router. DHCP Server The DHCP server function makes setting up a network very easy by assigning IP addresses to each computer on the network automatically.
- Page 31 IP address to change. Local Domain Name The default setting is “Belkin”. You can set a local domain name (network name) for your network. There is no need to change this setting unless you have a specific advanced need to do so. You can...
-
Page 32: Internet Wan
Manually Configuring your Router Manually Configuring your Router DHCP Client List You can view a list of the computers (known as clients), which are connected to your network. You are able to view the IP address the computer, the host name (if the computer has been assigned one), and the MAC address of the computer’s Network Interface... - Page 33 Manually Configuring your Router Connection Type From the “Connection Type” page, you can select one of these five connection types based on the instruction provided by your ISP: • PPPoE • PPPoA • Dynamic IP (1483 Bridged) • Static IP (IPOA) •...
-
Page 34: Setting Your Isp Connection Type To Pppoe Or Pppoa
Manually Configuring your Router Manually Configuring your Router Setting your ISP Connection Type to PPPoE or PPPoA PPPoE (Point-to-Point Protocol over Ethernet) is the standard method of connecting networked devices. It requires a user name and password to access the network of your ISP for connecting to the Internet. - Page 35 Manually Configuring your Router Setting your Connection Type to Dynamic IP (1483 Bridged) This connection method bridges your network and ISP’s network together. The Router will obtain an IP address automatically from your ISP’s DHCP server. 1. VPI/VCI - Enter your Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI) parameter here.
- Page 36 Manually Configuring your Router Manually Configuring your Router Setting your ISP Connection to Static IP (IPoA) This connection type is also called “Classical IP over ATM” or “CLIP”, which your ISP provides a fixed IP for your Router to connect to the Internet.
- Page 37 DNS (Domain Name Server) Settings A “Domain Name Server” is a server located on the Internet that translates Universal Resource Links (URLs) like “www.belkin.com” to IP addresses. Many ISPs do not require you to enter this information into the Router. The “Automatic from ISP” box should be checked if your ISP did not give you a specific DNS address.
-
Page 38: Wireless
Manually Configuring your Router Manually Configuring your Router Wireless The “Wireless” tab lets you make changes to the wireless network settings. From this tab, you can make changes to the wireless network name (SSID), operating channel, and encryption security settings. Channel and SSID 1. - Page 39 Manually Configuring your Router a change to the SSID, your wireless-equipped computers may also need to be reconfigured to connect to your new network name. Refer to the documentation of your wireless network adapter for information on making this change. 3.
- Page 40 Manually Configuring your Router Manually Configuring your Router these clients to be compatible with the newer 802.11g technology. Switching to this mode can solve problems that sometimes occur with these clients. If you suspect that you are using a client adapter that falls into this category, first check with the adapter vendor to see if there is a driver update.
- Page 41 Manually Configuring your Router Encryption/Security Securing your Wi-Fi Network Here are a few different ways you can maximize the security of your wireless network and protect your data from prying eyes and ears. This section is intended for the home, home office, and small office user.
- Page 42 Most of the new wireless equipment in the market today supports both 64-bit and 128-bit WEP encryption, but you might have older equipment that only supports 64-bit WEP. All Belkin wireless products will support both 64-bit and 128-bit WEP. Encryption Keys After selecting either the “64-bit”...
- Page 43 WPA (with radius server) With this system, a radius server distributes the Network key to the clients automatically. This is typically found in a business environment. For a list of Belkin wireless products that support WPA, please visit our website at www.belkin.com/networking.
- Page 44 Manually Configuring your Router Manually Configuring your Router Sharing the Same Network Keys Most Wi-Fi products ship with security turned off. So once you have your network working, you need to activate WEP or WPA and make sure your wireless networking devices are sharing the same Network key.
- Page 45 Manually Configuring your Router Using a Hexadecimal Key A hexadecimal key is a mixture of numbers and letters from A–F and 0–9. 64-bit keys are five two-digit numbers. 128-bit keys are 13 two-digit numbers. For instance: AF 0F 4B C3 D4 = 64-bit key C3 03 0F AF 0F 4B B2 C3 D4 4B C3 D4 E7 = 128-bit key...
- Page 46 Manually Configuring your Router Manually Configuring your Router WEP Setup 64-Bit WEP Encryption Select “64-bit WEP” from the drop-down menu. After selecting your WEP encryption mode, you can enter your key by typing in the hex key manually. A hex (hexadecimal) key is a mixture of numbers and letters from A–F and 0–9.
