The award-winning Wavefront W8C 3-Way System is a very compact, light weight,
high performance 3-way loudspeaker system in a trapezoidal cabinet. The Wavefront
W8C integrates a horn-loaded 12" low-mid driver with a horn-loaded 6.5" high-mid
driver and a horn-loaded 1" very high frequency compression driver. The 6.5" high-
mid cone driver provides a whole order better performance than a large compression
driver and is optimally loaded using a toroidal phase plug.
Wavefront series trapezoidal cabinets are fitted with MAN load-certified flying points
and are designed to comply with the 12:1 safety factor specified by the German
VBG70 standard when used with compatible 12:1 flying systems. One important
advantage of the MAN flying system is that inter-cabinet connections place a minimal
load on the cabinets and, being external, can be load certified and inspected
independently.

1.2 Specifications

Type:
Frequency response:
LF limit:
Drivers:
Rated power:
Sensitivity:
MARTIN AUDIO - APPLICATIONS GUIDE, WAVEFRONT COMPACT SERIES
ENGLISH ONLY
Wavefront W8C 3-Way System
All material © 2007. Martin Audio Ltd. Subject to change without notice.
3-way trapezoid, switchable active/passive
high-mid/high via rear panel
switch (see Section 1.5)
120Hz - 18kHz +/- 3dB
-10dB @ 100Hz
1 x 12" (305mm) low-mid horn
1 x 6.5" (165mm) high-mid horn
1 x 1" (25mm) exit hf compression driver
Low-mid 300W AES, 1200Wpk
High-mid (active/passive) 150W AES, 600Wpk
High (active) 60W AES, 240Wpk
Low-mid 106dB/W
High-mid 108dB/W
High 107dB/W
