Event Data Format
$F0
$06
$01
$3n
$0d
0nnnnnnn
$0v
$0v
$0v
$0v
$0v
$F7
Stored Bulk Data Format
$F0
$06
$01
$1n
0sss 0000
$0n
$0n
$0n
$0c
$0c
$0c
$0c
$0x
$0x
$0b
$09
$06
$0d
$0b
$06
$09
$0d
0mmmmmmm
$F7
480 System Exclusive Header
Parameter Data Message Class, Sysex Channel Device ID
Subclass = Control Class
$2 Global Controls
$3-$4 Program Controls Machine A and Machine B
$5-$6 Patch Controls Machine A and Machine B
$7-$8 Process Controls Machine A and Machine B
$9-$A Table Controls Machine A and Machine B
$B-$C Name Controls Machine A and Machine B
Event Number Index within Control Class
0-127
Nibblized Most Significant
Nibblized Least Significant
End of System Exclusive
480 System Exclusive Header
Parameter Data Message Class, Sysex Channel Device ID
Subclass = Setup Class
$30 Internal Register
$50 Preset
$70 External (Cartridge) Register
Nibblized Setup Index
Nibblized Setup Index
Nibblized Data Byte Count
(Number of Nibblized Pairs + 4)
Nibblized Data Byte Pairs
Bulk Data Flags
Data Checksum calculated by adding each data character to
previous sum starting with Nibblized Setup Index
End of System Exclusive
Appendix A: MIDI and the 480L
4 bits (out of 20 bits)
4 bits
4 bits
4 bits
4 bits (out of 20 bits)
Most Significant Bits
Least Significant Bits
Most Significant Bits
Least Significant Bits
Most Significant Bits
Least Significant Bits
4 bits (out of 12)
4 bits (out of 12)
4 bits (out of 12)
4 bits (out of 16)
4 bits (out of 16)
4 bits (out of 16)
4 bits (out of 16)
4 bits (out of 8)
4 bits (out of 8)
4 bits (out of 32)
4 bits (out of 32)
4 bits (out of 32)
4 bits (out of 32)
4 bits (out of 32)
4 bits (out of 32)
4 bits (out of 32)
4 bits (out of 32)
A-9
