Item Setting value
EFULL (00)
UP CONV.
MODE
(0405)
EAUTO (00)
HDMI MODE
(0406)
ESTANDARD (00)
DVI COLOR
(0407)
EFULL(00)
MON.OUT
ASPECT
(0408)
(SIDE P. is only
for 50 Hz sys-
tems)
EOFF (00)
TEST SIGNAL
(0409)
PAGE BACK
Up-converts DV/HDV-SD50p input signals or DV/DVCAM/
SIDE P. (01) HDV-SD50p recorded tape playback signals, and sets the video
mode for output from the COMPONENT OUT or HDMI OUT ter-
minal.
FULL : The 4:3 angle of view is stretched to 16:9 and displayed.
SIDE P:The 4:3 angle of view remains, with both sides in black.
Selects the video mode to output from the HDMI OUT terminal.
RGB (01) AUTO: Automatically outputs video to match the video mode of
RGB : Outputs RGB video. Use this setting when video is not
Set this item when connecting the HDMI OUT terminal to a DVI
ENHANCED (01) (Digital Video Interface) terminal on the monitor.
STANDARD : Standard mode. Usually, this setting is used.
ENHANCED: Enhanced mode. Select the video of your choice
For setting the aspect ratio of the output from the HDMI OUT ter-
LETTER(01) minal and the COMPONENT OUT terminal. Set according to the
SIDE P.(02) aspect ratio of the monitor.
FULL
LETTER
SIDE P.
Memo
Aspect ratio is fixed regardless of these settings when outputting
480I or 576I video.
Outputs test signals from the built-in video signal generator.
CB (01) OFF : Does not output test signals.
CB
Memo
These test signals are not controlled for use as standard signals.
Returns to TOP Menu screen.
Description
Set here to up-convert tapes recorded in 16:9.
Set here to up-convert tapes recorded in 4:3.
the connected monitor. Usually, this setting is used.
displayed properly on the connected monitor.
(image quality, color density, black blending).
: Sets for aspect 16:9 monitors such as multiformat
COMPONENT and HDMI monitors.
: Outputs aspect ratio 16:9 video such as HDV sig-
nals, to 4:3 and other non-16:9 monitors.
: Shows 4:3 screen as widescreen video blackened
on both sides when playing tapes recorded in
aspect ratio 4:3 in 576/50p mode on the GR-PD1
on a 16:9 monitor.
: Outputs color bar signals.
