- Page 1 Owner's manual & Installation manual Pedoman Pemilik & Pemasangan 사용설명서 및 설치설명서 คู ่ ม ื อ ใช้ ง านและคู ่ ม ื อ การติ ด ตั ้ ง CZ205A CD/USB/MP3/WMA RECEIVER PENERIMA CD/USB/MP3/WMA CD/USB/MP3/WMA CD/USB/MP3/WMA CD/MP3/WMA...
-
Page 2: Table Of Contents
• The items listed only show connectivity options and are not included with the unit. • CCA-755: Sold separately. • Optional CCA-750 (iPod cable) also available, but CZ205A doesn't have iPod Video function, so even if connect to the Monitor, CZ205A doesn't playback the video. -
Page 3: Precautions
In the event that trouble arises, never open the case, disassemble the unit, or lubricate the rotating parts. Contact your Clarion dealer or service center. 4. “Made for iPod” and “Made for iPhone” mean that an electronic accessory has... -
Page 4: Front Panel / Generalities
• Do not allow any liquids on the unit from When the memorized data is lost or CAUTION drinks, umbrellas, etc. Doing so may damaged by any chance, Clarion shall damage the internal circuitry. not be liable for any damage. • Do not disassemble or modify the unit in When using the USB memory stick, we •... -
Page 5: Controls
6. Insert the battery in proper direction • Play / Pause Preset station memory 2 (long according to the (+) and (-) polarities. press) 7. Store the battery in a place where children cannot reach to avoid the risk of accident. CZ205A... -
Page 6: Remote Control (Rcx001: Sold Separately)
• Do not use commercially available disc protection sheets or discs equipped with stabilizers, etc. These may damage the disc or cause breakdown of the internal mechanism. CZ205A... -
Page 7: Operations
Press the [MUTE] button on the remote control TAG information by press [DISP] button. radio stations, audio setting, etc. stored in to mute the volume from the unit. memory are cleared. Note Doing the operation above again or adjusting volume will release muting. RESET CZ205A... -
Page 8: Audio Setup
] or [ ] button on the remote BAS-Q: 1.0 / 1.25 / 1.5 / 2.0 CZ205A can store 24 stations in total. control to select preset stations. MID-F: 500 /1.0K / 1.5K /2.5K MID-Q: 0.5 / 0.75 / 1.00 / 1.25... -
Page 9: Cd/Mp3/Wma Operations
Insert a CD into the center of the CD tracks. play may not be possible if the disc is SLOT with label facing up. The CD plays recorded on another format. automatically after loading. CZ205A... -
Page 10: Usb Operations
• Some iPod models do not support this CCA-755 device. Close the cover. “RDM SONG” appears on the LCD to function. Consult your nearest Clarion 3. Operation is the same as MP3/WMA dealer or website to confi rm which models perform random play. -
Page 11: Aux Operations
Replace with a compact disc with no noisy. or warped. scratches. Sound is bad when Condensation may form on the internal power is fi rst turned lens when the car is parked in a Let dry for about 1 hour with power on. humid place. CZ205A... -
Page 12: Error Displays
Input Audio input sensitivity: High: 320mV (at 1V output) Mid: 650mV (at 1V output) Low: 1.3V (at 1V output) (input impedance 10 k or greater) Aux-in level: ≤2V CZ205A... -
Page 13: Installation / Wire Connection Guide
Owner’s manual........... 1 Trim ring ............1 Special screw ..1 Consult your Clarion dealer for details. (M2*5mm,front panel lock) Mounting bracket ......... 1 Screws M5x6 mm Double Sems ....4 2. Fasten the front stopper securely to prevent the source unit from coming loose. - Page 14 Attach the trim ring around the front panel. Take care of the top and bottom of the trim ring and mount it so that all the hooks are locked. 5. Disconnect all the wires. Mounting Bracket • Remove CD mech lock-screw. Bottom CZ205A...
