Arrow Storage Products BR67 Owner's Manual & Assembly Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
ABO01
Model No.
717840316
Storage Area: 39 Sq. Ft.
3,6 m
BUILDING DIMENSIONS
*Approx.
Base
Size
Size
6' x 7'
74" x 81"
1,8 m x 2,0 m
188,0 cm x 205,7 cm
BR67
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
212 Cu. Ft.
6,0 m
2
3
* Size rounded off to the nearest foot
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
76 1/4"
193,7 cm
212,1 cm
DW67BRD
Depth
Height
Width
83 1/2"
69 7/8"
71 1/4"
177,5 cm
181,0 cm
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Depth
Height
78 1/4"
68 5/8"
198,8 cm
174,3 cm
Door
Opening
Width
Height
32"
60"
81,3 cm
152,4 cm

Advertisement

Table of Contents
loading

Related Manuals for Arrow Storage Products BR67

Summary of Contents for Arrow Storage Products BR67

  • Page 1 Owner's Manual & Assembly Instructions ABO01 Model No. BR67 DW67BRD Missing Parts, Questions on Assembly? Call: 1-800-851-1085 or assist@arrowsheds.com Do not return to dealer, they are not equipped to handle your requests. 717840316 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE Storage Area: 39 Sq.
  • Page 3 BEFORE YOU BEGIN..Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.

  • Page 4: Tools And Materials

    PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 5 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
  • Page 6 CARE & MAINTENANCE..Finish: For long lasting fi nish, periodically clean and wax the exterior surface. Touch-up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
  • Page 7 ACCESSORIES..FLOOR FRAME KITS ROOF STRENGTHENING (heavy snow load) KITS Extra roof beams and gable braces designed for added protection against heavy snow accumulation. Increases the strength of your roof. BEFORE AFTER ANCHOR KITS Model No. AK4 MODELS FB47410, FB5465, FB106-A Anchor Kit contains heavy-duty steel FB109-A and FB1014-A augers, 60' (18 m) of steel cable and...

  • Page 8: Special Note

    ORDERING ACCESSORIES..02/13 We recommend that you purchase accessory items from your local storage building dealer whenever possible; however, because the full line of accessories is not always available from all dealers, Arrow is offering them to you on a direct basis. There are two ways to order Arrow Storage Building Accessories: Option 1 Option 2...
  • Page 9 Base ZX09 The Base For Your Building OPTION 1: Wood Platform If you decide to build your own base, be sure to select the appropriate materials. These are the recommended materials for your base:  2 x 4's (38 mm x 89 mm) Pressure Treated Lumber ...
  • Page 10 Anchoring Anchoring Down The Building It is important that the entire fl oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base.
  • Page 11 Hardware ZX11 Remove from bag of screws and save for the last step 65900A 65923 #10Bx1/2" (13 mm) 65004 65103 #8-32x3/8" (10 mm) Black Screw (8) #8Ax5/16" (8 mm) #8-32 Hex Nut (93) Bolt (93) (Packed with Screws) Screw (214) 65109 67468 66646...

  • Page 12: Parts List

    Parts List ABO12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 10539 Roof Beam 10540 Side Wall Angle (Right) 5996 Right Gable 5997 Left Gable 10454 Side Roof Trim 10538 Right Roof Panel 80003 Left Roof Panel 10499 Horizontal Door Brace 6657...
  • Page 13 Assembly by Key No. ZX13...
  • Page 14 Step 1  Parts Needed For   80007 Left Side Floor Frame (2) Floor Frame Assemblies  10542 Right Side Floor Frame (2) ZX14 (10) The side fl oor frames are made up of two pieces. The holes in these pieces will align when the pieces are positioned with correct amount of overlap.

  • Page 15: Frame Assemblies

    Step 2  80005 Left Side Wall Angle (2)  Parts Needed For   10541 Side Wall Channel (4) Frame Assemblies 10540 Right Side Wall Angle (2) ZX15 Side Wall Channels 78 1/8" 198,4 cm 10541 The main frame pieces reinforce 10541 the walls.
  • Page 16 Step 3  Parts Needed For   10539 Roof Beam (4) Roof Beam Assembly ZX16 (14) The roof beams join the two gables 10539 and support the roof panels. The roof beam is made up of four pieces overlapped back to back at the center. Hint: These pieces are force-fi...

