- Page 1 No.19S207-00 GigE Vision Monochrome / Color CMOS PoE Camera STC-MBS122BPOE Monochrome (12M / STC-MCS122BPOE Color (12M / Product Specifications and User’s Guide STC-MBS122BPOE / STC-MCS122BPOE 1/73 Product Specifications and User’s Guide...
-
Page 2: Table Of Contents
Product Number Naming Method ..................10 Specifications ...................... 11 Electronic Specifications ....................... 11 Spectral Sensitivity Characteristics ..................13 STC-MBS122BPOE ......................... 13 STC-MCS122BPOE (without IR Cut Filter) ..................13 IR Cut Filter (STC-MCS122BPOE) ....................14 Mechanical Specifications ..................... 14 Environmental Specifications ....................15 Connector Specifications .................. - Page 3 No.19S207-00 Dimensions ......................26 STC-MBS122BPOE ......................... 26 STC-MCS122BPOE ......................... 27 Sensor Information .................... 28 Pixel Transferring Image ......................28 Camera Operational Modes ................29 Normal Mode ........................... 29 Pulse width trigger mode....................... 30 Timing .............................. 30 Exposure Timing with Positive Polarity Trigger Signal ..............31 Exposure Timing with Negative Polarity Trigger Signal ...............
- Page 4 Chunk Control ........................56 10.20 Action Control ........................56 10.21 IEEE1588 ........................... 57 GenICam command .................... 59 11.1 DeviceControl ........................59 11.2 ImageFormatControl ......................61 11.3 AcquisitionControl ......................62 11.4 AnalogControl ........................63 STC-MBS122BPOE / STC-MCS122BPOE 4/73 Product Specifications and User’s Guide...
- Page 5 11.11 EventControl ........................67 11.12 UserSetControl ........................67 11.13 ChunkDataControl ....................... 68 11.14 ActionControl ........................68 11.15 FileAccessControl ....................... 69 11.16 TestControl .......................... 69 11.17 TransportLayerControl ....................... 70 12 Revision History ....................72 STC-MBS122BPOE / STC-MCS122BPOE 5/73 Product Specifications and User’s Guide...
- Page 6 Do not use with out of power voltage range Do not wrong wiring. that is specified in the specifications for this This will cause of fire or malfunction. camera. This will cause of fire, electrification or malfunction. STC-MBS122BPOE / STC-MCS122BPOE 6/73 Product Specifications and User’s Guide...
- Page 7 It is turn off the camera when maintaining or This will cause of fire, electrification or inspecting the camera. malfunction. This will cause of electrification. [Disposal] Caution It is necessary to dispose as industrial waste. STC-MBS122BPOE / STC-MCS122BPOE 7/73 Product Specifications and User’s Guide...
-
Page 8: Product Precautions
Exchange or repair the malfunction camera if the malfunction is occurred by our responsibility. “Warranty” mean is warranty for the delivered camera itself. Please accept the induction damage by the camera malfunction is not included. STC-MBS122BPOE / STC-MCS122BPOE 8/73 Product Specifications and User’s Guide... -
Page 9: Software Licensing
BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. STC-MBS122BPOE / STC-MCS122BPOE 9/73 Product Specifications and User’s Guide... -
Page 10: Overview
No.19S207-00 Overview This document describes the specification of the following cameras: STC-MBS122BPOE / STC-MCS122BPOE Features GigE Interface Support PoE (Power over Ethernet) Small robust camera housing Maximum frame rate (Full resolution): 8.9 fps @ 12M 8bits ... -
Page 11: Specifications
Input Voltage (*2) +10.8 to +26.4 Vdc External power (via 6 pin connector) / Power Over Ethernet (IEEE802.3af) Consumption +12 V / +24 V: 4.1 W, PoE: 4.4 W Default: Bold STC-MBS122BPOE / STC-MCS122BPOE 11/73 Product Specifications and User’s Guide... - Page 12 Black Level Optimum Target Luminance IM-600 (Topcon) Gamma Factory Setting (*2) The camera operates with external power when power suppling by external power supply and PoE to camera at same time. STC-MBS122BPOE / STC-MCS122BPOE 12/73 Product Specifications and User’s Guide...
