AV SURROUND RECEIVER
AVR-3803/1083

OPERATING INSTRUCTIONS

We greatly appreciate your purchase of the AVR-3803/1083.
2
To be sure you take maximum advantage of all the features the AVR-3803/1083 has to offer, read these
2
instructions carefully and use the set properly. Be sure to keep this manual for future reference, should any
questions or problems arise.
"SERIAL NO.
PLEASE RECORD UNIT SERIAL NUMBER ATTACHED TO THE REAR OF THE
CABINET FOR FUTURE REFERENCE"
REMOTE
SIGNAL
SURROUND
SENSOR
BACK CH
DIGITAL
OUTPUT
INPUT
SIGNAL
ON / STANDBY
AUTO
PCM
DTS
DETECT
VOLUME LEVEL
AMP

Advertisement

Table of Contents
loading

Summary of Contents for Denon 1083

  • Page 1: Operating Instructions

    We greatly appreciate your purchase of the AVR-3803/1083. To be sure you take maximum advantage of all the features the AVR-3803/1083 has to offer, read these instructions carefully and use the set properly. Be sure to keep this manual for future reference, should any questions or problems arise.
  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE.
  • Page 3: R6P/Aa Batteries

    SAFETY INSTRUCTIONS Read Instructions – All the safety and operating instructions should be read before the product is operated. Retain Instructions – The safety and operating instructions should be retained for future reference. Heed Warnings – All warnings on the product and in the operating instructions should be adhered to.
  • Page 4: Table Of Contents

    INTRODUCTION Thank you for choosing the DENON AVR-3803/1083 Digital A / V Surround Receiver. This remarkable component has been engineered to provide superb surround sound listening with home theater sources such as DVD, as well as providing outstanding high fidelity reproduction of your favorite music sources.
  • Page 5: Cautions On Handling

    The AVR-3803/1083 can be decoded with DTS-ES Extended Surround, a new multi-channel format developed by Digital Theater Systems Inc. The AVR-3803/1083 can be also decoded with DTS Neo:6, a surround mode allowing 6.1-channel playback of regular stereo sources. 6. DTS 96/24 compatibility...
  • Page 6: Connections

    Connecting a turntable (MM cartridge) Connect the turntable’s output cord to the AVR- 3803/1083’s PHONO jacks, the L (left) plug to the L jack, the R (right) plug to the right jack. NOTE: This unit cannot be used with MC cartridges directly.
  • Page 7 • When making connections, also refer to the operating instructions of the other components. • The AVR-3803/1083 is equipped with a function for up-converting video signals. • The signal connected to the video signal terminal is output to the S-Video and component video monitor out terminals.
  • Page 8 The input selectors for the S inputs and Video inputs work in conjunction with each other. • The AVR-3803/1083 is equipped with a function for converting video signals. • The signal connected to the S-Video signal terminal is output to the composite video and component video monitor out terminals.
  • Page 9 When the component video terminals are used to connect the AVR-3803/1083 with a TV (or monitor, projector, etc.) and the video (yellow) or S video terminals are used to connect the AVR-3803/1083 with a VTR, depending on the combination of the TV and VTR the picture may flicker in the horizontal direction, be distorted, be out of sync or not display at all when playing video tapes.
  • Page 10: Connecting The Antenna Terminals

    Connecting the antenna terminals DIRECTION OF BROADCASTING STATION FM ANTENNA /ohms COAXIAL CABLE FM INDOOR ANTENNA (Supplied) • An F-type FM antenna cable plug can be connected directly. AM loop antenna assembly Connect to the AM antenna terminals. Remove the vinyl tie Bend in the reverse and take out the direction.
  • Page 11 Connecting the external input (EXT. IN) jacks • These jacks are for inputting multi-channel audio signals from an outboard decoder, or a component with a different type of multi-channel decoder, such as a DVD Audio player, a multi-channel SACD player, or other future multi-channel sound format decoder. •...
  • Page 12 Speaker system connections • Connect the speaker terminals with the speakers making sure that like polarities are matched (≈ with ≈ , √ with √ ). Mismatching of polarities will result in weak central sound, unclear orientation of the various instruments, and the sense of direction of the stereo being impaired.
  • Page 13 If the protection circuit is activated again even though there are no problems with the wiring or the ventilation around the unit, switch off the power and contact a DENON service center. • The protector circuit may be activated if the set is played for long periods of time at high volumes when speakers with an impedance lower than the specified impedance (for example speakers with an impedance of lower than 4 connected.
  • Page 14: Part Names And Functions

