MIDI Program Table Map Format
$F0
$06
$01
$7n
$0p
$0x
$0x
$0x
(128 total 12 bit words = 384 data byte characters)
0mmmmmmm
$F7
Request Data Format
$F0
$06
$01
$4n
0sssssss
0nnnnnnn
$0x
$0x
$0x
$0x
$F7
480 System Exclusive Header
Parameter Data Message Class, Sysex Channel Device ID
Subclass = Machine
p = 0 =Machine A
p = 1 = Machine B
Nibblized Data Bytes
Data Checksum Calculated by adding each data character to
previous sum starting with Nibblized Data Bytes
End of System Exclusive
480 System Exclusive Header
Parameter Data Message Class, Sysex Channel Device ID
Subclass
Request Opcode
$00 $03
$00 $05
$00 $07
$00 $09
$03 $09
$04 $09
$03 $0A
$04 $0A
Nibblized Index
End of System Exclusive
Appendix A: MIDI and the 480L
Most Significant Bits
Least Significant Bits
All Registers (Internal and External)
Preset Setup
Register Setup
Global Controls
Machine A
Machine B
Midi Program Map Machine A
Midi Program Map Machine B
Most Significant Bits
Least Significant Bits
4 bits (out of 12)
4 bits ( out of 12)
4 bits (out of 12)
4 bits (out of 16)
4 bits ( out of 16)
4 bits ( out of 16)
4 bits (out of 16)
A-11
