Clarion CD-8100USB Service Manual

Cd/usb/mp3 receiver

Advertisement

Quick Links

SPECIFICATIONS

Radio section
Tuning system:
PLL synthesizer tuner
Receiving frequencies:
FM: 87.5 to 108 MHz (0.05 MHz steps)
MW: 522 to 1620 kHz (9 kHz steps)
CD
System:
Compact disc digital audio system
Frequency response:
10 Hz to 20 kHz (+3/-3 dB)
Signal to noise ratio:
70 dB (1 kHz) IFH - A
DynamicRange:
70 dB (1 kHz)
Distortion:
0.01%
MP3
Decode Format
MPEG 1
Sampling rate (kHz):
MPEG-1:32, 44.1, 48
Bit-rate (kbps):
64, 80, 96, 112, 128, 144, 160,
192, 224, 256, 320, VBR
CD-ROM Format:
ISO9660 Level 1, 2, Romeo and Joliet
Folder Level Limit:
No limitation
Folder Support:
128
File Support:
254
Folder Name:
Maximum 16 characters
File Name:
Maximum 28 characters
USB Section
USB 1.1 and 2.0 (same speed 1.1) are compatible.
Common MP3 USB and SD/MMC
Decode Format:
MPEG 1
Sampling rate (kHz):
MPEG-1: 32, 44.1, 48
Bit-rate (kbps):
64, 80, 96, 112, 128, 144, 160,
192, 224, 256, 320, VBR
Folder Support:
128
File Support:
254
Folder Name:
Maximum 16 characters
File Name:
Maximum 28 characters
General
Max power output
40 W x 4
Power supply voltage:
13.8 V DC (11V to 14V allowable),
negative ground
Power consumption:
Less than 15 A
Speaker impedance:
4ohm (4ohm to 8ohm allowable)
Auto antenna rated current:
Weight:
1.1 kg
Dimensions:
178(W) x 50(H) x 152(D)mm
COMPONENTS
1.
Main unit
2.
Mounting bracket
3.
DCP case
4.
Escutcheon(OUT-ES)
5.
Extension lead
6.
Removal Key
NOTE
* Specifi cations and design are subject to change without notice
for further improvement.
Xiamen Clarion Electrical Enterprise Co., Ltd
8/F., Xiamen Mail Processing Centre, No.275 Lujiang Road, Xiamen, China
Tel:+86-592-2389080 Fax:+86-592-2389089
Clarion Co., Ltd.
50 Kamitoda, Toda-shi, Saitama 335-8511 Japan
500 mA or less
——————
6500SM688260000
0790SM8558510
6000SM885500600
375JI4161000000
6500SM885300000

Service Manual

CD/USB/MP3 Receiver
CD8100USB
Model
TO ENGINEERS IN CHARGE OF REPAIR
OR ISPECTION OF OUR PRODUCTS
Before repair or inspection, make sure to follow the
instructions so that customers and Engineers in charge
of repair or inspection can avoid suffering any risk
or injury.
1. Use specifi ed parts.
The system uses parts with special safety features
against fi re and voltage. Use only parts with equivalent
characteristics when replacing them.
The use of unspecifi ed parts shall be regarded as remo-
deling for which we shall not be liable. The onus of pro-
duct liability(PL) shall not be our responsibility in cases
where an accident or failure is as a result of unspecifi ed
parts being used.
2. Place the parts and wiring back in their original p-osi-
tions after replacement or re-wiring.
For
proper
insulationtubes,bonding, gaps to PWB, etc, is involved.
The wiring connection and routing to the PWB are spe-
cially planned using clamps to keep away from heated
and high voltage parts. Ensure that they are placed back
in their original positions after repair or inspection.If ex-
tended damage is caused due to negligence during re-
pair, the legal responsibility shall be with the repairing
company.
3. Check for safety after repair.
Check that the screws, parts and wires are put b-ack
securely in their original position after repair. Ensure for
safety reasons there is no possibility of secondary pro-
blems around the repaired spots.
If extended damage is caused due to negligence of re-
pair, the legal responsibility shall be with the repairing
company.
4. Caution in removal and making wiring connection to the
parts for the automobile.
Disconnect the battery terminal after turning the ignition
key off. If wrong wiring connections are made with the
battery connected, a short circuit and/or fi re may occur.
1
If extensive damage is caused due to negligence of re-
1
pair, the legal responsibility shall be with the repairing
company.
1
5. Cautions regarding chips.
1
Do not reuse removed chips even when no abnormality is
1
observed in their appearance. Always replace them with
1
new ones. (The chip parts include resistors, capacitors,
diodes, transistors, etc). The negative pole of tantalum
capacitors is highly susceptible to heat, so use special
care when replacing them and check the operation afte-
rwards.
-1-
Published by Service Dept.
298-6500 81-00 (AUG.2008)
Printed in P.R.C.
circuit
construction,
use
CD8100USB
