GAS GRILL
LP Gas Grill Owner's Guide
330
YOU MUST READ THIS OWNER'S GUIDE
BEFORE OPERATING YOUR GAS GRILL.
m DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odour continues, keep away from the
appliance and immediately call your gas
supplier or your fire service.
Leaking gas may cause a fire or explosion,
which can cause serious bodily injury or
death, or damage to property.
m WARNING
1. Do not store or use petrol or other
flammable vapours and liquids in the
vicinity of this or any other appliance.
2. A gas supply cylinder not connected for
use should not be stored in the vicinity
of this or any other appliance.
#54412
m WARNING: Follow all leak-check
procedures carefully in this manual
before operating barbecue. Do this even
if barbecue was dealer-assembled.
m WARNING: Do not ignite this appliance
without first reading the BURNER
IGNITION sections of this manual.
INFORMATION FOR THE INSTALLER:
This manual must remain with the owner,
who should keep it for future use.
OUTDOOR USE ONLY.
54412 11/15/11 LP
EN - INTERNATIONAL ENGLISH
Advertisement
Table of Contents
Related Manuals for Weber Genesis 330
Summary of Contents for Weber Genesis 330
- Page 1 GAS GRILL LP Gas Grill Owner’s Guide #54412 YOU MUST READ THIS OWNER’S GUIDE m WARNING: Follow all leak-check BEFORE OPERATING YOUR GAS GRILL. procedures carefully in this manual before operating barbecue. Do this even if barbecue was dealer-assembled. m DANGER If you smell gas: m WARNING: Do not ignite this appliance 1.
-
Page 2: Warnings
Do not build this model of grill in any built-in or slide-in construction. Ignoring this warning could cause a fire or m Do not use charcoal, briquettes or lava rock in your Weber ® an explosion that may damage property or cause serious gas barbecue. -
Page 3: Table Of Contents
PRESERVE YOUR STAINLESS STEEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 WEBER SPIDER/INSECT SCREENS . -
Page 4: Exploded View
EXPLODED VIEW Genesis_330_LP_GB_080911... -
Page 5: Exploded View List
Cylinder Brackets 14. Rear Frame Support 31. Sear Burner Heat Shield 48. Caster 15. Disposable Drip Pan 32. Igniter Button 49. Matchstick Holder 16. Catch Pan 33. Igniter Module 50. Locking Caster Catch Pan Holder 34. Wind Deflector WWW.WEbER.cOm ®... -
Page 6: Warranty
® Infrared rotisserie burner: 2 years Weber is not liable for any special, indirect or consequential damages . Some regions do not allow the All remaining parts: 2 years exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not apply to you . -
Page 7: Gas Instructions
. Under moderate pressure, inside a cylinder, LP gas is a liquid . As the pressure is released, the liquid readily vapourises gas hose assembly on your Weber gas barbecue every and becomes gas . -
Page 8: Cylinder Installation Location Options
GAS INSTRUcTIONS CYLINDER INSTALLATION LOCATION OPTIONS Pick one of three options to determine the location of the cylinder; install inside the cabinet, mount on the cylinder hanger, or place the cylinder on the ground . The type and size of cylinder you purchase will help determine the cylinder installation location . Installation Inside of Cabinet 465 mm The LP gas cylinder can be connected inside the grill cabinet as long as the cylinder... -
Page 9: Installing The Cylinder
C) Turn the cylinder so the valve opening faces the front of the barbecue . Be sure that the cylinder brackets are installed in the base panel and that the base of the cylinder fits within the cylinder brackets . WWW.WEbER.cOm ®... - Page 10 A) Place the cylinder on the ground, outside the base cabinet, on the right side of the grill (7) . B) Turn the LP cylinder so the opening of the valve is facing the front of the Weber ® barbecue .
-
Page 11: Prepare To Connect The Lp Cylinder
WARNING: The hose must be secured to the side panel with the hose retention bracket. Failure to do so could cause damage to the hose resulting in a fire or explosion, which can cause serious bodily injury or death, and damage to property. ◆ WWW.WEbER.cOm ®... -
Page 12: Connecting The Liquid Propane Cylinder
GAS INSTRUcTIONS CONNECTING THE LIQUID PROPANE CYLINDER m WARNING: Make sure that the LP cylinder or regulator valve is closed. A) Connect LP cylinder . Some regulators push ON to connect, and pull OFF to disconnect, others have a nut that has a left-hand thread that connects to the cylinder valve . Follow one of the specific regulator connection instructions illustrated based on your regulator type . -
Page 13: Leak-Check Preparation
G) Lift control panel up slightly, tilt up front edge and gently lift up (8) . H) Replace control panel and wind deflector when leak check is completed . ◆ The grill illustrated may have slight differences than the model purchased. WWW.WEbER.cOm ®... -
Page 14: Check For Gas Leaks
NOTE: All factory-made connections have been thoroughly checked for gas leaks. The burners have been flame-tested. As a safety precaution however, you should recheck all fittings for leaks before using your Weber® gas barbecue. Shipping and handling may loosen or damage a gas fitting. - Page 15 OFF the gas. DO NOT OPERATE THE GRILL. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® G) Side burner quick disconnect connection (7) .
