Specifications

■ INPUT/OUTPUT
Input jacks
• HDMI input x 4
• AV input x 5
[Audio] Digital input (optical) x 2, digital input (coaxial) x 2,
analog input x 1
[Video] Component video jacks x 2, video jacks x 3
• AUDIO input x 2
[Audio] Analog jack x 2
• VIDEO AUX input x 1
[Audio] Analog x 1, stereo mini jack x 1
[Video] Video jack x 1
• DOCK input x 1
Output jacks
• TV output (monitor output) x 3
[Audio/Video] HDMI x 1
[Video] Component video jack x 1, video jack x 1
• AV output x 2
[Audio] Analog jack x 1
[Video] Video jack x 1
• AUDIO output x 1
[Audio] Analog jack x 1
■ HDMI
• HDMI Specification: Deep Color, "x.v.Color," Auto Lips Sync,
ARC (Audio Return Channel)
• Video Format (Repeater Mode)
- VGA
- 480i/60 Hz
- 576i/50 Hz
- 480p/60 Hz
- 576p/50 Hz
- 720p/60 Hz, 50 Hz
- 1080i/60 Hz, 50 Hz
- 1080p/60 Hz, 50 Hz, 24 Hz
• Audio Format
- Dolby Digital
- DTS
- DSD 6ch
- Dolby Digital Plus
- Dolby TrueHD
- DTS-HD
- PCM 2ch-8ch (Max 192 kHz/24 bit)
• Content Protection: HDCP compatible
■ Compatible Decoding Formats
• Decoding Format
- Dolby TrueHD, Dolby Digital Plus
- DTS-HD Master Audio, DTS-HD High Resolution, DTS Express
- Dolby Digital
- DTS, DTS 96/24
• Post Decoding Format
- Dolby Pro Logic
- Dolby Pro Logic II Music, Dolby Pro Logic II Movie,
Dolby Pro Logic II Game
- DTS Neo:6 Music, DTS Neo:6 Cinema
■ AUDIO SECTION
• Minimum RMS Output Power for Front, Center, Surround
[U.S.A. and Canada models]
(1 kHz, 0.9% THD, 8 Ω)
FRONT L/R........................................................................100 W/ch
CENTER .................................................................................100 W
SURROUND L/R...............................................................100 W/ch
[Other models]
(1 kHz, 0.9% THD, 6 Ω)
FRONT L/R........................................................................100 W/ch
CENTER .................................................................................100 W
SURROUND L/R...............................................................100 W/ch
• Dynamic Power (IHF)
[U.S.A. and Canada models]
Front Speakers 8/6/4/2 Ω .................................. 110/130/160/180 W
[Other models]
Front Speakers 6/4/2 Ω ............................................ 105/130/150 W
APPENDIX
• Maximum Useful Output Power (JEITA)
[China, Korea, General and Asia models]
1 kHz, 10% THD, 6 Ω ............................................................ 135 W
• Maximum Output Power [U.K., Europe and Asia models]
1 kHz, 0.7% THD, 4 Ω ........................................................... 120 W
• IEC Output Power [U.K., Europe and Asia models]
Front Speakers 1 kHz, 0.9% THD, 8 Ω .........................95 W+95 W
• Dynamic Headroom [U.S.A. and Canada models]
8 Ω ........................................................................................ 0.23 dB
• Input Sensitivity/Input Impedance
AV5, etc .....................................................................200 mV/47 kΩ
• Maximum Input Voltage
AV5, etc. (1 kHz, 0.5% THD)..................................... 2.3 V or more
• Rated Output Voltage/Output Impedance
AUDIO OUT ............................................................200 mV/1.2 kΩ
SUBWOOFER (2ch Stereo & Front: Small)................1.0 V/1.2 kΩ
• Headphone Jack Rated Output/Impedance
AV5, etc. (1 kHz, 50 mV, 8 Ω)...................................100 mV/470 Ω
• Frequency Response
AV5 to FRONT ..................................... 10 Hz to 100 kHz, +0/-3 dB
• Total Harmonic Distortion
AV5, etc. to FRONT
[U.S.A. and Canada models] (1 kHz, 50 W, 8 Ω)........ 0.06% or less
[Other models] (1 kHz, 50 W, 6 Ω) ............................. 0.06% or less
• Signal to Noise Ratio (IHF-A Network)
AV5, etc. Input Shorted (250 mV to Front Speakers)
................................................................................. 98 dB or more
• Residual Noise (IHF-A Network)
Front Speakers ........................................................... 150 µV or less
• Channel Separation (1 kHz/10 kHz)
AV5, etc. (5.1 kΩ shortened) ...........................60 dB/45 dB or more
• Volume Control ...................................... MUTE / -80 dB to +16.5 dB
• Tone Control (Front Speakers)
BASS Boost/Cut ............................................ ±10 dB/2 dB at 50 Hz
BASS Turnover Frequency .................................................... 350 Hz
TREBLE Boost/Cut ..................................... ±10 dB/2 dB at 20 kHz
TREBLE Turnover Frequency.............................................. 3.5 kHz
• Filter Characteristics (fc=40/60/80/90/100/110/120/160/200 Hz)
H.P.F. (Front, Center, Surround) ....................................... 12 dB/oct.
L.P.F. (Subwoofer) ............................................................ 24 dB/oct.
