Specifications

Standards
• IEEE 802.11b
• IEEE 802.3
• IEEE 802.3u
Data Rate
• Up to 22Mbps with Auto Fallback to
11/5.5/2/1 Mbps
Operating Range
• Up to 350m
(distance performance may be effected by
variables such as barrier composition and
local environment interference)
Interface
• RJ-45 – 10/100 Mbps
• Power Jack – 2.5mm
Network Configuration
• Infrastructure
Configuration and Management
• Web and Windows-based
Radio Signal Type
• Direct Sequence Spread Spectrum (DSSS)
Media Access Protocol
• CSMA/CA (Collision Avoidance) with ACK
Security
• 64-/128-/256-bit Wired Equivalent
Privacy (WEP)
RF Frequency
• 2400MHz – 2497 MHz – Japan Band
• 2400MHz – 2483.5MHz – North America,
Europe
• 2455MHz – 2475MHz – Spain
• 2446.5MHz – 2483.5MHz – France
Operating Channel
• 11 Channels (US, Canada)
• 13 Channels (Europe)
• 14 Channels (Japan)
RF Output Power
• 16.5-18 dBm
Sensitivity
• -80 dBm @ 22 Mbps PBCC
• -85 dBm @ 11Mbps PBCC
• -82 dBm @ 11Mbps CCK
Frequency Stability
• Within + 25 ppm
Data modulation type
• BPSK (1 Mbps)
• QPSK (2 Mbps)
• CCK (5.5/11 Mbps)
• PBCC (5.5/11/22 Mbps)
Operating Systems
• Windows 98/ME/2000/XP
Antenna Type
• Dual Dipole Antennas with Diversity
Antenna Gain
• 2 dBi
SMC Networks Europe
SMC Networks Eastern Europe
Head Office
Telephone: +420 607 96 6699
Edificio Conata II
Facsimile: +420 235 36 3905
Fructuós Gelabert 6-8 20, 4a
SMC Networks Italia
08970 - Sant Joan Despi
Telephone : +39 (0) 33 55 70 86 02
Barcelona
SMC Networks Ireland
Spain
Telephone: +353 61 34 0675
Telephone: +34 93 477 4920
Facsimile: +353 61 34 0675
Facsimile: +34 93 477 3774
SMC Networks Netherlands
SMC Networks Central Europe
Telephone: +31 627 075227
Telephone: +49 (0) 89 92861-0
Facsimile: +31 334 557 330
Facsimile: +49 (0) 89 92861-230
SMC Networks Nordic
SMC Networks CIS
Telephone: +46 (0) 8 687 0700
Telephone: +7 095 789 35 73
Facsimile: +46 (0) 8 87 62 62
Facsimle: +7 095 789 35 73
SMC Networks North West Africa
SMC Networks Denmark
Telephone: +216 71 23 66 16
Telephone: +45 (0) 566 62283
Facsimle:+216 71 75 14 15
Facsimile: +45 (0) 566 62286
SMC is a registered trademark; and EtherPower, EZStart, SimulTasking, TigerSwitch and SuperDisk are trademarks of SMC Networks, Inc.
Other product and company names are trademarks or registered trademarks of their respective holders. © Copyright 2002 SMC Networks, Inc.
LED Indicators
• Power/Status – RED for power on
• Wireless – Green
• Ethernet - Yellow
Power Consumption
• Operation: Maximum 1.05 A
• Standby: 600mA +/- 20mA
Dimension
• 198 x 150 x 61.5 mm
Weight
•600g
Compliance
• USA: FCC Part 15 Class B and C
• Europe: ETSI EN 300 328-2 and ETSI EN 301
489-1, -17, EN60950, CE-Mark
• Canada: ISC RSS139
• Japan: Telec RCR STD 33, T66; JETA
• Wi-Fi Compliant
Temperature Range
Operating: -0˚C to +50˚C
•
• Storage: -20˚C to +70˚C
Humidity
• Operating:0% to 70%
• Storage:0% to 95% Non-condensing
Warranty
• Limited Lifetime
SMCPOE-KIT*
SMCCPWR-INJ2
SMCSPLITTER
Input Specification
• Input Voltage: 40V~56V
• Input Current: 400mA, max. @ 48V Input,
Full Load
• Efficiency: 60%,min.@ Full Load
(including a 100m Ethernet
wire) and 48V Input 75%,
min.@ Full Load (not
including a Ethernet wire)
and 48V Input
• Line Regulation: The maximum voltage
change on output is ±
0.25V when input voltage
varies within 40V~56V
• Input Line Noise: ± 250mV
Output Specification
• Output Voltage: 5.0 ± 0.25 V from no load
to full load
• Output Current: 2.5A, max.
• Dynamic Load Regulation:
The maximum voltage
change on output is ±
0.25 V for 50%-100%
or 100%-50% load
change at any frequency
up to 100Hz (Duty 50%)
± 100mV
• Ripple & Spike:
Interface Requirement
Power Jack Female Connector:
• Connector J1 (to the Power Adapter):
Pin Assignment:
• Pin 1: Power Adapter Output (48V,Typical)
Pin 2: Power Ground