-
Page 13: Spectral Sensitivity Characteristics
No.19S207-00 Spectral Sensitivity Characteristics STC-MBS122BPOE STC-MCS122BPOE (without IR Cut Filter) STC-MBS122BPOE / STC-MCS122BPOE 13/73 Product Specifications and User’s Guide... -
Page 14: Ir Cut Filter (Stc-Mcs122Bpoe)
Ethernet connector: RJ45 connector Power- I/O connector: HR10A-7R-6PB (Hirose) or equivalent Camera Mounting Eight M4 screw holes (Four on top and bottom plates) Weight Approximately 100 g (*1) Excluding the connectors STC-MBS122BPOE / STC-MCS122BPOE 14/73 Product Specifications and User’s Guide... -
Page 15: Environmental Specifications
75 deg. C, the camera housing temperature (top plate) will be less than 63 deg. C. Taking these steps will maintain the heat rating of the electronic components of the camera. Upper side of camera Measuring point STC-MBS122BPOE / STC-MCS122BPOE 15/73 Product Specifications and User’s Guide... -
Page 16: Connector Specifications
Yellow light: Blinking 1 GB Transferring 100 MB Transferring Please use a 1GB supported NIC, Network Switcher and Ethernet cable. Check the setting of NIC and Network Switcher being used is “1GB transferring”. STC-MBS122BPOE / STC-MCS122BPOE 16/73 Product Specifications and User’s Guide... -
Page 17: Power And Control Signal Connector
8) Debounced Line 2 9) User Output 1 10) User Output 2 11) Timer 0 Active 12) Software Signal 0 13) Software Signal 1 14) Logic Block 0 15) Pulse Per Second STC-MBS122BPOE / STC-MCS122BPOE 17/73 Product Specifications and User’s Guide... - Page 18 Selected signal for “Software Signal 1” at “Software Signal Control” is out. 14) Logic Block 0 “Logic Block 0” signal is out. 15) Pulse Per Second “Pulse / second” signal (50% Duty, 1 Hz interval) is out. STC-MBS122BPOE / STC-MCS122BPOE 18/73 Product Specifications and User’s Guide...
-
Page 19: Opto-Isolated Input
The camera has current limiting circuit on camera. The current limiting resistor does not necessary. Opto-isolated output It is necessary to have current limiting resistor at outside of camera, to keep less than 50 mA. STC-MBS122BPOE / STC-MCS122BPOE 19/73 Product Specifications and User’s Guide... -
Page 20: Open Collector Gpio
The camera inside circuit may get damage if accidentally uses as output without current limiting resistor. For safety, please add current limiting resistor even use as input. a) Open Collector GPIO uses as output b) Open Collector GIPO uses as input STC-MBS122BPOE / STC-MCS122BPOE 20/73 Product Specifications and User’s Guide... -
Page 21: Input And Output Signal Timing (Hardware Trigger)
ExposureActive DebounceLine0, 2 FramTriggerInternal SensorReadOut Timer0 Parameter TimerDelay on GenICam Parameter TimerDuration on GenICam (*1) Please refers “5.2.6 External Hardware Trigger Input Delay” for more details about “External hardware trigger delay” STC-MBS122BPOE / STC-MCS122BPOE 21/73 Product Specifications and User’s Guide... -
Page 22: Input And Output Signal Timing (Software Trigger)
Camera internal processing Software trigger Parameter TriggerDelay on GenICam Trigger delay Exposure Parameter ExposureTime on GenICam Image out Output signals FrameTriggerWait ExposureActive FramTriggerInternal SensorReadOut Timer0 Parameter TimerDelay on GenICam Parameter TimerDuration on GenICam STC-MBS122BPOE / STC-MCS122BPOE 22/73 Product Specifications and User’s Guide... -