-
Page 16: Refilling The Liquid Propane Cylinder
GAS INSTRUcTIONS REFILLING THE LIQUID PROPANE CYLINDER We recommend that you refill the LP cylinder before it is completely empty . To refill, take LP cylinder to a “Gas Propane” dealer . Removal of the gas supply cylinder: A) Shut off gas supply and disconnect hose and regulator assembly from the cylinder . Follow one of the specific regulator connection instructions illustrated based on your regulator type . -
Page 17: Before Using The Grill
WARNING: Always check hose before using barbecue for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber authorised replacement hose. Contact ® the Customer Service Representative in your area using the contact information on our web site. -
Page 18: Main Burner Ignition & Usage
mAIN bURNER IGNITION & USAGE MAIN BURNER IGNITION m DANGER Failure to open the lid while igniting the barbecue’s burners, or not waiting five minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flare-up, which can cause serious bodily injury or death. -
Page 19: Main Burner Manual Ignition
◆ TO EXTINGUISH Push in and turn each burner control knob clockwise to the OFF position . Turn gas supply off at the source . ◆ WWW.WEbER.cOm ®... -
Page 20: Sear Station ® Ignition & Usage
SEAR STATION IGNITION & USAGE ® SEAR STATION BURNER IGNITION ® The 330 model includes a sear burner, which operates as an individual burner . Ignition of the sear burner is the same as ignition of a main burner . To ignite the sear burner refer to “MAIN BURNER IGNITION”... -
Page 21: Grilling Tips & Helpful Hints
Cooking conditions, such as wind and weather, may require adjustment of burner controls to obtain the correct cooking temperatures. Note: If grill loses heat while cooking refer to the troubleshooting section of this manual. m WARNING: Do not move the Weber gas barbecue when ®... -
Page 22: Side Burner Ignition & Usage
SIDE bURNER IGNITION & USAGE SIDE BURNER IGNITION The grill illustrated may have slight differences m DANGER than the model purchased. Failure to open the lid while igniting the side burner, or not waiting five minutes to allow the gas to clear if the side burner does not light, may result in an explosive flare-up, which can cause serious bodily injury or death. -
Page 23: Side Burner Manual Ignition
Wait five minutes to let the gas clear before you try again. ◆ TO EXTINGUISH Push down and turn side burner control knob to the OFF position . Be sure the burner is off and cool before closing the side burner lid . ◆ WWW.WEbER.cOm ®... -
Page 24: Troubleshooting
Check the adjustment pin on the bottom of each door. Loosen adjustment nut(s). Slide door(s) until aligned. Tighten nut . If problems cannot be corrected by using these methods, please contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® SIDE bURNER TROUbLESHOOTING PRObLEm cHEcK SOLUTION Side Burner does not light. -
Page 25: Maintenance
SPIDER/INSECT SCREENS ® Your Weber gas barbecue, as well as any outdoor gas appliance, is a target for spiders m WARNING: Turn your Weber gas barbecue off and wait for ® ® and other insects . They can nest in the venturi section (1) of the burner tubes . This it to cool before cleaning. -
Page 26: Burner Tubes Cleaning Or Replacement
BURNER TUBES CLEANING OR REPLACEMENT You will need: Phillips screwdriver, flathead screwdriver, and 5/16" nut-driver . A) Your Weber gas barbecue must be OFF and cool . ® B) Turn gas OFF at source . C) Remove cookbox components - warming rack, grates and Flavorizer bars . - Page 27 Your actions, if you fail to follow this Product Warning, may cause a fire, an explosion, or structural failure resulting in serious personal injury or death as well as damage to property. ◆ WWW.WEbER.cOm ®...
-
Page 28: Electronic Ignition System Operations
• Make sure the Electronic Ignition button is working by listening and looking for sparks at burner . If the Electronic Ignition System still fails to light, contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® ◆ IGNITER mODULE WIRE GUIDE 330 Wire End &... -
Page 29: Side Burner Maintenance
. If the spider/insect screen becomes damaged or cannot be cleaned, please contact the Customer Service Representative in your area using the contact information on our web site . Log onto www .weber .com ® Burner Flame Pattern... -
Page 30: Memo
mEmO... - Page 31 WWW.WEbER.cOm ®...
- Page 32 This product has been safety-tested and is only certified for use in a specific country. Refer to country designation located on outside of box. These parts may be gas-carrying or gas-burning components . Please contact Weber-Stephen Products LLC Customer Service Department for genuine Weber-Stephen Products LLC replacement part(s) information .
