- Page 1 V660p-A Installation Guide Verifone Part Number: DOC572-002-EN-A, Revision A00 www.verifone.com...
- Page 2 The information contained in this document is subject to change without notice. Although Verifone has attempted to ensure the accuracy of the contents of this document, Verifone shall not be liable for technical or editorial errors or omissions contained herein. Verifone and the Verifone logo are registered trademarks of Verifone.
-
Page 3: Table Of Contents
V660p-A Transactions ........ - Page 4 V660p-A Wi-Fi/BT Support ........
- Page 5 Checking CTLS Reader ......... . . 36 © VeriFone, Inc. All rights reserved.
-
Page 6: Audience
Troubleshooting Guidelines - Provides guidance for addressing issues that may arise during device installation. Related Documentation To learn more about the V660p-A, refer to the following document associated with the Verifone Part Number (VPN). V660p-A Quick Installation Guide VPN DOC572-001-EN-A... -
Page 7: Conventions
The lightning symbol is used as a For safety, do not string cables or warning when a bodily injury might cords across a walkway. occur. © VeriFone, Inc. All rights reserved. -
Page 8: Features And Benefits
V660p-A 1. Device Overview This chapter provides an overview of the V660p-A device: The Verifone V660p-A NEO device is a new generation handheld Android device with exceptional capabilities. The best-in-class consumer-facing device is offered with cellular/Wi-Fi/Bluetooth to provide mobile payment... -
Page 9: Compliance
Complies with PCI-PTS v6 requirements standards, ensuring secure solutions for approval class PED devices. • Adheres to ISO and ANSI standards for PIN encryption, key management, and MAC. • Simplifies and secures key injection through Verifone's Secure Kit key-loading software. © VeriFone, Inc. All rights reserved. -
Page 10: Contactless Capability
• Equipped with dual-band Wi-Fi for enhanced connectivity options. Connectivity • Multiple connectivity options, including 4G LTE and Wi-Fi, as well as Bluetooth. Options • Wired connectivity includes USB-C to USB-A. © VeriFone, Inc. All rights reserved. -
Page 11: Safety Instructions
Installation Guide V660p-A 2. Device Setup This section outlines the setup procedures for the V660p-A device, covering the following segments: • Safety Instructions • Periodic Inspection • Environmental Factors • PIN Protection Measures • Inside the Shipping Carton • Inspecting the Features of the Unit •... -
Page 12: Periodic Inspection
Position in-store security cameras so that the PIN-entry keypad is not visible. Inside the Upon opening the shipping carton, meticulously examine its contents for any signs of tampering or shipping damage. Shipping Carton To Unpack the Unpacking Instructions: Shipping Carton Thoroughly examine the shipping carton. © VeriFone, Inc. All rights reserved. - Page 13 Lift and extract the inner carton box from the outer carton box once the tape is removed. Unfold the inner carton box. Conduct a detailed inspection of the shipping carton contents. The carton box includes the following components as part of the V660p-A product: • V660p-A unit •...
-
Page 14: Inspecting The Features Of The Unit
Figure the Unit Figure: 1 V660p-A The Verifone V660p-A device provides the following features: A colored touch screen display for user interaction. A smart card reader integrated into the front of the device to process smart card-based debit or credit transactions. Refer to the instructions in "... -
Page 15: Installing Micro Sim And Or Sam Cards
Figure: 2 Removing Battery Cover Installing Micro To install a SIM (Subscriber Identity Module) and/or SAM (Security Access Module) card in the V660p-A device, follow these steps: SIM and or SAM Cards Follow the steps in " ." Removing the Battery Cover... - Page 16 Insert the SIM and/or SAM card with the gold contacts facing down as shown Figure 4 Figure: 4 SIM/SAM Insertion Turn the battery back into the compartment and place it in the slot as shown in Figure 5 Figure: 5 Placing the Battery Back © VeriFone, Inc. All rights reserved.
