LUBRICANTS
WARNING
Oil can cause serious damage to the skin
if handled every day and for long peri-
ods. Wash your hands carefully after us-
ing oil.
In case any maintenance operation has
to be carried out, it is advisable to use
latex gloves.
KEEP AWAY FROM CHILDREN.
DO NOT DISPOSE OF OIL IN THE ENVI-
RONMENT.
CAUTION
Proceed with care.
Do not spill the oil!
Take care not to smear any component,
the area in which you are working and
the surrounding area.
Carefully remove any trace of oil.
In case of leakages or malfunctions, con-
tact an aprilia Official Dealer.
use and maintenance Scarabeo 50
28
MIXER OIL
Top up with fresh oil every 2000 km (1250
mi).
The vehicle is provided with a power unit
controlling an electronic pump providing the
right amount of oil required for the engine
lubrication (see page 90 LUBRICANT
CHART).
The reserve is signaled by the mixer oil re-
serve warning light "
board, see page16 and 17 (ARRANGE-
MENT OF THE CONTROLS / INSTRU-
MENTS AND INDICATORS).
CAUTION
The use of the vehicle without mixer oil
causes serious damages to the engine.
If you run out of oil in the mixer oil tank
or if the mixer oil pipe has been removed,
it is necessary to contact an aprilia Offi-
cial Dealer, who will provide for bleeding
the system.
This operation is indispensable, since the
operation of the engine with air in the
mixer oil system may cause serious dam-
ages to the engine itself.
- Scarabeo 100 4T
" found on the dash-
To pour the oil in the reservoir:
Lift the saddle, see page 24 (UNLOCKING
/ LOCKING THE SADDLE).
Unscrew and remove the fuel tank plug (1).
MIXER OIL TANK CAPACITY: 1.5 l
TANK RESERVE: 0.6 l .
Do not put additives or other substances
into the oil.
If you use a funnel or other similar items,
make sure that they are perfectly clean.
Fill with oil
Make sure that the filler cap (1) is well
tightened.
Put back the cap (1).
1
CAUTION
CAUTION
