NAIM UNITI Brochure

Specification
OutputS
Audio Outputs Speaker output, line output (L+R RCA),
sub output (2 mono outputs via RCA),
preamp output (DIN)
Signal-to-Noise Ratio (SN ratio) 80dB
Power Output 50W per channel into 8Ω
CD Phase Response Linear phase, absolute phase correct
Other Outputs Headphone
INputS
Antenna Inputs WiFi, F type (plus PAL adapter)
Analogue Inputs 3.5mm socket on front, 3 RCA,
1 powered DIN for Naim phonostage
Input Sensitivity Rear: 275mV at 22KΩ,
Front: 125mV at 10KΩ
Digital Inputs 5 S/PDIF (2 optical, 2 coaxial,
1 digital/analogue 3.5mm jack)
USB Inputs 1 front-panel socket
Other Inputs Ethernet and iPod (analogue)
CONtROL
Remote Control Handset included
IR Input 3.5mm rear panel socket
RS232 Rear panel
Windows Media™ is a trademark of Microsoft Corporation.
UPnP™ is a trademark of the UPnP™ forum.
iPod and Mac are trademarks of Apple Inc, registered in the U.S. and other countries.
NAIM AUDIO LIMITED
Southampton Road • Salisbury • England • SP1 2LN
Tel: +44 (0) 1722 426600 • Fax: +44 (0) 871 230 1012
www.naimaudio.com
FORMAtS
Audio Files Supported Internet radio (Windows Media-formatted
content, MP3 streams, MMS)
Playlists (M3U, PLS)
MP3, AAC (up to 320kbit/s, CBR/VBR)
Apple Lossless (played from iPod)
Windows Media–formatted content-9
(up to 320kbit/s)
FLAC and WAV (up to 24bit/96kHz via
UPnP™ and USB only)
OGG Vorbis
CD Formats Disc compatibility: Redbook and CD-R
pOWER
Supply Voltage 100V - 120V or 220V - 240V, 50/60Hz
Power Consumption (maximum) 350VA
OtHER
Tuning Range FM 87.5 - 108MHz
DAB Band lll and L Band
Internet Radio Service Provider vTuner 5* full service
Languages English, German, French, Italian, Dutch,
Spanish, Chinese
pHYSICAL
Dimensions 87 x 432 x 314mm (H x W x D)
Weight 11.3kg
Colour Black
