- Page 1 DTV 6500 Bedienungsanleitung User manual Mode d’emploi Gebruiksaanwijzing Istruzioni d’uso Instrucciones de manejo Betjeningsvejledning...
-
Page 3: Table Of Contents
Contents Contents General information ........4 Notes in installation and operating instructions . -
Page 4: General Information
❑ AV output: Composite Video and Audio L/R for connecting a monitor (e.g. MM 2700). The audio outputs can also be used to connect the DTV 6500 to a car radio or WT 5100 infra-red transmitter in order to play a stereo signal. -
Page 5: Installation
Installation IMPORTANT INFORMATION The system must only be installed by trained personnel. Observe automotive industry quality standards. Fire hazard. When drilling, take care not to damage concealed wiring harnesses, the fuel tank or fuel lines. Never drill into supporting or safety-relevant body parts. It is essential to observe the following when installing components in the passenger compartment: Ensure that the driver has a clear all-round view. -
Page 6: Scope Of Delivery
Modes of installation Whether the DTV 6500 DVB-T tuner is connected to MS 5XXX navigation systems depends on whether a MI 2x00 or MC 5400 multimedia interface box is connected or whether the adapter cable CA 1220 is used. -
Page 7: Installation Of Dvb-T Tuner
Installation Installation of DVB-T Tuner ■ Before installing When installing the DVB-T tuner and the other multimedia components, ensure suitable cable routing and that the required cable length is available. In positioning the tuner, allow ample space for plugging the connector plug into and out of the DVB-T tuner whenever necessary. - Page 8 Insert power supply cable plug into the “DC 12-24V INPUT” socket of the DVB-T tuner. Ensure that the plug latch is engaged. ■ DVB-T tuner to multimedia monitor (e.g. VDO Dayton MM 2700) ☞ Connect the monitor lead for the MM 2700 to the AV output (“AUDIO OUT L/R”...
-
Page 9: Connecting Accessories
☞ Up to 2 antennae can be connected to the tuner via antenna sockets “ANT IN 1” and “ANT IN 2” (e.g. VDO Dayton Antenna Set TVA 6500). ☞ If using the TVA 6500 antenna set, turn the phantom power supply “ANT PWR” to “ON”. -
Page 10: Initial Operation
When the equipment is first put into operation, it is important for an antenna to be connected to the DTV 6500 and that the vehicle is parked in a location where DVB-T reception is possible. If necessary, enquire in advance via conventional media or the internet whether DVB-T is available in your area. - Page 11 Initial operation ■ Antenna Installation Menu The antenna installation menu helps you check that the receiving antenna(e) is (are) properly connected and functioning correctly. The antenna installation menu is always opened automatically if the automatic channel fails to locate a single channel. ☞...
-
Page 12: Operation
Operation Remote control Power On/off Text Subtitle TV/Radio Pause SWAP Exit Menu Audio Info List Mut e 1 Power ..Turn DVB-T tuner on or off 2 0 - 9 ..Number keys 3 TV/Radio . -
Page 13: On/Off - Stand-By
Subtitle ..Select sub-titles language (if subtitles are being transmitted) On/off - stand-by The DTV 6500 is switched on and off together with the ignition. You can switch the DTV 6500 into stand-by mode or turn it back on again using the remote control: ☞... - Page 14 Operation ■ Selecting a channel from the channel list ☞ Press the OK or LIST buttons while in TV mode. The current list of channels is then displayed. ☞ Using the 8 or 2 button select the required channel and confirm this with OK. You should now see the selected programme.
-
Page 15: Electronic Programme Guide - Epg
Operation ■ TV/Radio mode ☞ Press the TV/Radio button to switch between TV and radio reception. ✎ In TV mode you can only receive TV channels and in radio mode, only radio stations. ✎ Please note that not all countries have radio stations that transmit via DVB-T. ■... -
Page 16: Favourites Lists
Operation ■ Selecting programme and day ☞ Mark the required programme with the 2 or 8 keys of the remote control for detailed information on the programme. ☞ Select the required day using the 4 or 6 keys. ✎ You can read information on programmes up to seven days in advance. ☞... - Page 17 Operation Modify favourites list ■ Add/remove channels After creating a favourites list (see previous section) or whenever you select the “Modify a favourite list” option, you can then create your own personal selection of channels. ☞ Press PRF+ or PRF- to select the required list from those already created. ☞...
-
Page 18: Teletext
✎ You can cancel the deletion using the Exit button. Teletext The DTV 6500 is equipped with an integrated teletext decoder. This enables you to make use of teletext on those channels which transmit the service. ✎ TV channels, that provide teletext can be recognised by means of the teletext symbol in the info window. -
Page 19: Settings
Settings User Preferences ☞ Press the Menu button. The main menu appears. ☞ Select “User Preferences” You have the following options in the “User Preferences” menu: ■ Language The “Languages” menu allows you to set the respective languages for the menus, sound (audio) and sub-titles (when transmitted). -
Page 20: Time Settings
Settings TV Configuration The “TV Configuration” menu allows you to match the tuner optimally to the connected monitor. ☞ Select the required setting using the 4 or 6 keys. ☞ Press the OK button to save the values you have set and exit the menu. The following parameters can be set: ■... -
Page 21: Maintenance And Care
Maintenance and care Changing battery The batteries for the remote control need to be changed when the DVB-T tuner no longer reacts to the pressing of any buttons. ☞ Open the battery compartment on the back of the remote control. ☞... -
Page 22: Troubleshooting
This function is only intended for devices with Pay-TV option. Service If you cannot find a solution to your problem, contact an authorised VDO Dayton service agent or call our Customer Helpdesk. You will find the telephone number for your country on the Internet at: www.vdodayton.com... - Page 23 DTV 6500 © 11/2005 Siemens VDO Trading GmbH...
