Jabra Pro 9450 Mono Flex
How to connect my Jabra Pro 9450 with Alcatel IP Touch 4028,
4038, 4068
Prerequisite:
Jabra Pro 9450 + Jabra Link 14201-36
In combination with one of the following phones:
IP Touch 4028
IP Touch 4038
IP Touch 4068
Connection:
2-sided end:
Insert the RJ45 plug (red banderole) into the red socket marked with "
AUX" and the RJ10 plug (blue banderole) into the blue socket marked
with the "phone" symbol on the base of the Jabra Pro 94x0.
2-fold Y-coupling end:
Insert the 3.5 mm phone plug into the "headset" socket and the RJ12
plug into the "bell" socket of the phone. Now plug the phone lead of the
phone directly into the additional socket of the Y cable.
You now have the option of setting up the headset on your phone via the
automatic or manual configuration.
Automatic configuration:
https://www.jabra.com/supportpages/jabra-pro-9450/9450-65-707-
105/faq/06775e6a-dac5-472a-a4b3-87a8678d2113
03/03/2024 10:49
Page 1 of 3
Advertisement
Related Manuals for Jabra Pro 9450 Mono Flex
Summary of Contents for Jabra Pro 9450 Mono Flex
- Page 1 03/03/2024 10:49 Jabra Pro 9450 Mono Flex How to connect my Jabra Pro 9450 with Alcatel IP Touch 4028, 4038, 4068 Prerequisite: Jabra Pro 9450 + Jabra Link 14201-36 In combination with one of the following phones: IP Touch 4028...
- Page 2 Set the phone set-up switch to position "A". Setting the microphone volume: Remove the cover from the base of the Jabra Pro 9450 and make a call with the headset, to a colleague for example. If you are too loud or too quiet to the person you are calling, please use the volume adjuster until you achieve the optimum volume level.
- Page 3 Dial phone number > the following now appears in the phone display "transfer" > now press the appropriate function button next to the phone display > when connected you must now end the call using the button identified with the "handset". https://www.jabra.com/supportpages/jabra-pro-9450/9450-65-707- Page 3 of 3 105/faq/06775e6a-dac5-472a-a4b3-87a8678d2113...