    6 PART NAMES AND FUNCTIONS Front Panel • For details on the functions of these parts, refer to the pages given in parentheses ( ). Power ON/STANDBY switch...(47, 70) Headphones jack (PHONES) ...(51) VIDEO SELECT button ...(51) Surround speaker system indicators (SURROUND SPEAKER A/B) PURE DIRECT button/indicator ...(50, 70) ZONE 2 button/indicator...(53, 70)
  • Page 15 Remote control unit • For details on the functions of these parts, refer to the pages given in parentheses ( ). ZONE 2 buttons ...(53) Mode selector buttons ...(35, 37, 47, 53) Input source selector buttons ...(35~38, 48, 59, 61, 68) BACK LIGHT button System buttons...(35, 37, 38) SYSTEM SETUP/SETUP...
  • Page 16: Setting Up The System

    • Once all connections with other AV components have been completed as described in “CONNECTIONS” (see pages 6 to 13), make the various settings described below on the monitor screen using the AVR-3803/1083’s on-screen display function. These settings are required to set up the listening room’s AV system centered around the AVR-3803/1083. • Use the following buttons to set up the system: •...
  • Page 17 S-VIDEO MONITOR OUT jack. (For details, see page 33.) • The AVR-3803/1083’s on-screen display function is designed for use with high resolution monitor TVs, so it may be difficult to read small characters on TVs with small screens or low resolutions.
  • Page 18 Before setting up the system Check that all the connections are correct, then turn on the main unit’s power. Display the System Setup Menu. Setting the type of speakers • The composition of the signals output to the different channels and the frequency response are adjusted automatically according to the combination of speakers actually being used.
  • Page 19 • Parameters Large...Select this when using speakers that have sufficient performance for reproducing bass sound below the frequency set for the Crossover Frequency mode. Small...Select this when using speakers that do not have sufficient performance for reproducing bass sound below the frequency set for the Crossover Frequency mode.
  • Page 20 Select the “Subwoofer Mode”. Select the setting. Enter the setting. The System Setup Menu reappears. NOTES: — Assignment of low frequency signal range — • The only signals produced from the subwoofer channel are LFE signals (during playback of Dolby Digital or DTS signals) and the low frequency signal range of channels set to “SMALL”...
  • Page 21: Setting The Delay Time

    Setting the Delay Time • Input the distance between the listening position and the different speakers to set the delay time for the surround mode. • The delay time can be set separately for surround speakers A and B. Preparations: Measure the distances between the listening position and the speakers (L1 to L5 on the diagram at the right).
  • Page 22: Setting The Channel Level

    Enter the setting. The System Setup Menu reappears. The AVR-3803/1083 automatically sets the optimum surround delay time for the listening room. NOTE: • If the distance unit is changed after the delay time is set, the settings are reset to the factory default values (see page 16, 17).
  • Page 23 Select the mode. Select “Auto” or “Manual”. • Auto: Adjust the level while listening to the test tones produced automatically from the different speakers. • Manual: Select the speaker from which you want to produce the test tone to adjust the level. Select “Test Tone Start”.
  • Page 24: Setting The Digital In Assignment

    “A or B” and “A and B”. Setting the Digital In Assignment • This setting assigns the digital input jacks of the AVR-3803/1083 for the different input sources. At the System Setup Menu select “Digital In Assignment”.
  • Page 25 CD recorder, MD recorder or other digital recorder. Use this for digital recording between a digital audio source (stereo - 2 channel) and a digital audio recorder. • Do not connect the output of the component connected to the OPTICAL 4 OUT jack on the AVR-3803/1083’s rear panel to any jack other than the OPTICAL 4 IN jack.
  • Page 26 When the component video terminals are used to connect the AVR-3803/1083 with a TV (or monitor, projector, etc.) and the video (yellow) or S video terminals are used to connect the AVR-3803/1083 with a VTR, depending on the combination of the TV and VTR the picture may flicker in the horizontal direction, be distorted, be out of sync or not display at all when playing video tapes.
  • Page 27 Setting the Dolby Digital Setup Sets the down-mixing method when not using a center speaker or surround speakers. OFF: The dynamic range is not compressed. The dynamic range is compressed automatically according to the combination of speakers being used. Select “ON” if you want to use the Dolby Digital Down-mix, “OFF” if you do not want to use it.
  • Page 28: Setting The Audio Delay

