The RV-8 will set the mute state according to the value transmitted. The RV-8 may still be full
muted if other conditions require the audio path to be muted. This is only a direct access to the
user mute state.
7.3.11.4 Data Validation
The data value transmitted to the RV-8 will be verified as a valid value. If it is valid the RV-8 will
set/clear the mute and respond with an ACK Packet. If the data value is invalid the RV-8 will
respond with a DC_INVALID_DATA error NAK.
7.3.12 Send Display String Command
This command allows the Host to send a 40-character string to the RV-8 for display on the OSD
and Front Panel Display. This can be configured such that the message will display only on the
FPD, if desired.
7.3.12.1 Packet Description
Application Header:
Command
Data Count
Application Data:
Data[0]
Data[1]-Data[DataCount-1]
7.3.12.2 Data Description
Display Command Flags:
Word
Bit
Definition
0
0
FPD only: If set TRUE, the display string will only be sent to the FPD device for display.
0
1
Undefined.
0
2
Undefined.
0
3
Undefined.
0
4
Undefined.
0
5
Undefined.
0
6
Undefined.
0
7
Undefined.
Display String:
Data Type:
Max Length:
7.3.12.3 RV-8 Response
The display string is sent to the OSD and Front Panel Display. The RV-8 will ACK when
completed with this command.
7.3.12.4 Data Validation
If a string length exceeds the 40 character maximum the string will be truncated before
displaying and the RV-8 transmit a DC_NAK command with an error code DC_INVALID_DATA.
DC_CMD_SET_DISPLAY_STR 0x33
Number of characters in the
DisplayStr + 2
DisplayFlags
DisplayStr
Null (0x00) terminated ASCII character string.
40 characters.
RV-8 Serial Communications Protocol
nn
nn
ch ch ch ... 0x00
