Components
Components
Main unit components
Main unit x 1
1
Bezel
5
x 1
Bushing
9
x 1
*
Tip
When installing the main unit, some vehicle models may require the use of items that need to be
obtained separately such as a power supply adaptor cable, radio antenna adaptor cable or mounting
bracket.
Check that all of the following components are present
Check that all of the following components are present
Interconnecting cable
2
(Power and speaker connector)
(16P) x 1
Hex-head bolt
6
(Red:M5x8) x 4
Case
10
(For detachable panel)x 1
- 2 -
Mounting sleeve
3
x 1
Flat head screw
7
(Red:M5x8) x 4
Remote control
11
*
(Only included with CD8445E) x 1
Side bracket
4
x 2
Stud bolt
8
x 1
