- Page 1 MS 2010 MS 2110 Traffic Quick Start Guide Erste Schritte und wichtige Hinweise First Steps and Important Notes Premiers pas et instructions importantes Primeros pasos y advertencia importante Primi passi e avviso importante Primeiros passos e avisos importantes Aan de slag en belangrijke aanwijzingen Komma igång och viktiga anvisningar...
-
Page 2: Table Of Contents
Contents • General Instructions Contents General Instructions ............21 Safety Advice and Important Information. -
Page 3: General Instructions
General Instructions The navigation system does not take the relative safety of the suggested routes into consideration. Road closures, roadworks, height and weight restrictions, traffic and weather conditions, or other factors that can influence the safety and the journey time of the route are not taken into consideration for the suggested routes. -
Page 4: Overview Of Device
Overview of Device What's Included? Your navigation system package includes the following parts: Navigation system (including lithium ion battery) Mount with suction cup to attach the device to the windscreen. Cloth for cleaning the windscreen before attaching the suction cup. TMC antenna (only for traffic product version) for receiving traffic information DC cable 12V/24V to power the navigation system from within the vehicle (adapter for cigarette lighter) -
Page 5: Controls And Connection Ports
Overview of Device Controls and Connection Ports Front Display / touchscreen Infrared sensor Usable with remote control on steering wheel RCS 5100 (accessories) On-off switch / multi-function switch / status LED • Quick tap: switches the navigation system to stand-by mode. •... - Page 6 Overview of Device Left Side Right Side Slot for SD card 10 Headphone socket 11 Connection for TMC antenna (only for traffic product version) 12 Connection for 100V/240V mains adapter (optional) or 12V/24V cigarette lighter Underside 13 Serial port Only for service or active cradle (optional) purposes! 14 USB port for connecting...
-
Page 7: Setup And Mounting
Setup and Mounting Initial Setup When you switch on the navigation system for the first time, you must firstly deactivate the transport safety switch. This can be done by performing the following steps: • Open the battery compartment and lift up the battery. Here it is important that the connecting cable is not unplugged. -
Page 8: Configuration
Configuration Configuration • Press the on-off switch for about 3 seconds to switch on the navigation system. The system boots and the battery starts to charge. • The legal disclaimer screen appears. Tap OK after reading the screen. • When you switch on the device for the first time, you may have to select the desired lan- guage for the navigation instructions. -
Page 9: Settings
Settings Settings Tap the Settings button in the main menu to change basic settings. • Tap Settings. A sub-menu opens. Tap the arrow button on the bottom right of the screen to scroll through the other pages of the sub-menu. Tap Back to exit from a selection list without saving changes. - Page 10 Toolbar The toolbar is a shortcut to different functions and information (e.g. Mute, Volume setting, day or night, change route and information). You can open and close the Toolbar by tapping the VDO Dayton logo (bottom right of screen).
-
Page 11: Gps And Tmc
GPS and TMC GPS Status and Quality When you switch on the device for the first time, it can take several minutes for the GPS re- ception to reach a sufficient level and to determine your current position. If you are unable to obtain a sufficient GPS signal, please read the Troubleshooting chapter for suggestions on solving the problem. - Page 12 GPS and TMC TMC Status and Quality (only for traffic product version) Using TMC offers you an additional function to allow you to dynamically avoid traffic jam. During navigation the system regularly accesses the latest TMC traffic information in the background; provided that this information is available in the part of the country you are in.
-
Page 13: Navigation
Navigation Navigation The purpose of the navigation system is to guide you from your present location to your de- sired destination. The navigation function automatically determines your present location using the GPS signal. You simply have to enter your destination and the navigation process starts with spoken and visual instructions. - Page 14 Navigation Intelligent typewriter The navigation sys- tem is equipped with an intelligent typewrit- er. This allows possible characters only. List button After you have typed a few letters you can tap the “list button“. A list of matching results appears. Switch between alphabetical and numerical elements by using the key- board toggle.
- Page 15 Navigation Confirmation When you have entered the destination, all ele- ments for the desired destination appear on the Confirmation screen; the system will confirm your selection. Additionally you have the possi- bility to store the destination: in the Address book or as shortcuts under Home and Work. You can also adjust the navigation settings (e.g.
- Page 16 You can do this by tapping Map display in the Toolbar or in Settings. Toolbar Tapping the VDO Dayton logo (bottom right of screen), you can open the Toolbar, a shortcut to different functions and information. Example: Route & sound Tap the Route &...
-
Page 17: The Multimedia Menu
Multimedia The Multimedia Menu The navigation system offers the possibility of playing MP3 files or viewing JPEG images. In order to be able to use these multimedia functions, the MP3 or JPEG files in question must be saved on an SD card (not provided with this package). If you have a SD card reader/writer, you can copy your MP3 files and JPG pictures directly from your PC to the SD card! Insert the SD card in the slot on the left side of the device. - Page 18 Multimedia Setting the Play Functions Open the Music Settings menu. The Music Settings menu offers you the follow- ing options: • Tap the Equalizer button to select the de- sired equalizer settings, e.g. Jazz, Classic, Rock. • Tap the Random and Repeat buttons to activate or deactivate the corresponding functions.
- Page 19 Multimedia Viewing Pictures – The JPEG Viewer Tap the JPEG viewer button. The JPEG viewer's JPEG menu appears. Using the symbols in the menu, you can perform the following functions: Jump to previous picture Jump to next picture Switch to previous folder Switch to next folder Start slide show If you tap on the picture, the image is dis-...
-
Page 20: Troubleshooting
Troubleshooting Troubleshooting Problem Solution No GPS signal in vehicle The GPS signal can be blocked by heated windscreens or tinted windscreens with a vacuum-metallised surface. In this case, you will need an external GPS antenna. (available from accessory dealers, Article-no. MA2010/00) No GPS signal Make sure that the GPS antenna on the top of the naviga- tion system is not obstructed by other objects. -
Page 21: Technical Data
The device specifications and the contents of the package may deviate from what is stated in this document. Service For current information on VDO Dayton Multimedia Systems, service addresses, software updates please visit our website: www.vdodayton.com or contact a VDO Dayton dealer.
