burner tubes CLeAninG or rePLACeMent

You will need: Phillips screwdriver, flathead screwdriver, and 5/16" nut-driver .
A) Your Weber gas barbecue must be OFF and cool .
®
B) Turn gas OFF at source .
C) Remove cookbox components - warming rack, grates and Flavorizer
deflectors do not need to be removed .)

Control Panel removal

To remove control panel:
A) Locate door pin release in door assembly . Using a screwdriver, push down on door
pin release (1) until door detaches from frame assembly . Pull top of door away from
frame assembly (2) and lift door off bottom adjustable hinge pin .
B) Remove control knobs, igniter button, igniter retention nut, and battery (3) .
C) Remove screws from wind deflector (4) located underneath the control panel with a
Phillips screwdriver .
D) Tilt end of wind deflector down and slide away to remove (5) .
E) Remove igniter module from control panel (6) and remove all four wires from
module .
F) Remove screws from underside of control panel with Phillips screwdriver (7) .
G) Lift control panel up slightly, tilt up front edge and gently lift up and away (8) .
24
mAINTENANcE
bars . (Heat
®
5
1
2
3
4
7
6
8
