Smeg SC855A-8 Manual

Smeg SC855A-8 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

1.
INSTRUCTIONS FOR USE ......................................................................... 42
2.
SAFETY PRECAUTIONS ............................................................................ 44
3.
ENVIRONMENTAL RESPONSIBILITY ........................................................ 46
4.
GET TO KNOW YOUR OVEN...................................................................... 47
5.
AVAILABLE ACCESSORIES ....................................................................... 48
6.
USING THE OVEN ...................................................................................... 51
7.
COOKING WITH THE OVEN....................................................................... 56
8.
CLEANING AND MAINTENANCE ............................................................... 64
9.
EXTRAORDINARY MAINTENANCE ........................................................... 71
10. INSTALLING THE APPLIANCE ................................................................... 75
INSTRUCTIONS FOR THE USER: these instructions contain user
recommendations, a description of the controls and the correct
procedures for cleaning and maintenance of the appliance.
technician who must install the appliance, set it functioning and carry out
an inspection test.
Contents
41

Advertisement

Table of Contents
loading

Related Manuals for Smeg SC855A-8

Summary of Contents for Smeg SC855A-8

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified technician who must install the appliance, set it functioning and carry out an inspection test.

  • Page 2: Instructions For Use

    General instructions 1. INSTRUCTIONS FOR USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. IT MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE APPLIANCE. CAREFUL READING OF THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE APPLIANCE IS ESSENTIAL.

  • Page 3: General Instructions

    FATS AND OILS MAY CATCH FIRE. DO NOT COVER THE BOTTOM OF THE OVEN WITH ALUMINIUM OR TINFOIL SHEETS DURING COOKING AND DO NOT PLACE PANS OR TRAYS ON IT TO AVOID DAMAGE TO THE ENAMELLED SURFACE. IF THE SURFACES ARE STILL VERY HOT DURING COOKING, DO NOT POUR WATER DIRECTLY ONTO THE TRAYS.

  • Page 4: Safety Precautions

    BEFORE CARRYING OUT INSTALLATION/MAINTENANCE WORK, MAKE SURE THAT THE APPLIANCE IS NOT CONNECTED TO THE POWER GRID. THE PLUG TO BE CONNECTED TO THE POWER SUPPLY CABLE AND ITS SOCKET MUST BE OF THE SAME TYPE AND CONFORM TO THE REGULATIONS IN FORCE.
  • Page 5 General instructions DO NOT LET CHILDREN GO NEAR THE APPLIANCE WHEN IT IS IN OPERATION OR PLAY WITH IT AT ANY TIME. DO NOT INSERT POINTED METAL OBJECTS (CUTLERY OR UTENSILS) INTO THE SLITS IN THE APPLIANCE. DO NOT USE STEAM JETS FOR CLEANING THE APPLIANCE.

  • Page 6: Environmental Responsibility

    Therefore, the user must consign the...

  • Page 7: Get To Know Your Oven

    Instructions for the user 4. GET TO KNOW YOUR OVEN Control panel Roof liner Oven light Oven seal Rack and tray support frames (on some models only) Oven fan Pizza plate or cover recess (on some models only) Bottom plate (on some...

  • Page 8: Available Accessories

    NOTE: accessories. Rack: for holding cooking containers. Tray rack: to be placed over the top of the oven tray; for cooking foods which may drip. Oven tray: for collecting fat from foods placed on the rack above. Pizza plate: specially designed for cooking pizza and similar dishes.
  • Page 9 The mechanical lock must always face the back of the oven. Insert racks and trays fully into the oven until they come to a stop. Using the support rack The support rack is inserted into the tray (as shown in the figure).
  • Page 10 If you wish to add oil to your pizza, it is best to add it after removing it from the oven since oil stains on the pizza plate are unsightly and may reduce its efficiency.

  • Page 11: Using The Oven

    6.2.3 Oven inside lights The oven lights come on when the door is opened (depending on model) or any function is selected.
  • Page 12 During cooking, do not cover the bottom of the oven with aluminium or tin foil and do not place pans or oven trays on it as this may damage the enamel coating. If you wish to use greaseproof paper, place it so that it will not interfere with the hot air circulation inside the oven.
  • Page 13 Instructions for the user Description of the controls on the front panel All the appliance's control and monitoring devices are located together on the front panel. OVEN THERMOSTAT KNOB This knob can be used to select the cooking temperature. Turn the knob clockwise to the desired value, between 50°C and 250°C.
  • Page 14 Instructions for the user PROGRAMMING CLOCK The programming clock can be used to display the current time or to set a timer (only on multifunction models) or cooking programme (only for pyrolytic models). FUNCTION KNOB Turn the knob clockwise or anti-...
  • Page 15 To use the oven with manual cooking, turn knob C clockwise until the A pointer is aligned with the symbol 6.5.3 Timed cooking To set the cooking time, turn knob C clockwise until the A pointer is aligned with the required time (maximum 180 minutes). 6.5.4 End of cooking The oven will switch off automatically and simultaneously a buzzer will start to sound.

