Console Port - Cisco 3845 - Security Bundle Router Quick Start Manual

entered, becomes encrypted in the configuration.
Enter enable secret: xxxxxx
Step 5 Enter an enable password that is different from the enable secret password. This password is not encrypted (less secure)
and can be seen when you view the configuration.
The enable password is used when you do not specify an
enable secret password, with some older software versions, and
some boot images.
Enter enable password: xxxxxx
Step 6 Enter the virtual terminal password, which prevents unauthenticated access to the router through ports other than the

console port:

The virtual terminal password is used to protect
access to the router over a network interface.
Enter virtual terminal password: xxxxxx
Step 7 Respond to the following prompts as appropriate for your network:
Configure SNMP Network Management? [yes]:
Community string [public]:
A summary of the available interfaces appears.
Note The interface numbering that appears is dependent on the type of Cisco modular router platform and on the
installed interface modules and cards.
Current interface summary
Controller Timeslots D-Channel Configurable modes Status
T1 0/0/0 24
T1 0/0/1 24
T1 0/2/0 24
T1 0/2/1 24
Any interface listed with OK? value "NO" does not have a valid configuration
Interface
GigabitEthernet0/0
GigabitEthernet0/1
Step 8 Choose one of the available interfaces for connecting the router to the management network:
Enter interface name used to connect to the
management network from the above interface summary: gigabitethernet0/0
Respond to the following prompts as appropriate for your network:
Step 9
Configuring interface GigabitEthernet0/0:
Use the 100 Base-TX (RJ-45) connector? [yes]: yes
Operate in full-duplex mode? [no]: no
Configure IP on this interface? [yes]: yes
IP address for this interface: 172.1.2.3
Subnet mask for this interface [255.255.0.0] : 255.255.0.0
Class B network is 172.1.0.0, 16 subnet bits; mask is /16
The configuration is displayed:
The following configuration command script was created:
hostname Router
enable secret 5 $1$D5P6$PYx41/lQIASK.HcSbfO5q1
enable password xxxxxx
line vty 0 4
password xxxxxx
snmp-server community public
!
32
23 pri/channelized
23 pri/channelized
23 pri/channelized
23 pri/channelized
IP-Address OK? Method Status
20.0.0.40 YES DHCP
unassigned NO
Administratively up
Administratively up
Administratively up
Administratively up
up
unset up
Protocol
up
up