Page 23: External Hardware Trigger Input Delay
External Trigger Signal External Trigger Signal with camera internal delay Tdelay 6.2.6.2 External Trigger Signal Delay (Negative polarity trigger signal) External Trigger Signal External Trigger Signal with camera internal delay Tdelay STC-MBS122BPOE / STC-MCS122BPOE 23/73 Product Specifications and User’s Guide... -
Page 24: Measured External Trigger Signal Delay Through Opt-Isolated Port (Line 0)
2 μseconds +24 V 53.2 μseconds 2 μseconds Note. Please use this measured delay as reference. The delay time may fluctuate depending on photo coupler variation, pull-up voltage and pull-up resister. STC-MBS122BPOE / STC-MCS122BPOE 24/73 Product Specifications and User’s Guide... -
Page 25: Measured External Trigger Signal Delay Through Open Collector Gpio Port (Line 2)
2.2 μseconds 2 μseconds +24 V 0.8 μseconds 2 μseconds Note. Please use this measured delay as reference. The delay time may fluctuate depending on transistor variation, pull-up voltage and pull-up resister. STC-MBS122BPOE / STC-MCS122BPOE 25/73 Product Specifications and User’s Guide... -
Page 26: Dimensions
No.19S207-00 Dimensions STC-MBS122BPOE Top and bottom plates are same design 4-M4 depth4 Right and left plates are same design 14.5 50.5 54.5 1”-32UNF (C mount) 43.5 Unit: mm STC-MBS122BPOE / STC-MCS122BPOE 26/73 Product Specifications and User’s Guide... -
Page 27: Stc-Mcs122Bpoe
No.19S207-00 STC-MCS122BPOE Top and bottom plates are same design Right and left plates are same design 4-M4 depth4 14.5 50.5 54.5 1”-32UNF (C mount) 43.5 Unit: mm STC-MBS122BPOE / STC-MCS122BPOE 27/73 Product Specifications and User’s Guide... -
Page 28: Sensor Information
Pixel (m) of Data: mth pixel being transferred STC-MCS122BPOE (Color) Pixel 11 Pixel 21 of Data of Data Pixel 12 Pixel 22 of Data of Data Pixel (m, n) of Data: mth pixel of nth line being transferred STC-MBS122BPOE / STC-MCS122BPOE 28/73 Product Specifications and User’s Guide... -
Page 29: Camera Operational Modes
No.19S207-00 Camera Operational Modes Normal Mode Exposure Time Expose Image out * The exposure time for each line is same. STC-MBS122BPOE / STC-MCS122BPOE 29/73 Product Specifications and User’s Guide... -
Page 30: Pulse Width Trigger Mode
The expose period is low states of trigger signal. Timing Trigger signal (Positive polarity) Expose Image out Note: The exposure time is active pulse duration of trigger signal. Please refers “Exposure Timing” for more details. STC-MBS122BPOE / STC-MCS122BPOE 30/73 Product Specifications and User’s Guide... -
Page 31: Exposure Timing With Positive Polarity Trigger Signal
Note 2: Please refers “5.2.6 External Hardware Trigger Input Delay” for more details about “External hardware trigger delay”. Note 3: Please refers “5.2.6 External Hardware Trigger Input Delay” for shortest active pulse duration of trigger signal. STC-MBS122BPOE / STC-MCS122BPOE 31/73 Product Specifications and User’s Guide... -
Page 32: Exposure Timing With Negative Polarity Trigger Signal
Note 2: Please refers “5.2.6 External Hardware Trigger Input Delay” for more details about “External hardware trigger delay”. Note 3: Please refers “5.2.6 External Hardware Trigger Input Delay” for shortest active pulse duration of trigger signal. STC-MBS122BPOE / STC-MCS122BPOE 32/73 Product Specifications and User’s Guide... -
