AMX AXCENT3 AND AXCENT3 PRO INTEGRATED AXCESS SYSTEM Instruction Manual page 6

Product Information
Specifications (Cont.)
Rear Panel Components:
RS-232/RS-422/RS-485
ports
Status indicators
AXlink indicator
AXlink/PWR connector
RELAYS connector
IR/SERIAL/DATA
connectors
Input/Output connectors
PROGRAM port
Slots 1 - 4
Included Accessories:
Optional Accessories:
2
Six 9-pin (male) D-sub, RS-232/422/485 XON/XOFF, CTS/RTS, 300, 200 baud
32 red LEDs that show RS-232/422/485, relay, IR/Serial/Data, and I/O port
activity. The LEDs light when data activity occurs on the associated ports.
Green LED showing power and AXlink data activity.
4-pin connector for AXlink data and power, and 2-pin connector for external
12 VDC power supply
Two 8-pin connectors, 750 mA, 28 VAC/24 VDC (normally open)
12-pin (6 two-pins) male connector that supports IR, IR/Serial or one-way data
communication (0 - 5 VDC levels only)
8-pin connector, I/O 1 - 6, Common, +12 VDC power tap 200 mA, contact
closure or TTL logic inputs
DB-9 (male) connector for system programming and diagnostics
Four 16-pin connectors for Axcess Control Cards (Axcent
• 4 CC-IRC emitters
• Metal tab strip for commoning relays
• Rack-mount brackets
• 12 VDC power supply
• CSB Cable Support Bracket
• AC-RK3 Rack Kit
• Axcess Control Cards (Axcent
3
Axcent
3
Pro only)
3
Pro only)
3
and Axcent Pro Integrated Axcess Controllers
