WPM Touch +2 Box
4.3 Connection of electronically
regulated circulating pumps
Electronically regulated circulating pumps may have high start-
ing currents, which may reduce the service life of the heat
pump manager. In the event of a high or unknown starting cur-
rent value, a coupling relay must be installed. The coupling relay
must be supplied on-site. This is not necessary if the maximum
permissible operating current of the heat pump manager (see
information in electrical documentation) is not exceeded by the
electronically regulated circulating pump or a relevant approval
has been issued by the pump manufacturer.
5
Technical device
information
Line voltage
Voltage range
Power consumption
Degree of protection according to EN 60529
Switching capacity of outputs
Switch-off capacity
Operating temperature
Storage temperature
Gewicht / Weight / Poids
Mode of action
Degree of soiling
Heat/fire resistance
Temperature for ball pressure test
www.dimplex.de
HINWEIS
NOTE
The high-efficiency pumps (UPH) are supplied with the rele-
vant coupling relay for connecting and operating the elec-
tronically regulated circulating pump.
CAUTION!
It is not permitted to connect more than one electronically
regulated circulating pump via a relay output.
230 V AC 50 Hz
195 to 253 V AC
Approx. < 50 VA
IP 20
min. 2 A (2 A) cos ( ) = 0.6 LRA = 12 A at 230 V
P1.5 kA
0 °C bis / to / à +35 °C
-15 °C bis / to / à +60 °C
-
Type 1.C
2
Category D
125 °C
452117.66.36-EN · FD 0301
English