    Enter the setting. At the “Zone2 Control” screen, select “Exit” and press the ENTER button. The System Setup Menu reappears. [2] Setting the Zone2 vol. level Set the Zone 2 pre-out output level adjustment. Select the desired settimg. Variable: The level can be adjusted freely using the buttons on the remote control unit.
  • Page 29: Setting The Auto Surround Mode

    Setting the Ext. In Subwoofer Level • Set the method of playback of the analog input signal connected to the Ext.In Subwoofer. At the System Setup Menu select “Ext.In Subwoofer Level”. Switch to the Ext.In Subwoofer Level screen. Select the desired setting. Select according to the specifications of the player being used.
  • Page 30 Select “ON” if you want to use the auto surround mode, “OFF” if you do not want to use it. Enter the setting. The System Setup Menu reappears. Setting the On Screen Display (OSD) • Use this to turn the on-screen display (messages other than the menu screens) on or off. •...
  • Page 31 Setting the Trigger Out Setup • Sets the Trigger Out output for the different input sources. At the System Setup Menu select “Trigger Out Setup”. Switch to the Trigger Out Setup screen. Enter the setting. The System Setup Menu reappears. Auto Tuner Presets Use this to automatically search for FM broadcasts and store up to 40 stations at preset channels A1 to 8, B1 to 8, C1 to 8, D1 to 8 and E1 to 8.
  • Page 32 Use the CURSOR button to select “Yes”. “Search” flashes on the screen and searching begins. “Completed” appears once searching is completed. The display automatically switches to screen. This completes system setup. Once these settings are made, there is no need to change them unless different AV components are connected or the speakers are repositioned.
  • Page 33 This button can be pressed at any time during the system setup process to complete the process. At the System Setup Menu, press the SYSTEM SETUP button. The changed settings are entered and the on-screen display turns off. • On-screen display signals Signals input to the AVR-3803/1083 VIDEO signal input jack S-video signal input jack (yellow)
  • Page 34: Remote Control Unit

    • The included remote control unit (RC-921) can be used to operate not only the AVR-3803/1083 but other remote control compatible DENON components as well. In addition, the memory contains the control signals for other remote control units, so it can be used to operate non-Denon remote control compatible products.
  • Page 35: Operating Denon Audio Components

    Operating DENON audio components Use the mode selector buttons to select the component you want to operate. The function switches as shown below each time one of the mode buttons is pressed. AMP/ZONE2 : AMP, ZONE2 CDR/MD : CDR,MD DBS/CABLE...
  • Page 36: Preset Memory

    This setting can be canceled by resetting the preset memory or registering another preset signal. The preset codes are as follows upon shipment from the factory and after resetting: TV, VCR1 ...HITACHI CD, MD, TAPE, CDR, VDP, DVD...DENON VCR2, DBS...SONY CABLE...ABC “OK”...
  • Page 37: Operating A Component Stored In The Preset Memory

    Operating a component stored in the preset memory Press the mode selector button for the component you want to operate. NOTE: • For the DVD player remote control buttons, function names may differ according to manufacturer. Compare with the remote control operation of the various components.
  • Page 38 3. Video deck (VCR-1/VCR-2) system buttons POWER : Power on/standby (ON/SOURCE) : Manual search (forward and reverse) : Stop : Play : Pause Channel +, – : Channels 4. Monitor TV (TV), digital broadcast satellite (DBS) tuner and cable (CABLE) system VCR1 buttons POWER...
  • Page 39: Learning Function

    Learning function If your AV component is not a Denon product or if it cannot be operated using the preset memory, it can be controlled with the accessorious remote control unit by storing its remote control signals in the remote control unit.
  • Page 40 System call The accessorious remote control unit is equipped with “system call” function allowing a series of remote control signals to be transmitted by pressing a single button. This function can be used for example to turn on the amplifier’s power, select the input source, turn on the monitor TV’s power, turn on the source component’s power and set the source to the play mode, all at a signal button.
  • Page 41: Punch Through

