PRE-OPERATING INSTRUCTIONS
1. Pull back the front grill as illustrated. (Figure 2)
2. Remove the filter from the unit. Remove scented
electric gel cartridge from unit. Slowly remove
peelable label from gel cartridge using peel tab. Do
not remove or puncture clear film protecting gel
concentrate. The film controls the release of
concentrated freshening ingredients.
3. Return cartridge to unit with soft flexible side
facing out. (Figure 3)
4. Remove new filter from plastic bag before placing
the filter into the unit. Place the filter in the
alotted area.
5. Close the filter grill and make sure the door snaps
into a locked position.
6. Turn the scent cartridge reminder dial ahead
one month for heavy use and two months for
light use. (figure 4)
7. Place the unit in the lower plug of the outlet
on the wall.
8. Turn unit to desired speed setting. We recommend
low for continuous use and high for increased
odor removal.
Figure 2
Figure 3
Figure 4