  • Page 17: End View

    Step 4  Parts Needed For   9396 Door Track (1) Door Track Assembly ZX17 The door track assembly supports the sliding doors and reinforces the front wall. Hint: The holes in the top side of the door track are for fastening the gable to the top of the front wall in a later step.
  • Page 18 Step 5  9403 Front Floor Frame (1)  Parts Needed For   Side Floor Assembly (2) Floor Frame  9399 Rear Floor Frame (1) ZX18 RIGHT REAR 10542 Assemble the four corners of the fl oor frame using two screws at each corner as shown.

  • Page 19: Top View

    Step 6  Parts Needed For   9389 Front Corner Panel (2)  10681 Rear Corner Panel (2) Corners ABO19 Narrow Side 10681 (12) WideSide NOTE REAR The remainder of the building assembly STEP requires many hours and more than one 10681 person.
  • Page 20  9397 Rear Wall Angle (1) Step 7  Parts Needed For   9925 Rear Wall Channel (1)  Side Wall Channel Assemblies (2) Frames  Side Wall Angle Assemblies (2)  Door Track Assembly (1) ZX20 (22) The main frame pieces give rigidity to the side walls and provide a surface for attaching the gables which sup- port the roof.
  • Page 21 Step 8  Parts Needed For   6515 Wall Panel (2) Wall Panels  7332 Wall Panel (4) ABO21 STEP 6515 6515 (90) 7332 7332 STEP The wall panels come in two widths. Each wall panel has a crimped rib on one side.
  • Page 22 Step 9  Parts Needed For   9369 Door Jamb (2) Door Jamb P22 ctr STEP (3) bolts TOP VIEW Door Track Hex Nut Acorn Nut Plug The door jambs reinforce the door 9369 opening and provide an attractive Bolt trim.
  • Page 23 Step 10  Parts Needed For   5996 Right Gable (2) Gable Assemblies  5997 Left Gable (2) ZX23 The gables go on top of the front and rear walls to support the roof beams. STEP NOTE Edge Trim The gables are packed nested (Plastic Piece) together and might be mistaken...
  • Page 24 Step 11  Right Gable Assemblies (2)  Parts Needed For   Left Gable Assemblies (2) Gables/Braces  6658 Gable Brace (2) ZX24 (16) STEP Lift and fasten a right and left gable, under angle at corner, to the Gable 6658 Gable Brace door track with screws.
  • Page 25 Step 12  Parts Needed For   Main Roof Beam (1) Roof Beam ZX25 Spread Two Halves Of Roof Beams Spread the two halves of the main STEP roof beam and fasten the roof beam to the gable brace of the front gable. Fasten the other end of the roof beam to the gable brace of the rear gable.
  • Page 26 Step 13  Parts Needed For   10538 Right Roof Panel (1) Right Roof Panel ZX26 STEP Installing the roof panels is best done 80003 10538 with a step ladder. Begin installing roof panels at the back right corner 6444 of the building.

  • Page 27: Roof Assembly

    Step 14  Parts Needed For   80003 Left Roof Panel (1)  6444 Roof Panel (2) Roof Assembly ZX27 STEP 80003 Left Roof Panel (12) STEP 6444 Roof Panel Install a left roof panel at the left 6444 Roof Panel rear corner of the roof.
  • Page 28  10453 Ridge Cap (1) Step 15  Parts Needed For   80003 Left Roof Panel (1) Ridge Caps & Panels  10538 Right Roof Panel (1) ZX28  8814 Ridge Cap (1) 10453 STEP (14) (32) Install the fi rst ridge cap on the completed roof section using bolts and nuts.
  • Page 29 Step 16  Parts Needed For   8811 Left Side Roof Trim (2) Roof Trim  10454 Right Side Roof Trim (2) ZX29 Attach the right and left side roof trim to the lower end of the roof panels on each side of the building using screws at each panel overlap.

  • Page 30: Door Assembly

    Step 17  Parts Needed For   6657 Door Handle Brace (2)  10476 Right and Left Doors (2) Door Assembly  10499 Horizontal Door Brace (4) ABO30 (10) The steps on this page tell how to assemble the right door. You will per- form exactly the same procedures for 66045 66045...
  • Page 31 Step 18  Parts Needed For   Right Door Assembly (1) Door Installation & Adjustment Left Door Assembly (1) ZX31 Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the building) behind door jamb into the front frame track.
  • Page 32 BR67 DW67BRD ABO32 Anchoring Anchor your building at this time. SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfi...