    NOTES: • The remote control signals of the buttons pressed while registering the system call signals are emitted, so be careful not to operate the components accidentally (cover the remote sensors, for example). • If you exceed the number of signals that can be registered, “FULL” appears on the remote control unit’s display and only the number of signals that can be registered are registered (up to 10 operations).
  • Page 42 Setting the back light’s lighting time Press the power ON/SOURCE button and the OFF button at the same time. • “PRE” appears on the remote control unit’s display. Use the • and ª cursor buttons to display “BKLT” on the remote control unit, then press the ENTER button.
  • Page 43 Use the • and ª cursor buttons to display “PRE” on the remote control unit, then press the ENTER button. • After “SEL” is displayed on the remote control unit’s display, the registered preset memory is displayed on the remote control unit’s display. Use the •...
  • Page 44 (3) Resetting the system call buttons Press the power ON/SOURCE button and the OFF button at the same time. • “PRE” appears on the remote control unit’s display. Use the • and ª cursor buttons to display “RST” on the remote control unit, then press the ENTER button.
  • Page 45 (4) Resetting the punch through setting Press the power ON/SOURCE button and the OFF button at the same time. • “PRE” appears on the remote control unit’s display. Use the • and ª cursor buttons to display “RST” on the remote control unit, then press the ENTER button.
  • Page 46 (5) All reset function • This function is for resetting all the settings to the factory defaults. Press the power ON/SOURCE button and the OFF button at the same time. “PRE” appears on the remote control unit’s display. Use the • and ª cursor buttons to display “RST” on the remote control unit, then press the ENTER button.
  • Page 47: Operation

    9 OPERATION Before operating Refer to “CONNECTIONS” (pages 6 to 13) and check that all connections are correct. Select “AMP” using the AMP button. (only when operating with the remote control unit) (Remote control unit) Turn on the power. Press the POWER switch (button). (Main unit) (Remote control unit) When pressed, the power turns on and the display lights.
  • Page 48 In this mode, the types of signals being input to the digital and analog input jacks for the selected input source are detected and the program in the AVR-3803/1083’s surround decoder is selected automatically upon playback. This mode can be selected for all input sources other than PHONO and TUNER.
  • Page 49 Select the play mode. Example: Stereo SELECT (Main unit) To select the surround mode while adjusting the surround parameters, channel volume or tone control, press the surround mode button then operate the selector. (Main unit) Start playback on the selected component. •...
  • Page 50 5/7CH STEREO, WIDE SCREEN or DSP SIMULATION) cannot be set. Playing audio sources (CDs and DVDs) The AVR-3803/1083 is equipped with three 2-channel playback modes exclusively for music. Select the mode to suit your tastes. PURE DIRECT mode In this mode, the music is played with an extremely high level of sound quality.
  • Page 51 After starting playback [1] Adjusting the sound quality (TONE) The tone control function will not work in the direct mode. The tone switches as follows each time the TONE CONTROL button is pressed. BASS (Main unit) With the name of the volume to be adjusted selected, turn the SELECT knob to adjust the level.
  • Page 52 [5] Checking the currently playing program source, etc. On screen display • Each time an operation is performed, a description of that operation appears on the display connected to the unit’s VIDEO MONITOR OUT jack. Also, the unit’s operating status can be checked during playback by pressing the remote control unit’s ON SCREEN/DISPLAY button.
  • Page 53 [2] Outputting a program source to an amplifier, etc., in a different room (ZONE2 mode) Press the ZONE2 button. Press the ZONE2/REC button. The display switches as follows each time the button is pressed. With “ZONE2 SOURCE” displayed, turn the FUNCTION knob and select the source you wish to output.
  • Page 54 Back Speaker OUT cannot be used for MAIN ZONE. (See page 27.) • When a sold separately room-to-room remote control unit (DENON RC-616, 617 or 618) is wired and connected between the MAIN ZONE and ZONE 2, the remote-controllable devices in the main zone can be controlled from ZONE 2 using the remote control unit.
  • Page 55: Surround

