Insignia NS-L19X-10A User Manual
19" lcd tv with decorative faceplates
Hide thumbs
Also See for NS-L19X-10A:
- Guía del usuario (44 pages) ,
- Manual de l'utilisateur (44 pages) ,
- User manual (40 pages)
Related Manuals for Insignia NS-L19X-10A
Summary of Contents for Insignia NS-L19X-10A
-
Page 1: User Guide
NS-L19X-10A_09-0241_MAN_V2_English.book Page 0 Tuesday, April 7, 2009 9:29 AM User Guide 19" LCD TV with Decorative Faceplates NS-L19X-10A... -
Page 2: Table Of Contents
NS-L19X-10A_09-0241_MAN_V2_English.book Page i Tuesday, April 7, 2009 9:29 AM Contents CHILD SAFETY ...........1 Important safety instructions . - Page 3 NS-L19X-10A_09-0241_MAN_V2_English.book Page ii Tuesday, April 7, 2009 9:29 AM Contents Adjusting the picture ......... . . 16 Adjusting the TV picture .
- Page 4 NS-L19X-10A_09-0241_MAN_V2_English.book Page iii Tuesday, April 7, 2009 9:29 AM Contents www.insigniaproducts.com...
-
Page 5: Child Safety
NS-L19X-10A_09-0241_MAN_V2_English.book Page 1 Tuesday, April 7, 2009 9:29 AM CHILD SAFETY It makes a difference how and where you use your flat panel display As you enjoy your new product, keep these safety tips in mind The issue The home theater entertainment experience is a growing trend, and larger TVs are popular purchases. -
Page 6: Important Safety Instructions
NS-L19X-10A_09-0241_MAN_V2_English.book Page 2 Tuesday, April 7, 2009 9:29 AM Important safety 15 The mains plug is the disconnecting device. The plug must remain readily operable. instructions 16 The apparatus with grounding-type plug is a class I apparatus. Class I apparatus need to be connected to earth ground wire to prevent possible electric shock. -
Page 7: Cautions
NS-L19X-10A_09-0241_MAN_V2_English.book Page 3 Tuesday, April 7, 2009 9:29 AM Power source Note to CATV system installer Operate your TV only from the type of power source Article 820 of the National Electrical Code, indicated on the marking label. If you are not sure ANSI/NFPA No. -
Page 8: Introduction
TV using the four M4 screws provided with bracket. Congratulations on your purchase of a high-quality Adjusting the viewing angle Insignia product. Your NS-L19X-10A represents the state of the art in LCD TV design and is designed for To adjust the viewing angle: reliable and trouble-free performance. -
Page 9: Tv Components
NS-L19X-10A_09-0241_MAN_V2_English.book Page 5 Tuesday, April 7, 2009 9:29 AM 2 Align the plastic studs on the new faceplate Side buttons with the holes on the front of your TV, then press firmly to install the new decorative faceplate. TV components Accessories # Button Description... -
Page 10: Back
NS-L19X-10A_09-0241_MAN_V2_English.book Page 6 Tuesday, April 7, 2009 9:29 AM Back # Jack Description Service port for upgrading firmware. Do not use. SERVICE PORT Connect the 75 ohm coaxial cable from an FM antenna to this jack. Connect headphones to this jack. For more information, see “Connecting headphones”... -
Page 11: Using The Remote Control
NS-L19X-10A_09-0241_MAN_V2_English.book Page 7 Tuesday, April 7, 2009 9:29 AM Using the remote control # Button Description Press to confirm selections in an on-screen menu, or to ENTER open a submenu. Installing the remote control battery Press to navigate within the on-screen menus. For more information, see “Navigating the menus”... -
Page 12: Aiming The Remote Control
Programming a universal remote control to work with your TV To aim the remote control: You can operate your Insignia TV with a new or • Point the remote control toward the remote existing universal remote control. control sensor on the front of your TV. -
Page 13: Making Connections
NS-L19X-10A_09-0241_MAN_V2_English.book Page 9 Tuesday, April 7, 2009 9:29 AM Making connections Connecting a VCR To connect a VCR: 1 Make sure that your TV’s power cord is Cautions unplugged and the VCR is turned off. • Check the terminals for position and type before making any connections. -
Page 14: Connecting A Camcorder Or Game
NS-L19X-10A_09-0241_MAN_V2_English.book Page 10 Tuesday, April 7, 2009 9:29 AM Connecting a camcorder or game 2 Connect an HDMI cable to the HDMI OUT jack on the HDMI device. Some game consoles have an HDMI connector, which can be used for a better picture. Device with HDMI To connect a camcorder or game: output... -
