USER'S GUIDE
MODEL – 40L30N
All information included in this publication is based on the latest information available
at the time of printing. Pentair reserves the right to make changes at any time without
notice and without incurring any obligation whatsoever. Photocopying of this
publication by authorized original equipment manufacturers who have purchased
directly from Pentair, or by persons using the materials for legitimate educational
purposes, is approved by Pentair. Otherwise all copyright protection afforded by the
law applies.
Product Bulletin – 98603 -Rev. B
EcoLine
Goa, India. Phone: 91-832-6754400 Fax: 91-832-6754412
www.codeline.com
ECN No. 6139 Revision dated – 09/06/2023
Page 1 of 11
Advertisement
Related Manuals for Pentair EcoLine 40L30N
Summary of Contents for Pentair EcoLine 40L30N
- Page 1 MODEL – 40L30N All information included in this publication is based on the latest information available at the time of printing. Pentair reserves the right to make changes at any time without notice and without incurring any obligation whatsoever. Photocopying of this...
- Page 2 DANGER – HIGH PRESSURE DEVICE This vessel may cause loss of life, severe bodily harm, or property damage if not correctly installed, operated and maintained. Read and understand all guidelines given in this bulleting before attempting to open, operate or service this vessel. Failure to follow these guidelines and observe every precaution will result in malfunction and could result in catastrophic failure.
-
Page 3: Installation
INSTALLATION Regardless of when or by whom your vessel may have been installed, there are a few quick checks you should make before use. Check that each vessel is: • Mounted with compliant material (Polyurethane saddle) between the fiberglass shell and any rigid frame. - Page 4 OPENING THE VESSEL WARNING Remove the Retaining Ring from the groove Relieve pressure from vessel – before beginning this procedure. 1. No Special tools are required for this Contamination Removal operation. Engage you fore finger in the Metal oxidation products and mineral end tab of the retaining ring, lift it up and deposits interfere...
- Page 5 OPENING THE VESSEL (CONTD…) Removing Head Assembly – 1. Using a mallet, tap the head assembly lightly. Do not use a metal component to tap the head assembly. 2. Thread a ½” O.D. Engineering Thermoplastic pipe approximately 1 feet long into the permeate port.
- Page 6 Where vessel bore. conflicts exist, contact element manufacturer Pentair Water clarification. Removing Elements 1. Remove heads from both ends of vessels as described in Opening the Vessel. Push element out of vessel from the upstream end.
- Page 7 REPLACING ELEMENTS & CLOSING THE VESSEL (CONTD…) 7. Lubricate element seals sparingly with the element manufacturers recommended lubricant or with glycerin. 8. Insert each element with the brine seal (typically a U-cup seat) installed on the upstream end with its lip facing upstream. CAUTION System malfunctions and element damage may result if elements are installed in the wrong direction.
-
Page 8: Head Disassembly
HEAD DISASSEMBLY NOTE Head Rebuilding should be performed in a clean work area. Dust or dirt on O- rings or other parts can scratch inner surfaces, with subsequent leakage. Use a small screw driver or similar tool 1. Using a small screwdriver or similar tool remove the PWT seal from the grove remove the Plug Seal. -
Page 9: Head Assembly
HEAD ASSEMBLY 1. Use only head components in as-new condition. Use new O-rings each time the head is assembled. 2. Cover O-rings with a this even layer of Parker Super O-Lube silicone lubricant or the lubricant recommended by your element supplier. Lubricating Plug seals and O-rings NOTE Glycerin is a commercially available lubricant that will not foul elements. -
Page 10: Warranty
: Use of components damaged by corrosion can cause catastrophic failure. 3. Seals should be replaced as necessary each time the vessel is serviced. Any parts that need to be replaced are available from your supplier or from Pentair. NOTE... - Page 11 Page 11 of 11...