    10 SURROUND Before playing with the surround function • Before playing with the surround function, be sure to use the test tones to adjust the playback level from the different speakers. This adjustment can be performed with the system setup (see page 22) or from the remote control unit, as described below. •...
  • Page 56 Fader function • This function makes it possible to lower the volume of the front channels (FL, C and FR) or the rear channels (SL, SR, SBL and SBR) together. Use it for example to adjust the balance of the sound from the different positions when playing multi-channel music sources. Select “FADER”.
  • Page 57 SURR. PARA. button to finish. NOTE: • There are four Dolby Surround Pro Logic modes (NORMAL, PHANTOM, WIDE and 3 STEREO). The AVR-3803/1083 sets the mode automatically according to the types of speakers set during the system setup process (page 18).
  • Page 58 DTS NEO:6 mode • Surround playback can be performed for the analog input and PCM digital input 2-channel signals. Select the DTS NEO:6 mode. SELECT (Main unit) Play a program source. Set the surround parameter mode. (Main unit) Select the play mode. SELECT (Main unit) Display...
  • Page 59 Dolby Digital mode (only with digital input) and DTS Surround mode (only with digital input) Select the input source. Playback with a digital input q Select an input source set to digital (COAXIAL/OPTICAL) (see page 24). FUNCTION (Main unit) w Set the input mode to “AUTO” or “DTS”. (Main unit) Select the Dolby/DTS Surround mode.
  • Page 60 (Main unit) (Remote control unit) NOTE: The display on the screen differs depending on whether you are performing the operation from the main unit or the remote control unit. Select the various parameters. (Main unit) (Remote control unit) Dialogue Normalization The dialogue normalization function is activated automatically when playing Dolby Digital program sources.
  • Page 61: Adjusting The Audio Delay

    Adjusting the Audio Delay When watching a DVD or other video source, the picture on the monitor may seem delayed with respect to the sound. In this case, adjust the audio delay to delay the sound and synchronize it with the picture. The audio delay setting is stored separately for each input source.
  • Page 62: Dsp Surround Simulation

    11 DSP SURROUND SIMULATION • The AVR-3803/1083 is equipped with a high performance DSP (Digital Signal Processor) which uses digital signal processing to synthetically recreate the sound field. One of ten preset surround modes can be selected according to the program source and the parameters can be adjusted according to the conditions in the listening room to achieve a more realistic, powerful sound.
  • Page 63 DSP surround simulation • To operate the surround mode and surround parameters from the remote control unit. Select the surround mode for the input channel. (Remote control unit) The surround mode switches in the following order each time the DSP SIMULATION button is pressed: WIDE SCREEN SUPER STADIUM...
  • Page 64 • Operating the surround mode and surround parameters from the main unit‘s panel. Turn the SELECT knob to select the surround mode. SELECT (Main unit) • When turned clockwise DIRECT STEREO DOLBY PRO LOGIC VIRTUAL MATRIX VIDEO GAME • When turned counterclockwise DIRECT STEREO DOLBY PRO LOGIC...
  • Page 65: Tone Control Setting

    Tone control setting • Use the tone control setting to adjust the bass and treble as desired. • To operate the tone control from the remote control unit. Display the surround parameter screen on the monitor. The screen for the selected surround mode appears.
  • Page 66 • To operate the tone control from the main unit. The tone switches as follows each time the TONE CONTROL button is pressed. (Main unit) With the name of the volume to be adjusted selected, turn the SELECT knob to adjust the level. SELECT •...
  • Page 67: Surround Modes And Parameters

    Surround modes and parameters Channel output SURROUND Mode FRONT L/R CENTER PURE DIRECT, DIRECT STEREO EXTERNAL INPUT DOLBY PRO LOGIC DTS NEO:6 DOLBY DIGITAL DTS SURROUND (DTS ES MTRX 6.1) 5/7CH STEREO WIDE SCREEN SUPER STADIUM ROCK ARENA JAZZ CLUB CLASSIC CONCERT VIDEO GAME MONO MOVIE...
  • Page 68: Listening To The Radio

    12 LISTENING TO THE RADIO • Check that the remote control unit is set to AMP. Auto tuning Set the input function to “TUNER”. FUNCTION (Main unit) Watching the display, press the BAND button to select the desired band (AM or FM). (Remote control unit) Press the MODE button to set the auto tuning mode.
  • Page 69: Checking The Preset Stations

    Preset memory Use the “Auto tuning” or “Manual tuning” operation to tune in the station to be preset in the memory. Press the MEMORY button. (Remote control unit) Press the SHIFT button and select the desired memory block (A to E). (Remote control unit) Press the CHANNEL + (UP) or –...
  • Page 70: Last Function Memory

    Recalling preset stations • Recalling preset stations from the remote control unit. Watching the display, press the SHIFT button to select the preset memory block. (Remote control unit) Watching the display, press the CHANNEL + (UP) or – (DOWN) button to select the desired preset channel.
  • Page 71: Troubleshooting

