Configuration

Chapter Overview

Chapter Overview
This chapter contains the following main sections:

• Workstation Configurations

• System Hardware Configurations

— Internal Storage Devices

— Memory
— I/O Cards
— Monitor-Type Selection
Workstation Configurations
Refer to the HP Workstations website for a complete list of supported accessories,
peripherals, and operating system versions for the HP V
URL for the website is:
http://hp.unixworkstations.com
System Hardware Configurations
This section provides information for setting up or changing the configuration of the Field
Replaceable Units (FRUs) for the B2000 workstation.
Internal Storage Devices
Hard Disk Drive Configuration
The SCSI IDs for hard disk drives are hard-wired into the SCA Ultra2 Wide LVD SCSI
interfaces on the system board within the B2000 workstation. Hence, SCSI IDs do not need
to be set for the hard disk drives (up to two) installed in this workstation. From top to
bottom, the pre-set SCSI IDs for hard disk drives are: 6 and 5.
Similarly, no jumpers are installed at the factory, nor is any jumper installation required at
the customer's site, on the hard disk drive model supported with the B2000 workstation.
To remove and replace or install a hard disk drive, see the section titled "Hard Disk
Drives" on page 104. Also see the next subsection, "Configuring a Hard Disk Drive as a File
System," when removing or installing a hard disk drive.
32
B2000 workstation. The
ISUALIZE
Chapter 2