Page 33: Edge Preset Trigger Mode
In this trigger mode with negative polarity, the expose starts at falling edge of trigger signal. The exposure duration time is based on preset exposure setting stored by camera setting communication. Timing Trigger signal (Positive polarity) Expose Image out Note: The exposure time is “Exposure Time” on GenICam setting. STC-MBS122BPOE / STC-MCS122BPOE 33/73 Product Specifications and User’s Guide... -
Page 34: Exposure Timing With Positive Polarity Trigger Signal
“Line Debounce Time” setting time. Please input trigger signal has more than “Line Debounce Time” time active pulse width trigger signal. Note 2: Please refers “5.2.6 External Hardware Trigger Input Delay” for more details about “External hardware trigger delay”. STC-MBS122BPOE / STC-MCS122BPOE 34/73 Product Specifications and User’s Guide... -
Page 35: Edge Preset Trigger Mode (Trigger Input While Image Is Out)
However, if the trigger signal input while exposing with previous trigger signal or output image, trigger signal is disregard. Timing Trigger signal (Positive polarity) Expose Image out Note: The exposure time is “Exposure Time” on GenICam setting. STC-MBS122BPOE / STC-MCS122BPOE 35/73 Product Specifications and User’s Guide... -
Page 36: 10 Camera Functions
ROM that is selected at Settings “UserSetSelector”. Caution: Default Selector “UserSetSave” CANNOT execute when “Default” was selected at “UserSetSelector” UserSetSelector Setting Procedure 1. Selects “UserSet X” at “UserSetSelector” 2. Execute “UserSetSave” STC-MBS122BPOE / STC-MCS122BPOE 36/73 Product Specifications and User’s Guide... -
Page 37: Loading Camera Settings
Camera Settings Initialization Please follow the procedure in below for camera settings put back to factory default settings. Setting Procedure Selects “Default” at “UserSetSelector”. Executes “UserSetLoad”. Select “UserSet X” at “UserSetSelector”. Executes “UserSetSave”. STC-MBS122BPOE / STC-MCS122BPOE 37/73 Product Specifications and User’s Guide... -
Page 38: Frame Rate
IEnumeration Type Selects control gain DigitalAll: Digital Gain DigitalGain IFloat Type Digital Gain Range: 0 to 255 Default: 0 Digital Gain Formula Gain (x times) = 1 + (“Digital Gain” / 128) STC-MBS122BPOE / STC-MCS122BPOE 38/73 Product Specifications and User’s Guide... -
Page 39: Exposure Time
The lower limit of signal is clamped at this setting level. The signal does not lower than this. GenICam Parameters BlackLevel IFloat Type Black Level Range: 12bits output: 0 to 240 10bits output: 0 to 60 8bits output: 0 to 15 Default: 0 STC-MBS122BPOE / STC-MCS122BPOE 39/73 Product Specifications and User’s Guide... -
Page 40: Alc (Auto Light Control)
Default: 1 * Sets 10 on Region 4 only Sets the weight for each weight area. AutoLuminancePeak IInteger Type Importance ratio for the brightness peak at ALC control. Range: 0 to 255 Default: 0 STC-MBS122BPOE / STC-MCS122BPOE 40/73 Product Specifications and User’s Guide... -
Page 41: Alc Control Method
The brightness of image maintains to “AutoLuminanceTarget” with AGC and auto shutter functions. If AGC and auto shutter are ON for ALC control, auto shutter function maintains brightness first. The AGC function maintains brightness if brightness cannot maintain to “AutoLuminanceTarget” with auto shutter. STC-MBS122BPOE / STC-MCS122BPOE 41/73 Product Specifications and User’s Guide... -
