1.25Gbps Upstream/1.25Gbps Downstream
GE-PON ONU Transceiver
Description
DELTA's
GE-PON
OPEP-33-A4Q3R is designed for Gigabit Ethernet
Passive Optical Network transmission.
The module is contained in a 2x5 SFF
package with a 9/125um SC pigtail single mode
fiber.
The module consists 1310nm FP laser,
InGaAs PIN, Preamplifier and WDM filter in a
high-integrated
optical
receives up to 1.25Gbps of continuous data at
1490nm, and transmits 1.25Gbps of burst-mode
data at 1310nm.
DELTA ELECTRONICS, INC.
ONU
transceiver
sub-assembly,
and
FEATURES
RoHS compliant
IEEE802.3ah Gigabit Ethernet compliant
2x5 pin SFF package with SC pigtail fiber
1310nm Burst Mode 1.25Gbps transmitter,
and 1490nm Continuous Mode 1.25Gbps
receiver
Integrated with WDM filter to cut 1550nm and
1650nm optical signal off
Single +3.3V power supply
LVTTL Bias Control input and Rx Signal
Detect output
Laser Class 1 Product which comply with the
requirements of IEC 60825-1 and IEC 60825-2
Application
IEEE 802.3ah 1000BASE-PX10-U
GE-PON ONU
Burst Mode Application
FTTx WDM Broadband Access
OPEP-33-A4Q3R data link up to 10km in
9/125um single mode fiber.
it
1
OPEP-33-A4Q3R
Revision: S1
03/12/2007
www.deltaww.com
Advertisement
Table of Contents
Related Manuals for Delta GE-PON ONU Transceiver OPEP-33-A4Q3R
Summary of Contents for Delta GE-PON ONU Transceiver OPEP-33-A4Q3R
- Page 1 1.25Gbps of continuous data at 1490nm, and transmits 1.25Gbps of burst-mode data at 1310nm. DELTA ELECTRONICS, INC. FEATURES RoHS compliant IEEE802.3ah Gigabit Ethernet compliant 2x5 pin SFF package with SC pigtail fiber 1310nm Burst Mode 1.25Gbps transmitter, and 1490nm Continuous Mode 1.25Gbps...
-
Page 2: Absolute Maximum Ratings
Note (1). Launched power (avg.) is power coupled into a single mode fiber with master connector. B.O.L=Before of Life; E.O.L= End of Life Note (2). These are unfiltered 20-80% values. Note (3). Measure at 2 -1 NRZ PRBS pattern DELTA ELECTRONICS, INC. Symbol Min. Typ. -0.3 -0.3... - Page 3 Data Output Rise/Fall time Receiver 1480 to 1500nm Reflectance 1260 to 1360nm Optical Isolation from External 1550 to 1560nm Source 1640 to 1665nm DELTA ELECTRONICS, INC. 1240 1260 1- X2 1- X1 Symbol Min. 1480 λ OPEP-33-A4Q3R Transmitter Spectral Limits 1280...
- Page 4 Note (2). Internally AC coupled, but requires a 100Ohm differential termination at or internal to Serializer/ Deserializer. 6. Transmitter Burst Mode Timing Characteristics Parameter BiasCNT Enable Duration Interval of BiasCNT Signal BiasCNT DELTA ELECTRONICS, INC. Symbol Min. Typ. LOSH LOSL Symbol Min.
-
Page 5: Pin Description
VeeR VccR RD(n) RD(p) VccT VeeT BiasCNT TD(p) TD(n) DELTA ELECTRONICS, INC. Data Input Optical Output Other Laser bias and modulation signal output Within 15% of steady state Toff Receiver Ground +3.3V Receiver Power Supply Normal Optical Input indicated by logic “High”, and No Optical Input indicated by logic “Low”. - Page 6 8. Recommended Interface Circuit BiasCNT Protocol IC SerDes IC * RES is the internal 4.7K to 10K Ohms pull-up resistor. DELTA ELECTRONICS, INC. 3.3V 10uF 100nF Z0=50ohm Z0=50ohm 150ohm 150ohm 10uF Z0=50ohm 100ohm Z0=50ohm OPEP-33-A4Q3R DELTA GEPON ONU Module 6. VccT 100nF 8.
-
Page 7: Outline Dimensions
Parameter Mechanical Dimensions Connector Type Minimum Fiber Bending Radius Maximum Fiber Contact Temperature Tensile Force on Pigtail Maximum Fiber Stress Allowance Fiber length (L) DELTA ELECTRONICS, INC. Unit Description 49.5x13.34x9.6 SC/UPC connector ºC kpsi 540 +/-20 W eek (52W eeks/Year) : 1月 2日 =01... -
Page 8: Regulatory Compliance
FDA/CDRH Laser Eye Safety Component Recognition UL/CSA Appendix A. Document Revision Version No. Date 2006-08-15 2007-03-12 DELTA ELECTRONICS, INC. Reference MIL-STD-883E Method 3015.7 EIA-JESD22-A114 IEC/EN 61000-4-2 IEC/EN 61000-4-2 IEC/EN 61000-4-3 FCC Part 15 Class B EN 55022 Class B (CISPR 22A) FDA 21CFR 1040.10, 1040.11...
