Britax MULTI-TECH Manual page 7

2f
2h
3
1
2
4
2i
2
1
2j
100° 80°
2g
Slide the loop ends of the tether straps between the front car seat and back
as shown 1 (dia 2h). Bring the buckle ends of the tether straps around the
outside of the car seat and feed through the loops
Making sure that the footprop tether brackets are facing forward and that the
straps are not twisted, snap the buckle of the tether straps onto the tongues on
the sides of the child seat
loose ends downwards
Pull the footprop away from the back of the child seat as far as possible
(dia 2i). Whilst maintaining the correct angle, lower the footprop until it touches
the floor 2 . Make sure that the footprop is securely locked in place by pulling
the sliding section of the footprop.
Finally ensure that the tether straps are fully tightened by pulling the loose
ends downwards (dia 2j). The footprop must rest on a solid floor, not on the
lids of storage boxes or similar, at an angle of 100° to the horizontal
Use the angle guide on the back page of this user guide to check the angle of
the footprop to the floor.
Once firmly strapped in, test the child seat by trying to move it back and forth
and side to side. If it seems loose or if the footprop is not at 100° to the floor,
you must re-install until firmly installed at the correct angle.
To fit your child in the child seat refer to
Loop the tether straps around the vehicle
seat in front of the child seat as shown
(dia 2f).
If your car is equipped with a runner loop
on the seat runners, these may be used
as an alternative
IMPORTANT
straps using the luggage loops.
. Tighten the tether straps by equally pulling the
3
.
4
dia 5f.
9-25kg
(dia 2g inset).
- Do not install the tether
2 .
1
(dia 2j).