Page 42: Agc (Auto Gain Contorl)
Range: 0 to 208 Default: 0 This cannot be set greater than “GainAutoLimitMax” GainAutoLimitMax IFloat Type Maximum gain for AGC [GainSelector] Range: 0 to 208 Default: 208 This cannot be set smaller than “GainAutoLimitMin” STC-MBS122BPOE / STC-MCS122BPOE 42/73 Product Specifications and User’s Guide... -
Page 43: Auto Shutter
3. Sets “GainAutoLimitMin” and “GainAutoLimitMax” when using AGC function. 4. Sets “Continuous” for “ExposureAuto” when using auto shutter function. 5. Sets “ExposureAutoLimit Min” and “ExposureAutoLimitMax” when using auto shutter function. 6. Sets “AutoLuminanceTarget”. STC-MBS122BPOE / STC-MCS122BPOE 43/73 Product Specifications and User’s Guide... -
Page 44: White Balance (Only Available For Color Camera)
Sets “OFF” at “BalanceWhiteAuto” automatically after sets “Balance Ratio” for all colors. Push to set white balance setting procedure 1. Sets the flat white target then acquires image. 2. Sets “Once” at “BalanceWhiteAuto”. STC-MBS122BPOE / STC-MCS122BPOE 44/73 Product Specifications and User’s Guide... - Page 45 1. Selects “Preset0” to “Preset2” at “BalanceWhiteAuto”. 2. Selects adjusting color from Red, Green or Blue at “BalanceRatioSelector”. 3. Sets gain for selected adjusting color at “BalanceRatio”. The settings can be save into camera with “UserSetControl” function. STC-MBS122BPOE / STC-MCS122BPOE 45/73 Product Specifications and User’s Guide...
-
Page 46: White Balance Calculate Region Setting
Vertical offset (in line) for region 0 OffsetY Range: 0 to 2,999 Default: 0 The white balance calculation region settings are like below: BalanceWhite AutoOffsetY White balance gain BalanceWhite calculation region 0 AutoHeight BalanceWhite BalanceWhite AutoOffsetX AutoWidth STC-MBS122BPOE / STC-MCS122BPOE 46/73 Product Specifications and User’s Guide... -
Page 47: Gamma Correction
OffsetY IInteger Type Vertical offset for output image (in line) Range: 0 to 2,996 Default: 0 Adjustable steps: 4 The ROI region settings are below: OffsetY Height ROI region OffsetX Width STC-MBS122BPOE / STC-MCS122BPOE 47/73 Product Specifications and User’s Guide... -
Page 48: Pixel Format
(*1) Decimation cannot change horizontal only or vertical only. Selection applies for horizontal and vertical. (*2) It is necessary to change exposure time (to shorten exposure time), to increase frame rate when using Decimation. STC-MBS122BPOE / STC-MCS122BPOE 48/73 Product Specifications and User’s Guide... -
Page 49: Trigger
Camera Action 0 Trigger Delay Timing Generator Software Signal 0 Software Signal 1 Sensor Logic Block 0 Trigger Source The trigger signal is selectable by GenICam commands. TriggerSource: select trigger type STC-MBS122BPOE / STC-MCS122BPOE 49/73 Product Specifications and User’s Guide... -
Page 50: Image Flip
Range: 0 to 4,095 LUTValue IInteger Type The output value for input value that specifies by index Range: 0 to 4,095 4095 4095 LUT Index e.g. LUT usage (low brightness level enhancement) STC-MBS122BPOE / STC-MCS122BPOE 50/73 Product Specifications and User’s Guide... -
Page 51: Flat Field Correction Function