- Page 47 Manually Configuring your Router 128-Bit WEP Encryption Select “128-bit WEP” from the drop-down menu. After selecting your WEP encryption mode, you can enter your key manually by typing in the hex key manually. A hex (hexadecimal) key is a mixture of numbers and letters from A–F and 0–9.
- Page 48 Manual’s publication, a security patch download is available free from Microsoft. This patch works only with the Windows XP operating system. You also need to download the latest driver for your Belkin Wireless G Desktop or Notebook Network Card from the Belkin support site.
- Page 49 Manually Configuring your Router Setting WPA-PSK (no server) From the “Security Mode” drop-down menu, select “WPA-PSK (no server)”. For Encryption Technique, select “TKIP” or “AES”. This setting will have to be identical on the clients that you set up. Enter your Pre-Shared key. This can be from eight to 63 characters and can be letters, numbers, or symbols.
- Page 50 Please Note: This section provides information on how to configure your Belkin Wireless G Network Cards to use security. At this point, you should already have your Wireless Router or access point set to use WPA or WEP. In order for you to gain a wireless connection, you will need to set your wireless notebook card and wireless desktop card to use the same security settings.
- Page 51 Manually Configuring your Router Connecting your Computer to a Wireless Network that Requires a 64-Bit or 128-Bit WEP Key Double-click the “Signal Indicator” icon to bring up the “Wireless Network” screen. The “Advanced” button will allow you to view and configure more options of your wireless card. Under the “Wireless Network Properties”...
- Page 52 Manually Configuring your Router Manually Configuring your Router Connecting your Computer to a Wireless Network that Requires WPA-PSK (no server) Double-click the “Signal Indicator” icon to bring up the “Wireless Network” screen. The “Advanced” button will allow you to view and configure more options of your wireless card.
- Page 53 Under the “Authentication” tab, select the settings that are indicated by your network administrator. Click “OK” to save the settings. Setting Up WPA for a Non-Belkin Wireless Desktop and Wireless Notebook Cards For non-Belkin WPA Wireless Desktop and Wireless Notebook Cards that are not equipped with WPA-enabled software, a file from Microsoft called “Windows XP Support Patch for Wireless Protected...
- Page 54 Manually Configuring your Router Manually Configuring your Router Important: You also need to ensure that the wireless card manufacturer supports WPA and that you have downloaded and installed the latest driver from their support site. Supported Operating Systems: • Windows XP Professional •...
- Page 55 Manually Configuring your Router Under the “Wireless Networks” tab, click the “Configure” button, and you will see the following screen. For a home or small business user, select “WPA-PSK” under “Network Authentication”. Note: Select “WPA” if you are using this computer to connect to a corporate network that supports an authentication server such as a radius server.
-
Page 56: Firewall
Manually Configuring your Router Manually Configuring your Router Firewall Your Router is equipped with a firewall that will protect your network from a wide array of common hacker attacks including: • IP Spoofing • Land Attack • Ping of Death (PoD) •... - Page 57 Manually Configuring your Router Virtual Servers Virtual servers allow you to route external (Internet) calls for services such as a web server (port 80), FTP server (Port 21), or other applications, through your Router to your internal network. Since your internal computers are protected by a firewall, machines from the Internet cannot get to them because they cannot be “seen”.
- Page 58 Manually Configuring your Router Manually Configuring your Router Client IP Filters The Router can be configured to restrict access to the Internet, email, or other network services at specific days and times. Restriction can be set for a single computer, a range of computers, or multiple computers. To restrict Internet access to a single computer for example, enter a name of the filter in “Filter Name”...
- Page 59 Manually Configuring your Router DMZ (Demilitarized Zone) If you have a client PC that cannot run an Internet application properly from behind the firewall, you can open the client up to unrestricted two-way Internet access. This may be necessary if the NAT feature is causing problems with an application such as a game or video conferencing application.
-
Page 60: Utilities
Manually Configuring your Router Manually Configuring your Router Utilities The “Utilities” screen lets you manage different parameters of the Router and perform certain administrative functions. Restart Router Sometimes it may be necessary to restart or reboot the Router if it begins working improperly. - Page 61 Manually Configuring your Router Restarting the Router to Restore Normal Operation Click the “Restart Router” button. The following message will appear. Click “OK” to restart your Router. Restore Factory Defaults Using this option will restore all of the settings in the Router to the factory (default) settings.
- Page 62 Manually Configuring your Router Manually Configuring your Router Saving/Backup Current Settings You can save your current configuration by using this feature. Saving your configuration will allow you to restore it later if your settings are lost or changed. It is recommended that you back up your current configuration before performing a firmware update.
