Lexicon LEXICON480LV4 Owner's Manual page 113

Page 2
PDL and PDR (Left and Right Predelays)
PDL and PDR are predelay lines which are indepen-
dently set for left and right. The entire modulation effect
takes place within these two delay lines. All feedbacks
wrap back to these delay lines.
INDL and INDR (Left and Right Input Delays)
INDL and INDR are dry path delay lines. Any amount
of dry mix passes through these two delay lines.
TREB (Treble Cut)
TRB controls a low-pass filter which rolls off the pro-
cessed audio. It is functionally placed at the output of
the algorithm.
MIX
MIX controls the amount of dry audio (unprocessed)
relative to processed audio. Most programs have the
mix value set to 100% wet (All FX).
Page 3
FBK (Left and Right Feedback)
FBL and FBR are feedback paths which route back to
their respective inputs.
CFB (Left and RIght Cross Feedback)
XFBL and XFBR are independent cross-feedbacks
which route the outputs of each delay line to the
opposite input.
PAN
Left and Right PAN controls position the processed
audio of each delay line between the left and right
outputs.
Bank 15: the Prime Time III Programs
Programs — Bank 12: Prime Time III
1 Prime Chorus
SPD SPD MAX
2 19 3
PDL PDL IND
19.30ms 18.55ms 22.79 ms 22.79 ms 13.4kHz
FBK FBK CFB
2 -2 -11
2 Slap Chorus
SPD SPD MAX
121 158 2
PDL PDL IND
93.79ms 80.35ms 22.79ms
FBK FBK CFB
24 24 -27
3 Bounce Glide
SPD SPD MAX
67 28 2
PDL PDL IND
325.0ms 661.29ms 22.79ms
FBK FBK CFB
+6 +6 +70
4 Swirls
SPD SPD MAX
3 5 2
PDL PDL IND
0.0ms 0.0ms 8.30ms
FBK FBK CFB
-39 -39 24
5 Heavy Chorus
SPD SPD MAX
110 85 4
PDL PDL IND
13.34ms 8.89ms 5.62ms
FBK FBK CFB
-38 15 -15
MAX WIN WIN
3 59smp 31smp
IND TRB MIX
All Fx
CFB PAN PAN
-10 Left Right
MAX WIN WIN
3 31smp 125smp
IND TRB MIX
22.79ms 6.5kHz All Fx
CFB PAN PAN
-27 Left Right
MAX WIN WIN
2 59smp 62smp
IND TRB MIX
22.79ms 6.0kHz All Fx
CFB PAN PAN
+35 Right Left
MAX WIN WIN
3 51smp 43smp
IND TRB MIX
5.62ms 5.62kHz All Fx
CFB PAN PAN
-24 Left Right
MAX WIN WIN
5 78smp 74smp
IND TRB MIX
5.62ms 6.5kHz All Fx
CFB PAN PAN
38 Left Right
12-3