False: None FFC applied image is acquired. FFCIndex IInteger Type The index of area for FFC function Range: 0 to 12,254 12,126 12,254 FFCValue IInteger Type The FFC value for selected index area. Range: 0 to 1,023 STC-MBS122BPOE / STC-MCS122BPOE 51/73 Product Specifications and User’s Guide... -
Page 52: Ffc Function Procedure
* Note1: Please sets “OFF” for “Trigger mode” as free-run operation when using FFC function. * Note2: Please adjusts “Exposure Time” to acquiring “50%” brightness level of image when using FFC function. * Note3: Please uses FFC function again when changing lens or light source STC-MBS122BPOE / STC-MCS122BPOE 52/73 Product Specifications and User’s Guide... -
Page 53: Defective Pixel Correction
Horizontal position for selected index for process defective pixel correction Range: 0 to 4.095 Default: 0 PixelCorrectionY IInteger Type Vertical position for selected index for process defective pixel correction Range: 0 to 2,999 Default: 0 STC-MBS122BPOE / STC-MCS122BPOE 53/73 Product Specifications and User’s Guide... -
Page 54: Counter And Timer Control
CounterReset IEnumeration Type Polarity of reference signal to reset counter Activation CounterReset ICommand Type Rest switch “Activate as switch when selecting “Software” at “CounterResetSource” CounterValue IInteger Type Returns number of counter STC-MBS122BPOE / STC-MCS122BPOE 54/73 Product Specifications and User’s Guide... -
Page 55: E.g. Event Control
“Line 0 Input Rising Edge”, “Line 0 Input Falling Edge”, “Line 2 Input Rising Edge” and “Line 2 Input Falling Edge” Event Notification IEnumeration Type Event notification ON / OFF selection On: Enable event notification Off: Disable event notification STC-MBS122BPOE / STC-MCS122BPOE 55/73 Product Specifications and User’s Guide... -
Page 56: Chunk Control
IInteger Type Select camera to apply action command Logical AND of Group Mask of camera and Group Mask of action command is 1 for any bit of 32bits, camera executes action command. STC-MBS122BPOE / STC-MCS122BPOE 56/73 Product Specifications and User’s Guide... -
Page 57: Ieee1588
Defined delay between master device and slave device by comparing these messages. If time difference between master device and slave device is occurred, adjust internal clock of slave device to synchronize to master device. Synchronize clock regularly to correcting time drift. STC-MBS122BPOE / STC-MCS122BPOE 57/73 Product Specifications and User’s Guide... - Page 58 Timestamp, action command will be scheduled automatically and each camera start exposing at same time. ActionControl setting is required when action command generating. IEEE1588 PTP supported Switching HUB M: Master S: Slave e.g. PTP configuration STC-MBS122BPOE / STC-MCS122BPOE 58/73 Product Specifications and User’s Guide...
-
Page 59: 11 Genicam Command
Sub minor version of the Transport Layer of the device. DeviceMaxThroughput Maximum bandwidth of the data that can be streamed out of the device. DeviceLinkSelector Selects which Link of the device to control. STC-MBS122BPOE / STC-MCS122BPOE 59/73 Product Specifications and User’s Guide... - Page 60 Latches the current timestamp counter into Timestamp Latch Value. TimestampLatchValue Returns the latched value of the timestamp counter. DeviceUserMemory Read / Write the user data from / to the non-volatile memory. STC-MBS122BPOE / STC-MCS122BPOE 60/73 Product Specifications and User’s Guide...