    15 TROUBLESHOOTING If a problem should arise,first check the following table. 1. Are the connections correct ? 2. Have you operated the receiver according to the Operating Instructions ? 3. Are the speakers, turntable and other components operating property ? If this unit is not operating properly, check the items listed in the table below.
  • Page 72: Additional Information

    The AVR-3803/1083 is equipped the function of surround speakers selection that makes it possible to change the settings according to the combination of surround speakers being used and the surrounding environment in order to achieve the ideal surround sound for all sources.
  • Page 73 SCREEN mode is a mode for achieving surround sound with up to 7.1 channels using surround back speakers, for sources recorded in conventional Dolby Surround as well as Dolby Digital 5.1-channel and DTS Surround 5.1-channel sources. Furthermore, all the Denon original surround modes (see page 62) are compatible with 7.1-channel playback, so you can enjoy 7.1-channel sound with any signal source.
  • Page 74 • We recommend installing the surround back speaker(s) at a slightly downward facing angle. This effectively prevents 60° • Connect the surround speakers to the surround speaker A jacks on the AVR-3803/1083 and set all settings on the setup Surround back speakers...
  • Page 75 Subwoofer • Connect the surround speakers for watching movies to the surround speaker A jacks on the AVR-3803/1083, the surround speakers for playing multi-channel music to the surround speaker B jacks. Set the surround speaker selection 45°...
  • Page 76 Surround The AVR-3803/1083 is equipped with a digital signal processing circuit that lets you play program sources in the surround mode to achieve the same sense of presence as in a movie theater. Dolby Surround (1) Dolby Digital Dolby Digital is the multi-channel digital signal format developed by Dolby Laboratories.
  • Page 77: Dts Digital Surround

    AVR-3803/1083, or may only produce noise. Before playing DTS signals for the first time, turn down the master volume to a low level, start playing the DTS disc, then check whether the DTS indicator on the AVR-3803/1083 (see page 59) lights before turning up the master volume.
  • Page 78 DTS-ES Extended Surround DTS-ES Extended Surround is a new multi-channel digital signal format developed by Digital Theater Systems Inc. While offering high compatibility with the conventional DTS Digital Surround format, DTS-ES Extended Surround greatly improves the 360-degree surround impression and space expression thanks to further expanded surround signals.
  • Page 79 DTS 96/24 The sampling frequency, number of bits and number of channels used for recording of music, etc., in studios has been increasing in recent years, and there are a growing number of high quality signal sources, including 96 kHz/24 bit 5.1-channel sources. For example, there are high picture/sound quality DVD video sources with 96 kHz/24 bit stereo PCM audio tracks.
  • Page 80 System setup items and default values (set upon shipment from the factory) System setup Input the combination of speakers in your system and their Speaker corresponding sizes (SMALL for regular speakers, LARGE for full- Configuration size, full-range) to automatically set the composition of the signals output from the speakers and the frequency response.
  • Page 81 Surround modes and parameters Channel output SURROUND Mode FRONT L/R CENTER PURE DIRECT, DIRECT STEREO EXTERNAL INPUT DOLBY PRO LOGIC DTS NEO:6 DOLBY DIGITAL DTS SURROUND (DTS ES MTRX 6.1) 5/7CH STEREO WIDE SCREEN SUPER STADIUM ROCK ARENA JAZZ CLUB CLASSIC CONCERT VIDEO GAME MONO MOVIE...
  • Page 82 Differences in surround mode names depending on the input signals Surround Mode ANALOG LINEAR PCM PURE DIRECT, DIRECT STEREO DTS SURROUND DTS NEO:6 DTS NEO:6 DOLBY SURROUND DOLBY DOLBY PRO LOGIC PRO LOGIC DSP SIMULATION C : Selectable : The surround mode name differs depending on the “SB CH OUT” surround parameter setting. B : The surround mode name differs depending on the input signal.
  • Page 83: Specifications

    17 SPECIFICATIONS Audio section • Power amplifier Rated output: Dynamic power: Output terminals: • Analog Input sensitivity / input impedance: Frequency response: S/N: Distortion: Rated output: • Digital D/A output: Digital input: • Phono equalizer (PHONO input — REC OUT) Input sensitivity: RIAA deviation: Signal-to-noise ratio:...
  • Page 84 16-11, YUSHIMA 3-CHOME, BUNKYOU-KU, TOKYO 113-0034, JAPAN Telephone: (03) 3837-5321 Printed in Japan 511 3965 008...