- Page 63 Manually Configuring your Router When the save is complete, you will see the window below. Click “Close”. The configuration is now saved. Restore Previous Settings This option will allow you to restore a previously saved configuration. Click “Browse”. A window will open that allows you to select the location of the configuration file.
- Page 64 Manually Configuring your Router Manually Configuring your Router Firmware Update From time to time, Belkin may release new versions of the Router’s firmware. Firmware updates contain feature improvements and fixes to problems that may have existed. When Belkin releases new firmware, you can download the firmware from the Belkin update website and update your Router’s firmware to the latest version.
- Page 65 Manually Configuring your Router System Settings The “System Settings” page is where you can enter a new administrator password, set the time zone, enable remote management, and turn on and off the UPnP function of the Router. Setting or Changing the Administrator Password The Router ships with NO password entered.
- Page 66 Internet and get a response. You cannot set the clock yourself. Enabling Remote Management Before you enable this advanced feature of your Belkin Router, MAKE SURE YOU HAVE SET THE ADMINISTRATOR PASSWORD. Remote management allows you to make changes to your Router’s settings from anywhere on the Internet.
- Page 67 Click on the “Apply Changes” button to save your settings. Enabling/Disabling UPnP UPnP (Universal Plug-and-Play) is yet another advanced feature offered by your Belkin Router. It is a technology that offers seamless operation of voice messaging, video messaging, games, and other applications that are UPnP-compliant. Some applications require the Router’s firewall to be configured in a specific way to operate...
-
Page 68: Troubleshooting
Troubleshooting Problem: The ADSL LED is not on. Solution: Check the connection between the Router and ADSL line. Make sure the cable from the ADSL line is connected to the port on the Router labeled “DSL Line”. Make sure the Router has power. The Power LED on the front panel should be illuminated. - Page 69 Solution: If you are unable to connect to the Internet from a wireless computer, please check the following items: Look at the lights on your Router. If you are using a Belkin Router, the lights should be as follows: •...
- Page 70 Troubleshooting Does the name of your wireless network appear in the results? Yes, my network name is listed—go to the troubleshooting solution titled “I can’t connect to the Internet wirelessly, but my network name is listed”. No, my network name is not listed—go to the troubleshooting solution titled “I can’t connect to the Internet wirelessly, and my network name is not listed”.
- Page 71 This setting is found on the Router’s wireless “Channel and SSID” configuration page. If you are still unable to access the Internet after completing these steps, please contact Belkin Technical Support. Problem: My wireless network performance is inconsistent. Data transfer is sometimes slow.
- Page 72 Problem: I am having difficulty setting up Wired Equivalent Privacy (WEP) security on a Belkin Router or Belkin Access Point. Solution Log into your Wireless Router or access point. Open your web browser and type in IP address of the Wireless Router or access point.
- Page 73 The “Advanced” button will allow you to view and configure more options of the Card. Once the “Advanced” button is clicked, the Belkin Wireless LAN Utility will appear. This Utility will allow you to manage all the advanced features of the Belkin Wireless Card.
- Page 74 C3 03 0F AF 4B B2 C3 D4 4B C3 D4 E7 E4 = 128-bit key Click “OK”, and then “Apply” to save the settings. If you are NOT using a Belkin Wireless Card, please consult the manufacturer for that wireless client card’s user manual.
- Page 75 Troubleshooting Problem: I am having difficulty setting up Wi-Fi Protected Access (WPA) security on a Belkin Wireless Router or Belkin Access Point for a home network. Solution: From the “Security Mode” drop-down menu, select “WPA-PSK (no server)”. For “Encryption Technique”, select “TKIP” or “AES”. This setting will have to be identical on the clients that you set up.
- Page 76 Troubleshooting Problem: I am having difficulty setting up Wi-Fi Protected Access (WPA) security on a Belkin Wireless Card for a home network. Solution: Clients must use the same key that the wireless router or access point uses. For instance if the key is “Smith Family Network Key” in the wireless router or access point, the clients must also use that same key.
- Page 77 Click “OK, then “Apply” to save the settings. Problem: I am having difficulty setting up Wi-Fi Protected Access (WPA) security and I am NOT using a Belkin Wireless Card for a home network. Solution: If you are NOT using a Belkin Wireless Desktop or Wireless Notebook Network Card and it is not equipped with WPA-enabled software, a file from Microsoft called “Windows XP Support Patch...