-
Page 61: Imageformatcontrol
Selects which test pattern generator is controlled by the Test Pattern feature. TestPattern Selects the type of test pattern that is generated by the device as [TestPatternGeneratorSelector] image source. TestPatternInputValue Test Pattern Input Value [TestPatternGeneratorSelector] STC-MBS122BPOE / STC-MCS122BPOE 61/73 Product Specifications and User’s Guide... -
Page 62: Acquisitioncontrol
Sets the automatic exposure mode when Exposure Mode is Timed. ExposureAutoLimitMin Determine the lower limit of exposure time when Exposure Auto is set to Continuous. ExposureAutoLimitMax Determine the upper limit of exposure time when Exposure Auto is set to Continuous. STC-MBS122BPOE / STC-MCS122BPOE 62/73 Product Specifications and User’s Guide... -
Page 63: Analogcontrol
Determine X offset of targeted region for auto white balance. [BalanceWhiteAutoRegionSelector] (STC-MCS122BPOE) BalanceWhiteAutoOffsetY Determine Y offset of targeted region for auto white balance. [BalanceWhiteAutoRegionSelector] (STC-MCS122BPOE) Gamma Controls the gamma correction of pixel intensity. STC-MBS122BPOE / STC-MCS122BPOE 63/73 Product Specifications and User’s Guide... -
Page 64: Lutcontrol
Returns the Value at entry FFC Index of the FFC table. FFCValueAll [FFCSelector] Accesses all the FFC table coefficients in a signal access without using individual FFC Index. This feature can only be accessed programmatically. STC-MBS122BPOE / STC-MCS122BPOE 64/73 Product Specifications and User’s Guide... -
Page 65: Digitaliocontrol
Selects if the selected Logic Block Input source signal is inverted. [LogicBlockSelector] [LogicBlockInputSelector] SoftwareSignalControl 11.9 Name Description SoftwareSignalSelector Selects which Software Signal features to control. SoftwareSignalPulse Generates a pulse signal that can be used as a software trigger. [SoftwareSignalSelector] STC-MBS122BPOE / STC-MCS122BPOE 65/73 Product Specifications and User’s Guide... -
Page 66: Counterandtimercontrol
Selects the source of the trigger to start the Timer. TimerTriggerActivation [TimerSelector] Selects the activation mode of the trigger to start the Timer. TimerValue [TimerSelector] Reads or writes the current value (in microseconds) of the selected Timer. STC-MBS122BPOE / STC-MCS122BPOE 66/73 Product Specifications and User’s Guide... -
Page 67: Eventcontrol
Save the User Set specified by User Set Selector to the non-volatile memory of the device. UserSetDefault Selects the feature User Set to load and make active by default when the device is reset. STC-MBS122BPOE / STC-MCS122BPOE 67/73 Product Specifications and User’s Guide... -
Page 68: Chunkdatacontrol
Provides the mask that the device will use to validate the action on reception of the action protocol message. ActionGroupKey [ActionSelector] Provides the key that the device will use to validate the action on reception of the action protocol message. STC-MBS122BPOE / STC-MCS122BPOE 68/73 Product Specifications and User’s Guide... -
Page 69: Fileaccesscontrol
Represents the file operation result. [FileSelector] [FileOperationSelector] FileSize [FileSelector] Represents the size of the selected file in bytes. TestControl 11.16 Name Description TestPendingAck Tests the device's pending acknowledge feature. TestEventGenerate Generates a Test Event. STC-MBS122BPOE / STC-MCS122BPOE 69/73 Product Specifications and User’s Guide... -
Page 70: Transportlayercontrol
Controls the Persistent subnet mask associated with the Persistent IP [GevInterfaceSelector] address on this logical link. GevPersistentDefaultGateway Controls the persistent default gateway for this logical link. [GevInterfaceSelector] GevGVCPExtendedStatusCodesSelector Selects the GigE Vision version to control extended status codes for. STC-MBS122BPOE / STC-MCS122BPOE 70/73 Product Specifications and User’s Guide... - Page 71 GVSP transmitter must send data stream or the destination IP address from which a GVSP receiver may receive data stream. GevSCSP [GevStreamChannelSelector] Indicates the source port of the stream channel. STC-MBS122BPOE / STC-MCS122BPOE 71/73 Product Specifications and User’s Guide...
-
Page 72: 12 Revision History
Note: Product specifications would be changed without notification. GigE Vision is trademark of AIA. GenICam is trademark of EMVA. Other company names and product names in this document are trademarks of their respective owners. STC-MBS122BPOE / STC-MCS122BPOE 72/73 Product Specifications and User’s Guide... - Page 73 No.19S207-00 19F, Ebina Prime Tower 9-50, Chuo 2 chome Ebina-city, Kanagawa 243-0432 Japan TEL 81-46-236-6660 FAX 81-46-236-6661 URL http://www.sentech.co.jp/ STC-MBS122BPOE / STC-MCS122BPOE 73/73 Product Specifications and User’s Guide...
