- Page 1 • Xerox DocuTech 61xx • Xerox iGen3® Digital Production Press • Xerox Nuvera™ 100 / 120 Digital Production System • Xerox DocuColor 6060 / 7000 / 8000 Digital Color Press GBC Fusion Punch II with Offset and Bypass Stacker June 29, 2005...
- Page 2 Xerox iGen3® Digital Production Press, Xerox Nuvera™ Digital Production System and Xerox DocuColor 6060 / 7000 / 8000 Digital Color Press are trademarks of, or licensed to, Xerox Corporation. Other product names used herein are trademarks of their respective owners.
-
Page 3: Table Of Contents
Table Of Contents INTRODUCTION ... I About this guide ... I Contents ... I ... 1-1 RODUCT VERVIEW Install Planning ... 1-2 Device Configurations ... 1-2 Space Requirements... 1-2 Electrical Requirements ... 1-4 Environmental Requirements... 1-4 Estimated Installation Time ... 1-4 Operating Supplies ... - Page 4 Table Of Contents...
-
Page 5: Introduction
This guide will provide the Analyst and the coordinating Customer with common FP II specifications and specific pre- installation tasks for the specific Xerox printer to which the FP II is to be installed with. This section lists the contents of this guide: •... - Page 6 GBC Fusion Punch II with Offset and Bypass Stacker...
-
Page 7: Product Overview
1. Product Overview Fusion Punch Offset Stacker The GBC Fusion Punch II provides in-line printer punching combining printing and punching into one step. Single sheets are punched and emerge ready to be finished into lay flat documents. These types of documents are typically bound with coil, wire or plastic comb binding and will lay flat when opened. -
Page 8: Install Planning
Bypass Stacker, optional (not available with iGen3) Note: The GBC Fusion Punch II with dual Stacker is currently NOT supported with the Xerox iGen3 The space requirements diagram provides machine footprint as well as the overall operating and maintenance area. - Page 9 GBC Fusion Punch II with Offset and Bypass Stacker Power 36 inches (914 mm) GBC Fusion Punch II 54 inches (1372 mm) 36 inches (914 mm) Note: The space requirements diagram for the FP II is a representation only and not drawn to scale. Dimensions Fusion Punch Width x Depth x...
-
Page 10: Electrical Requirements
GBC Fusion Punch II with Offset and Bypass Stacker Electrical Requirements Environmental Requirements Estimated Installation Time Operating Supplies Device North America Punch Power 115V, 60 Hz, 4.7A Stacker Power 115V, 60 Hz, 1.0A Temperature 41 - 104° F (5 - 40°C) Humidity 30 –... -
Page 11: Floor Load
Measurement 9 ft (2.74 m) 6.75 ft (2.1 m) Note: The floor level is based on a printer paper exit height above the floor of 34” (860 mm). Point load Casters A: 108.5 lbs / sq.in. (7.63 kg / sq. cm) Casters B: 201.5 lbs / sq.in. -
Page 12: Unique Features Set
GBC Fusion Punch II with Offset and Bypass Stacker Unique Features Set The following are diagrams of the die set configurations, which are available for the Fusion Punch ll. These pictures do not reflect sheet size limitations, rather provide a visual for the die set configuration. -
Page 13: Xerox Docutech 61Xx
GBC Fusion Punch II with Offset and Bypass Stacker 2. Xerox DocuTech 61xx Performance Specifications Punch / Stacker Paper Size / Weight Stacker Capacity Input Heights Limitations Listed below are the Performance Specifications for the Fusion Punch II. Specifications Paper Size: 7” x 10” (178 x 254 mm) – 11” x 17” (279 x 432 mm) / A3 Paper Weight: 16 lbs (60 gsm) –... -
Page 14: System Dependencies And Prerequisites
GBC Fusion Punch II with Offset and Bypass Stacker System Dependencies and Prerequisites Configuration Guide Printer Configurations INTERPOSER BYPASS - The following inline devices are available: • BDFx • Book Factory • Book Factory with Gateway • SQFBM Productivity Guide Listed below are the dependencies and prerequisites for installing the Fusion Punch II. -
Page 15: Xerox Igen3® Digital Production Press
432mm) / A3 may have stacking limitations. If installing a new FP II on an existing iGen3 installation, a Xerox iGen3 Finishing Interface kit (product code UYR) must be ordered. The Fusion Punch II requires an iGen3 Upgrade Kit, part... -
Page 16: Configuration Guide
Finishing Solutions that are currently supported. Printer Configurations FEEDER FEEDER PRINT ENGINE The diagram above is only an example. The Xerox iGen3 Digital Production Press can have the following configurations: • Up to 6 Feeders • 1 inserter • Up to 4 Stackers... -
Page 17: Xerox Nuvera™ 100 / 120 Digital Production System
GBC Fusion Punch II with Offset and Bypass Stacker 4. Xerox Nuvera™ 100 / 120 Digital Production System Performance Specifications Punch / Stacker Paper Size / Weight Stacker Capacity Input Heights Limitations Listed below are the Performance Specifications for the Fusion Punch II. -
Page 18: System Dependencies And Prerequisites
The Finisher Transport Module is required for in-line connectivity to the printer. A Xerox Document Stacker 5000 is recommended for stacking paper weights greater than 203 gsm and sizes smaller than 8.5” x 11” (216 x 279 mm) or larger than 11” x 17”... -
Page 19: Xerox Docucolor 6060 / 7000 / 8000 Digital Color Press
GBC Fusion Punch II with Offset and Bypass Stacker 5. Xerox DocuColor 6060 / 7000 / 8000 Digital Color Press Performance Specifications Listed below are the Performance Specifications for the Fusion Punch II. Punch / Stacker Paper Size / Weight... -
Page 20: System Dependencies And Prerequisites
. A DFA Enablement Kit (675K11272) is required to connect the FPII with the Xerox DocuColor 6060 / 7000 / 8000. A Feeding & Finishing Interface Unit kit (FFIU kit 497K02331) is required to connect the FPII with the Xerox DocuColor 6060 / 7000 / 8000. -
Page 21: Customer Agreement Form
For installations made in the US and Canada, a copy of the signed Customer Agreement must A) Attached to the XOA / Customer purchase order and faxed to SPA: 1-800 –407-8430. B) Scanned and emailed to Phil.Schmelzlen@xerox.com, or faxed to Phil Schmelzlen (585) 427-3140 (8*227-3140).