- Page 78 Troubleshooting Under the “Wireless Networks” tab, click the “Configure” button, and you will see the following screen. For a home or small business user, select “WPA-PSK” under “Network Administration”. Note: Select WPA (with radius server) if you are using this computer to connect to a corporate network that supports an authentication server such as a radius server.
- Page 79 Troubleshooting Wireless Comparison Chart Speed 11Mbps 54Mbps 54Mbps 108Mbps Common Common Common household household household devices such as devices such as devices such as cordless phones cordless phones 5GHz - cordless phones and microwave and microwave uncrowded and microwave ovens may ovens may band ovens may...
-
Page 80: Technical Support Information
Technical Support Information Technical Support For latest software updates or if you have any further questions regarding installation of this product, please visit www.belkin.com/networking or contact: 877-736-5771 or 310-898-1100 ext. 2263 Europe: 00 800 223 55 460 Australia: 1800 235 546... -
Page 81: Appendixes
DNS is an acronym for Domain Name Server. A Domain Name Server is a server located on the Internet that translates URLs (Universal Resource Links) like www.belkin.com to IP addresses. Many ISPs do not require you to enter this information into the Router. If you... - Page 82 Appendixes You have to double-click on a desktop icon other than your browser to get on the Internet. To set the Router to use PPPoE, type in your user name and password in the spaces provided. After you have typed in your information, click “Apply Changes”.
- Page 83 This occurs if the computer’s SSID is set to “ANY”. Your Belkin Router can block this random search for a network. If you disable the “ESSID Broadcast” feature, the only way a computer can join your network is by its SSID being set to the specific name of the network (like WLAN).
- Page 84 Appendixes Client IP Filters The Router can be configured to restrict access to the Internet, email, or other network services at specific days and times. Restriction can be set for a single computer, a range of computers, or multiple computers. URL Blocking To configure the URL blocking feature, specify the websites (www.
- Page 85 Appendixes NAT feature is causing problems with an application such as a game or video conferencing application. Use this feature on a temporary basis. The computer in the DMZ is not protected from hacker attacks. To put a computer in the DMZ, enter the last digits of its LAN IP address in the “Static IP”...
- Page 86 Appendixes immediately. Allow at least 15 minutes for the Router to contact the time servers on the Internet and get a response. You cannot set the clock yourself. Remote Management Before you enable this function, MAKE SURE YOU HAVE SET THE ADMINISTRATOR PASSWORD.
-
Page 87: Appendix B: Important Factors For Placement And Setup
To achieve the best wireless network coverage for your “wireless clients” (i.e., computers enabled by Belkin Wireless Notebook Network Cards, Wireless Desktop Network Cards, and Wireless USB Adapters): •... - Page 88 Experiment with more than one of the available channels, in order to find the clearest connection and avoid interference from neighboring cordless phones or other wireless devices. For Belkin wireless networking products, use the detailed Site Survey and wireless channel information included in your User Manual.
-
Page 89: Appendix C: Internet Connection Setting Table
These guidelines should allow you to cover the maximum possible area with your Wireless Router (or access point). Should you need to cover an even wider area, we suggest the Belkin Wireless Range Extender/Access Point. 5. Secure Connections, VPNs, and AOL Secure connections typically require a user name and password, and are used where security is important. - Page 90 Appendixes Country Connection VPI/VCI Encapsulation ISPs Protocol Europe France PPPoE 8/35 Various Germany PPPoE 1/32 T-Online, various Holland 1483 0/35 BBNed, XS4all Bridged 0/32 Versatel DHCP 0/34 Baby XL, Tiscali (start/ Surf/ Family/ Live) PPPoA 8/48 VC MUX KPN, Hetnet, HCCNet, Tiscali (lite/ Basis/Plus)
-
Page 91: Information
Information FCC Statement DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC COMPATIBILITY We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under our sole responsibility that the product, F5D7633-4 to which this declaration relates, complies with Part 15 of the FCC Rules. Operation is... - Page 92 Modifications The FCC requires the user to be notified that any changes or modifications to this device that are not expressly approved by Belkin Corporation may void the user’s authority to operate the equipment. Canada-Industry Canada (IC) The wireless radio of this device complies with RSS 139 &...
- Page 93 Belkin Corporation Limited Lifetime Product Warranty Belkin Corporation warrants this product against defects in materials and workmanship for its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product.
- Page 94 Belkin Tech Support Europe: 00 800 223 55 460 © 2004 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Apple, AirPort, Mac, Mac OS, and AppleTalk are trade- marks of Apple Computer, Inc., registered in the U.S. and other countries. The mark “Wi-Fi”...
