M
M
ENU
ODE
S IF SFT
( S
B
UB
044 S-iF LSB SFT
Function: Sets the center frequency of the Sub band (VFO-
B) receiver's IF filter in the LSB mode.
Available Values: –1000 ~ +1000 Hz (20Hz/step)
Default Setting: 0 Hz
045 S-iF USB SFT
Function: Sets the center frequency of the Sub band (VFO-
B) receiver's IF filter in the USB mode.
Available Values: –1000 ~ +1000 Hz (20Hz/step)
Default Setting: 0 Hz
046 S-iF CWL SFT
Function: Sets the center frequency of the Sub band (VFO-
B) receiver's IF filter in the CW (LSB) mode.
Available Values: –1000 ~ +1000 Hz (20Hz/step)
Default Setting: 0 Hz
047 S-iF CWU SFT
Function: Sets the center frequency of the Sub band (VFO-
B) receiver's IF filter in the CW (USB) mode.
Available Values: –1000 ~ +1000 Hz (20Hz/step)
Default Setting: 0 Hz
048 S-iF RTTY
Function: Sets the center frequency of the Sub band (VFO-
B) receiver's IF filter in the RTTY mode.
Available Values: –1000 ~ +1000 Hz (20Hz/step)
Default Setting: 0 Hz
049 S-iF RTTY-R
Function: Sets the center frequency of the Sub band (VFO-
B) receiver's IF filter in the RTTY reverse mode.
Available Values: –1000 ~ +1000 Hz (20Hz/step)
Default Setting: 0 Hz
050 S-iF PKT-LSB
Function: Sets the center frequency of the Sub band (VFO-
B) receiver's IF filter in the Packet (LSB) mode.
Available Values: –1000 ~ +1000 Hz (20Hz/step)
Default Setting: 0 Hz
051 S-iF PKT-USB
Function: Sets the center frequency of the Sub band (VFO-
B) receiver's IF filter in the Packet (USB) mode.
Available Values: –1000 ~ +1000 Hz (20Hz/step)
Default Setting: 0 Hz
Page 120
G
)
IF S
ROUP
AND
HIFT
MODE-AM G
052 A3E MICGAIN
Function: Sets the microphone gain for the AM mode.
Available Values: Ur (VR) / 0 ~ 100
Default Setting: 30
When this menu is set to "Ur (VR)," you may adjust the
microphone gain using the front panel's [ MIC ] knob.
053 A3E MIC SEL
Function: Selects the microphone to be used on the AM
mode.
Available Values: Frnt / dAtA / PC
Default Setting: Frnt
Frnt: Selects the microphone connected to the front
panel's MIC jack while using the AM mode.
dAtA: Selects the microphone connected to pin 1 of
the PACKET Jack while using the AM mode.
PC:
This parameter is for future expansion of this
transceiver's capabilities, but at this time is not
supported.
FT-2000D O
ROUP
M
PERATING
ANUAL
