Configure The Router With The Configuration Wizard - D-Link DSL-524T User Manual

To use the web-based management software, launch a suitable web browser and direct it to the IP
address of the Router. Type in http:// followed by the default IP address, 192.168.1.1 in the address
bar of the browser. The URL in the address bar should read: http://192.168.1.1. Once entered, the user
will be prompted to enter the username and password to access the Configuration Manager, as show
below. A new window will appear and you will be prompted for a user name and password to access
the web-based manager. Use the default user name "admin" and password "admin" for first time setup.
You should change the web-based manager access user name and password once you have verified
that a connection can be established. The user name and password allows any PC within the same
subnet as the Router to access the web-based manger.

Configure the Router with the Configuration Wizard

The first page that appears after you successfully login displays information about the Router's Setup
Wizard. Tabs across the top of the screen show other available menus: Home, Advanced, Tools,
Status, and Help.
DSL-524T ADSL Router Manual
NOTE: Do not confuse the user name and password used to
access the web-based manager with the ADSL account user
name and password needed for PPP connections to access the
service provider's network.
Figure 3-1. Enter Network Password dialog box.
25