Page 15: Connecting A Computer
NS-L19X-10A_09-0241_MAN_V2_English.book Page 11 Tuesday, April 7, 2009 9:29 AM 3 Connect the other end of the component video To play video from a computer: cable to the COMPONENT1 IN jacks on the back 1 Turn on your TV, then press INPUT. The INPUT of your TV (you can also use the SOURCE menu opens. -
Page 16: Connecting A Digital Sound System
NS-L19X-10A_09-0241_MAN_V2_English.book Page 12 Tuesday, April 7, 2009 9:29 AM Connecting a digital sound system Connecting an FM radio antenna To connect a digital sound system: To connect an FM radio antenna 1 Make sure that your TV’s power cord is •... -
Page 17: Understanding The Basics
NS-L19X-10A_09-0241_MAN_V2_English.book Page 13 Tuesday, April 7, 2009 9:29 AM 3 Press to select the menu language you Selecting the video input source want, then press ENTER. The Choose your TV source screen opens. To select the video input source: 1 Turn on your TV, then press the INPUT key on the remote, or the INPUT button on the TV. -
Page 18: Navigating The Menus
NS-L19X-10A_09-0241_MAN_V2_English.book Page 14 Tuesday, April 7, 2009 9:29 AM Audio menu (TV mode, equalizer on) Radio menu (FM mode) PICTURE AUDIO CHANNELS SETTINGS RADIO PICTURE AUDIO CHANNELS SETTINGS RADIO Radio Audio Equalizer Available Stations Equalizer Mode Custom Frequency 105.15 Equalizer Setting Fine Tune Balance Auto Search... -
Page 19: Adjusting The Volume
NS-L19X-10A_09-0241_MAN_V2_English.book Page 15 Tuesday, April 7, 2009 9:29 AM • To select a digital sub-channel, press the 2 Press to highlight Settings, then press number buttons to select the main digital or ENTER. The Settings menu opens. channel, then press the dot (.) button to select the sub-channel. -
Page 20: Adjusting The Picture
NS-L19X-10A_09-0241_MAN_V2_English.book Page 16 Tuesday, April 7, 2009 9:29 AM • Analog mode information—Displays channel • Advanced Video—Lets you adjust the Aspect number, channel label (if preset), signal type, Ratio, OverScan, Color Temperature, Backlight, audio information, and resolution. Noise Reduction and Advanced Contrast. See “Adjusting Advanced Video settings”... -
Page 21: Adjusting The Computer Image
NS-L19X-10A_09-0241_MAN_V2_English.book Page 17 Tuesday, April 7, 2009 9:29 AM 4 Press MENU to return to the previous menu, or • Phase—Adjusts the focus of stable images press EXIT to close the menu. • Reset Computer Settings—Resets computer settings to factory default. Adjusting the computer image 6 Press MENU to return to the previous menu, or press EXIT to close the menu. -
Page 22: Adjusting The Sound
NS-L19X-10A_09-0241_MAN_V2_English.book Page 18 Tuesday, April 7, 2009 9:29 AM Adjusting the sound • Equalizer Setting—(Available when the Equalizer is On) Select to make custom audio settings. Adjusting the sound To adjust the sound: 1 Press MENU. The on-screen menu opens. PICTURE AUDIO CHANNELS SETTINGS RADIO Picture... -
Page 23: Playing Tv Audio Only
NS-L19X-10A_09-0241_MAN_V2_English.book Page 19 Tuesday, April 7, 2009 9:29 AM Changing channel settings Playing TV audio only You can turn off the picture on your TV and listen to only the program audio. Automatically scanning for channels To play only the TV audio: To auto scan for channels: 1 Press MENU. -
Page 24: Adding Or Skipping Channels
NS-L19X-10A_09-0241_MAN_V2_English.book Page 20 Tuesday, April 7, 2009 9:29 AM If you selected Antenna or Cable, the TV 3 Press to highlight Add/Skip Channels, searches automatically for available channels in then press ENTER. The Channels - Add/Skip your area and stores the channel information in Channels menu opens. -
Page 25: Adding Or Changing A Channel Label
NS-L19X-10A_09-0241_MAN_V2_English.book Page 21 Tuesday, April 7, 2009 9:29 AM 3 Press to highlight Favorites, then press 3 Press to highlight Channel Labels, then ENTER. The Channels - Favorites menu opens. press ENTER. The Channels - Channel Labels screen opens with the channel number field highlighted. -
Page 26: Setting Parental Controls
NS-L19X-10A_09-0241_MAN_V2_English.book Page 22 Tuesday, April 7, 2009 9:29 AM 3 Press to highlight Channel Strength, 4 Press the number buttons to enter the four-digit then press ENTER. The Channel Strength screen password. The default password is 0000. You opens showing the signal strength meter. should change the password to a number you can remember. -