-
Page 17: Battery Management
After unpacking the device, connect the power pack to the unit. Allow the device to charge for eight hours or until fully charged. The battery in the V660p-A device is equipped with a safety circuit to safeguard the Li-ion cells from overcharging and over-discharging. If the battery becomes over-discharged, the safety circuit will shut down the battery, and it must be recharged to restore operation. -
Page 18: Using The Battery
Faites preuve de prudence pour éviter toute perte involontaire de données de transaction lors d'actions liées à l'alimentation. Using the Battery The V660p-A device utilizes a dual-cell Li-ion battery with the following features: • The battery incorporates a safety circuit that prevents damage from overcharge, over-discharge, or overheating. -
Page 19: Battery Life
Li-ion batteries are not affected by shallow charging. To ensure optimal function, follow these best practices: • Conserve battery power by turning off the V660p-A device when not in use. • Keep the Li-ion battery inserted in the device and power up the device periodically to check the battery charge. -
Page 20: Charging The Battery Via Power Pack
Battery Via Power pack Insert the USB-C plug into the USB-C port of the V660p-A device. Plug the AC power pack into a wall outlet or a powered surge protector. This procedure ensures a direct connection between the device and the power source, allowing the battery to charge. -
Page 21: Connecting To A Pc
Ensure a secure connection and proper alignment. Power on the V660p-A using the designated power switch, if applicable. This ensures the proper power supply connection for the V660p-A. Using an incorrectly rated power supply can damage the unit or cause it to malfunction. -
Page 22: V660P-A Transactions
Wait for the application to signal a completed transaction before removing the card. Note that premature card removal may invalidate the transaction. EMV transactions support both credit and debit card transactions using the specified procedure. © VeriFone, Inc. All rights reserved. -
Page 23: V660P-A Wi-Fi/Bt Support
Contactless Reader icon. V660p-A Wi- The V660p-A device is equipped with an integrated WLAN RF (Wireless Local Area Network Radio Frequency) transceiver for Wireless LAN systems Fi/BT Support © VeriFone, Inc. All rights reserved. -
Page 24: Loading A Printer Paper
• Un papier de mauvaise qualité peut provoquer des bourrages dans l'imprimante et générer une poussière de papier excessive. Pour acheter du papier Verifone de haute qualité, reportez-vous à la section Accessoires et documentation. • Assurez-vous que le papier thermique est stocké dans un endroit sec et sombre. -
Page 25: Camera/Qr Code Reader
Install a Paper Roll in the V660p-A Camera/QR The V660p-A device features a primary camera boasting 5MP CMOS autofocus and a front-facing camera equipped with 2MP CMOS fixed focus. Code Reader Additionally, it expands the functionality of countertop devices by incorporating barcode and QR scanning capabilities. -
Page 26: Unit Power Requirement
Installation Guide V660p-A 3. Specifications This chapter provides details on the power requirements, dimensions, and additional specifications of the V660p-A device. Unit Power • AC 100V-240V/50-60Hz/0.5A Input power rating: Requirement • DC 5V/2.2A Output: • 2500mAh/7.3V Li-ion rechargeable battery: Temperature •... -
Page 27: Magnetic Stripe Card
Latin America): • GSM 850/900/1800/1900 MHz • WCDMA B1/2/4/5/8 • LTE-FDD: B1/2/3/4/5/7/8/20/28/66/38/40/41 North America (NA): • WCDMA B2/4/5 • LTE-FDD: B2/4/5/7/12/13/14/17/25/26/66/71/41 Camera • 2 MP (Front QR/Barcode Scanner) • Rear camera - 2 MP © VeriFone, Inc. All rights reserved. -
Page 28: Printer
Installation Guide V660p-A • Front-facing camera - 0.3 MP • LED torch Printer • High-speed thermal printer: 30 lps • Paper roll: maximum 40 mm diameter © VeriFone, Inc. All rights reserved. -
Page 29: General Care
Verifone authorized service provider for maintenance or replacement. Cleaning & Verifone devices should only be gently cleaned to remove dirt, residue, or debris using a lightly water-damped, clean microfiber cloth. One or two Sanitizing drops of pH-neutral, non-scrubbing soap may be used. -
Page 30: Cleaning Instructions
Installation Guide V660p-A Cleaning Turn off your device. Instructions Disconnect it from the power source. Clean it following the instructions and guidelines as mentioned above. Once completely dry, reconnect to power up. © VeriFone, Inc. All rights reserved. -
Page 31: Returning A Device For Service
Il est conseillé aux clients en dehors des États-Unis de contacter leur Verifone local représentant pour obtenir de l'aide concernant l'entretien, le retour ou le remplacement des appareils Et accessoires. - Page 32 • Reference the model and part number in the Note box. Each V660p-A returned to Verifone requires a distinct MRA number to be issued. Even if you are returning multiple terminals of the same model, ensure that a separate MRA number is issued for each unit.
-
Page 33: Connecting Cable
V660p-A 6. Accessories and Cables Verifone provides a range of accessories and documentation for the V660p-A. When placing orders, it is essential to reference the specific part numbers. Here are the available channels for ordering: Verifone online store: • Verifone - https://www.verifone.com/en/us/contact-us... - Page 34 Utilizing services from unauthorized parties may potentially void any existing warranty. All units require the use of a power supply. Only use a Verifone-supplied power pack. Using an incorrectly rated power supply may damage the unit or cause it to malfunction. Ensure that the power supply used to power the unit matches...
-
Page 35: Device Does Not Start/Does Not Display Correct Readable Information
Verify all the cable connections including the proper insertion of the power Correct cable connector. Readable • If the problem persists, reach out to your local Verifone representative for Information assistance. Blank Display When the device display is blank: •... - Page 36 Installation Guide V660p-A If the issue persists, get in touch with your local Verifone representative. Checking CTLS To check the CTLS reader: Make sure there are no obstructions between the contactless logo and the Reader card, ensuring a clear path between the contactless reader and the actual card for a seamless transaction.
- Page 37 As commerce experts, we are here for you and your business. With our payment devices, our systems & solutions and our support. Everywhere. Anytime. So that your customers feel enabled, recognized and well taken care of, even beyond their expectations. Verifone. Creating omni-commerce solutions that simply shape powerful customer experiences.