  • Page 16: Cooking With The Oven

    STATIC: As the heat comes from above and below at the same time, this system is particularly suitable for certain types of food. Traditional cooking, also known as static or thermal radiation cooking, is suitable for cooking just one dish at a time.
  • Page 17 FAN-ASSISTED GRILL: The air produced by the fan softens the strong heatwave generated by the grill, giving perfect grilling results even with very thick foods. Perfect for large cuts of meat (e.g. shin of pork). We recommend using the 4 runner.
  • Page 18 We recommend using a meat thermometer for meat when roasting it. Alternatively, simply press on the roast with a spoon: if it is hard, it is ready; if not, it needs another few minutes cooking.
  • Page 19 When defrosting meat, we recommend using a rack positioned on the second runner with the food on it and a tray positioned on the first runner. In this way, the liquid from the defrosting food drains away from the food.
  • Page 20 Instructions for the user Cooking process information table DISHES WEIGHT FUNCTION FIRST COURSES LASAGNE 3 kg Static OVEN-BAKED PASTA Static MEAT ROAST VEAL 1 kg Fan-assisted static LOIN OF PORK 1 kg Fan-assisted static SHOULDER OF PORK 1 kg Turbo / Circular...
  • Page 21 Instructions for the user RUNNER POSITION TEMPERATURE TIME IN MINUTES FROM BOTTOM °C 2 or 3 220 - 230 40 - 50 2 or 3 220 - 230 180 - 190 70 - 80 180 - 190 70 - 80...
  • Page 22 Turbo / Circular RICE PUDDING Static CROISSANTS Circular APPLE PIE Static CROISSANTS (on multiple runners) SHORT PASTRY BISCUITS (on multiple runners) The times indicated in the following tables do not include the preheating times and are provided as a guide only.
  • Page 23 50 - 60 25 - 30 2 and 4 160 - 170 16 - 20 2 and 4 160 - 170 16 - 20 For cooking on multiple runners, we recommend that you use functions only, and the 2 and 4 runners.

  • Page 24: Cleaning And Maintenance

    To clean and preserve the stainless steel surfaces, always use only specific products that do not contain abrasives or chlorine-based acids. How to use: pour the product onto a damp cloth and wipe the surface, rinse thoroughly and dry with a soft cloth or a microfibre cloth.
  • Page 25 The oven should be operated at the maximum temperature for about 15-20 minutes after the use of specific products, to burn off the residues left inside the oven. On pizza models only, to clean the bottom of the oven, the following operations...
  • Page 26 When the operation is complete, damp parts should be dried thoroughly. 8.5.1 Removing guide frames Removing the guide frames makes it easier to...
  • Page 27 Multifunction models: the stone must be cleaned after every use. Do not heat it again if it has any encrustations. To clean, pour 55 cc of vinegar onto the stone, leave it to act for 10 minutes, then remove it by wiping with a metallic mesh or abrasive sponge.
  • Page 28 VAPOR CLEAN is an assisted cleaning procedure which facilitates the removal of grease and oily residues. Thanks to this process, it is possible to clean the inside of the oven very easily. The dirt residues are softened by the heat and water vapour for easier removal afterwards.
  • Page 29 (the coloured zone on the figure to the side shows where the solution can be sprayed). Do not spray excessive amounts of the water and washing up liquid solution. We recommend spraying approx. 20 times at the most. •...
  • Page 30 Vapor Clean function; • set a cooking time of 15 minutes using the timer control knob; At the end of the assisted cleaning cycle, the timer will deactivate the oven heating elements. 8.7.3 End of the assisted cleaning cycle The water remaining at the end of the assisted cleaning cycle cannot be left inside the oven for long (for example overnight).

  • Page 31: Extraordinary Maintenance

    Replace the bulb with one of the same type (25W). Replace cover correctly, so that the moulded part of the glass is facing the door. Press the cover down as far as it will go so that it attaches completely to the bulb support.
  • Page 32 9.2.1 With pins Open the door completely. Insert two pins into the holes indicated A in the two hinges towards the back of them until they engage. Grasp the door on both sides with both hands, lift it forming an angle of around 30°...
  • Page 33 The glass in the door should always be kept thoroughly clean. To facilitate cleaning, it is possible to remove the door (see 9.2 Removing the door) and place it on a canvas, or open it and lock the hinges in order to extract the glass panels.
  • Page 34 Replace the panels in the reverse of the order in which they were removed. • Reposition the internal glass panel, taking care to centre and insert the 4 pins attached to the glass into their slots in the oven door by applying slight pressure.

  • Page 35: Installing The Appliance

    The appliance must be connected to earth in compliance with electrical system safety regulations. If a fixed connection is being used, fit the power line with an omnipolar circuit- breaker in accordance with the installation rules, located in a position which is easy to reach and near the appliance.

  • Page 36: Cable Replacement

    35-40 mm deep. Remove the screw covers on the frame and screw in the 2 screws A (fig. 5) to fix the appliance to the unit. Replace the screw covers. For installing beneath a countertop hob, allow for a rear and bottom clearance as shown in figure 1 (ref.

  • Page 37: Instructions For The Installer

    Instructions for the installer FIG.1 Measurements 583 ÷ 585 554 ÷ 564 490 ÷ 500 560 min. 35 ÷ 40 (mm)
  • Page 38 Instructions for the installer FIG. 2 FIG. 3 FIG. 4 FIG. 5...