Page 27: Blocking Unrated Tv
NS-L19X-10A_09-0241_MAN_V2_English.book Page 23 Tuesday, April 7, 2009 9:29 AM 3 Press ENTER. The Enter Password screen opens. 4 Press the number buttons (0-9) to enter the four-digit password. The Settings - Parental 4 Press the number buttons (0-9) to enter the Controls submenu opens. -
Page 28: Downloading Rating Information
NS-L19X-10A_09-0241_MAN_V2_English.book Page 24 Tuesday, April 7, 2009 9:29 AM 4 Press the number buttons to enter the four-digit U. S. TV ratings (content-based) password. The Settings - Parental Controls All ratings. submenu opens. Fantasy violence. Strong language. PICTURE AUDIO CHANNELS SETTINGS RADIO Sexual situations. -
Page 29: Using Closed Captioning
NS-L19X-10A_09-0241_MAN_V2_English.book Page 25 Tuesday, April 7, 2009 9:29 AM 2 Press to highlight SETTINGS, then press 2 Press to highlight SETTINGS, then press or ENTER. The Settings menu opens with or ENTER. The SETTINGS menu opens. Parental Controls selected. PICTURE AUDIO CHANNELS SETTINGS RADIO Settings... -
Page 30: Setting Digital Closed Captioning Styles
NS-L19X-10A_09-0241_MAN_V2_English.book Page 26 Tuesday, April 7, 2009 9:29 AM 3 Press to highlight Closed Caption, then 3 Press to highlight Closed Caption, then press ENTER. The Settings - Closed Caption menu press ENTER. The Settings - Closed Caption menu opens. opens. -
Page 31: Adjusting Time Settings
NS-L19X-10A_09-0241_MAN_V2_English.book Page 27 Tuesday, April 7, 2009 9:29 AM Adjusting time settings • Set the time by pressing to highlight Hour, then press to move the highlight to the hour, minute, or AM/PM field. Setting the date and time • Press to adjust the setting. -
Page 32: Adjusting Menu Settings
NS-L19X-10A_09-0241_MAN_V2_English.book Page 28 Tuesday, April 7, 2009 9:29 AM Adjusting menu settings Labeling an input source You can add a label to an input source to make it easier to identify. Selecting the menu language and transparency To label an input source: 1 Press MENU. -
Page 33: Setting The Input Sensor
NS-L19X-10A_09-0241_MAN_V2_English.book Page 29 Tuesday, April 7, 2009 9:29 AM 6 Press to highlight Custom, then press . Restoring default settings A custom label entry field opens. Caution When you restore default settings, all the settings you have customized (except the password and PICTURE AUDIO CHANNELS SETTINGS RADIO... -
Page 34: Selecting An Fm Program
NS-L19X-10A_09-0241_MAN_V2_English.book Page 30 Tuesday, April 7, 2009 9:29 AM Selecting an FM program 3 Press or ENTER to access. To select an FM program: • Press the number buttons (0-9) to select a PICTURE AUDIO CHANNELS SETTINGS RADIO preset station directly. Radio vailable Stations - OR -... -
Page 35: Troubleshooting
NS-L19X-10A_09-0241_MAN_V2_English.book Page 31 Tuesday, April 7, 2009 9:29 AM Troubleshooting General Problem Solution Warning Cannot tune to one or • The program you want to watch may be blocked Do not try to repair your TV yourself. Contact more channels through the parental controls. -
Page 36: Specifications
NS-L19X-10A_09-0241_MAN_V2_English.book Page 32 Tuesday, April 7, 2009 9:29 AM Specifications Canada ICES-003 statement This Class B digital apparatus complies with Canadian ICES-003. Standard Television Receiving Apparatus — Appareil de Design and specifications are subject to change without notice. réception télévision ordinaire, Canada BETS-7 / NTMR-7 Dimensions and weight are approximate. -
Page 37: Two-Year Limited Warranty
Products and parts replaced under this warranty become the property of Insignia and are not returned to you. If service of Products or parts are required after the Warranty Period expires, you must pay all labor and parts charges. - Page 38 NS-L19X-10A_09-0241_MAN_V2_English.book Page 34 Tuesday, April 7, 2009 9:29 AM www.insigniaproducts.com...
- Page 39 NS-L19X-10A_09-0241_MAN_V2_English.book Page 35 Tuesday, April 7, 2009 9:29 AM www.insigniaproducts.com...
- Page 40 7601 Penn Avenue South, Richfield, MN USA 55423-3645 © 2009 Best Buy Enterprise Services, Inc. All rights reserved. INSIGNIA is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
